Home Accents Holiday Gravedigger Easy Assembly And Operation Instructions

EASY ASSEMBLY AND OPERATION INSTRUCTIONS
5124733_Gravedigger
Please follow the step by step guide and enjoy your
Gravedigger!

CARE AND STORAGE INSTRUCTIONS

For best performance operate your item indoors. When not in use, store this product in it's original packing. Keep
away from heat and moisture.

TROUBLE SHOOTING:

• Ensure that the item's adapter is plugged in at the Function Control Box and in the wall.
• Ensure that the switch on the function control box is on the desired setting.
• If not functioning properly, ensure that cables are connected to their corresponding cable as shown in the instruction sheet (ex: Mouth doesn't move, eyes don't light up, body doesn't move).
• Be sure nothing is blocking movement or caught in moving parts.
• Ensure that the floor or surface that the item sits on is flat and level.
• Be sure nothing is blocking the sensor.

PARTS LIST

A. Base x 1
B. Support Pole x 4
C. Shoe x 2
D. Pants x 1
E. Torso Frame x 1
F. Shirt x 1
G. Left Arm x 1
H. Left Hand x 1
I. Shovel Handle x 1
J. Shovel x 1
K. Right Arm x 1
L. Right Hand and Lantern x 1
M. Head x 1
N. Hat x 1
O. Adapter * x 1
O
Adapter *
* Power Adapter Spec
Input: 100 - 240VAC 50/60Hz
Output: 5.9V 1.5A
BEFORE ASSEMBLING, REMOVE ALL THE ABOVE PARTS FROM BOX. IF ANY PART IS MISSING, DO NOT ATTEMPT TO ASSEMBLE THE PRODUCT AND CONTACT
CUSTOMER SERVICE FROM 8:30AM TO 5:30PM PST AT 1-877-527-0313, 1-855-428-3921.EMAIL CUSTOMERSERVICE@SVIUS.COM.
Right and Left are relative to the character.
Locking Pin
Click
Means It's
Locked
B
B
Back
Right
A
Front
Note: Throughout the instructions, Right
and Left are relative to the character.
A
F
M
C
B B
A
C C
B B
Left
A
1.1

WARNING

This item is not a toy and should be used for decoration only. This item contains small parts that can be a choking
hazard. Keep all plastic and wire parts away from children.
1. Please use the transformer supplied by manufacturer.
2. Please assemble item according to instructions. Connect all wires according to matching color.
3. Children should be supervised by adults. Item should not be grabbed, as it becomes a tipping
hazard. Keep all away from the transformer, as it heats up during operation.
Please view all instructions carefully before assembling. Save this instruction sheet for future reference.
B C
G H
N
C
B
1.2
B
C
1 3
.
USA/ États-Unis 1005343392
D E
I J K
B
B
C
2 1
.
YOW 1005215772
TM
L
D
2.2
1/3
