Deda Elementi SL38C User Manual page 3

Wheel Type
Shimano/Sram
Campagnolo
closing of the wheel or excessive closing force of the
wheel. The improper adjusting of the wheel closing can
cause serious accidents and injury for the user.
• When the lever is closed, make sure it is completly
closed (full travel) and do not allow the frame or fork
to inhibit the complete closing of the lever (Fig. 3)
• Check before every ride the closing force of the
wheel and correct mechanism functioning of quick
releases.
Fig 3
OK
WARNING: After cleaning the bicycle or a ride in rain
conditions, please lubricate pivot and cam points in
order to prevent oxidation phenomenons that damage
the correct mechanism functioning of quick releases.
BRAKE PADS INSTRUCTIONS
Deda SL38C carbon wheels are supplied with specific
Deda Elementi brake pads for carbon rims.
BRAKE PADS MOUNTING
• Remove original pads from the brakesets of your
bicycle and replace them with those blue color pro-
vided with the wheels. Make sure to respect the cor-
rect mounting direction of brake pads by watching
the indications directly present on the pad surface.
• If present on the brake pad holder, tighten the secu-
rity screw to secure the pad in position.
• Adjust the brake pads in order to be aligned with
the rim brake surface and to be around 2mm distant
from the upper edge of the rim (Fig. 4).
Fig 4
2 mm
Before usign the bicycle, always make sure that the
installed brakesets installed work correctly and brake
pads have been mounted according to the wheels
user's manual. Frequently inspect the brake pads and,
if necessary, remove metal ships or other foreign debris
from their surfaces. In rain conditions the braking power
decrease so that the braking distance of the bicycle will
increase considerably. Once the wear limit of the brake
pads has been reached (a Wear Limit is indicated on
the pad surface), discontinue riding the bicycle and
replace them with original Deda Elementi spare parts.
WARNING: The brake pads installation require a
specifc knowledge of the product. In case of doubts
always contact a official Deda Elementi dealer or a
qualified bicycle technician. The incorrect installation of
the brake pads can cause serious accident and injury
for the user.
WARNING: Metal debris and foreign objects included
into the brake pad surface will compromise the braking
performance and cause severe rim damages that may
result in wheel failure and cause serious accident to
the user.
Freehub Cassette Compatibility
Shimano 11v
Campagnolo 11v
NO!
Shimano 10v + 1.80mm
spacer
Campagnolo 10v
CLEANING, MAINTENANCE AND REPLACEMENT
PARTS
The wheels you have just purchased are high technolgy
products that require specific care and maintenance
to fully obtain the maximum performance advantages
and to preserve them over time. So we recommend to
follow simple rules of use to avoid any kind of problem.
WARNING: Never clean the wheels and parts using
high pressure and high temperature water. The water
pressure can overcome seals and bearings protections
systems causing damages irreparably or malfunfion of
internal parts of the hub. Never use solvents, chemicl
products, petrol or similar substances, over the hubs
that can damage seals and rubber gaskets or remove
the grease from the bearings completely.
After the bicycle washing, dry every parts and
components avoiding to store water into the hollow
points of the wheel ( for instance inside the rim and
hub).
Frequently check the wear status od the wheels parts
and if necessary make the maintenance and/or parts
replacement through the official Deda Elementi dealers.
The recommended service intervals depend on the use
and using condition of the wheels. It is recommended
to make an inspection after each riding season or every
time in case of bearing problems, wheel out of center or
damaged parts are apparent. Since specific tools and
experience are necessary for hub maintenance, wheel
trueing or parts replacement it is recommended that
the service should be done by official Deda Elementi
dealer.
For any service or replacement parts, only orginal
Deda Elementi spare parts have to be used in order
to guarantee the product quality and the warranty
maintaining.
CONTACTS
For any question or technical information please
contact Deda Elementi by visiting the website at www.
dedaelementi.com and through the email address
info@dedaelementi.com.
Deda Elementi s.r.l reserves the right to modify without
notice the content of this manual always guaranteeing
the avalaibility of the updated versions on the website
dowanload area.
www.dedaelementi.com
Deda Elementi S.r.l.
Via Leonardo Da Vinci, 21/23
26010 Campagnola Cremasca (CR) - Italia
Tel. +39 0373 750 129
Fax +39 0373 751 105
www.dedaos.com.tw
Deda OS
No.8, Lane 150-30, Sec. 3, Xitun Rd.,
Xitun Dist.
Taichung City 407, Taiwan (R.O.C.)
tel: +886-4-24623436
fax: +886-4-24623430
Deda Elementi USA
dedausa@dedaelementi.com
Sram 10v +
1.80mm spacer
-
