(1) ATTACHING UPRIGHT SUPPORTS TO BOTTOM TRAY AND
DRAWER BODY
1. Loosely attach the 4 upright supports (3) to the bottom tray (2) using the M6x10 bolts (7).
2. With a helping hand, slot the drawer body (1) into the uprights, align the holes and
loosely fit the top bolts (7).
3. The handle (4) can be placed into the lower mounting holes either side of the trolley.
Use the longer bolts (8) to install the handle.
4. Fit the remaining bolts to the drawer body, square up the unit and tighten all securely.
