Summary of Contents for SinoCon KonNad C2000-C2-SFI0101-BA1
- Page 1 Last updated: 2019-11-8 C2000-C2-SFI0101-BA1 User Manual 1 * RS232 ⇋ 1 * RS485/422 Serial-to-Ethernet Device — Serial-to-Serial Converter SinoCon Co., Ltd.
-
Page 2: Table Of Contents
3.2. RS232 to RS485 3.2.1. RS232 to RS485 point-to-point / two-wire half-duplex 3.2.2. RS232 to RS485 point-to-multipoint / two-wire half-duplex 3.2.3. RS232 to RS485 to RS232 two-wire half-duplex 4. Package Contents 5. Warranty Policy SinoCon Co., Ltd. www.sinoconsys.com 2 / 17... - Page 3 Copyright Notice ©2000 - 2019 SinoCon Co., Ltd. All Rights Reserved. Trademarks The KonNaD logo is a registered trademark of SinoCon Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer This document only provides information about KonNaD products. No license to any intellectual property rights is granted by this document, including any intellectual property licenses, expressed or implied, or by any means.
-
Page 4: Getting Started
After the device is connected to the other device, it indicates data from the RS485/422 to RS232 port when the "RXD" flashing, and it indicates data from the RS232 to RS485/422 port when the "TXD" flashing. Indicator Refer to for the meaning of LED indicators. SinoCon Co., Ltd. www.sinoconsys.com 4 / 17... -
Page 5: Hardware Description
Data Direction Control Automatic Data Direction Control Communication Protocol RS485/422 Automatic Identification Power Power Connector Dual power inputs Input Voltage 9~27VDC Current 80mA @ 12VDC Physical Dimensions 75*105*30mm Characteristics Installation Din-rail or wall SinoCon Co., Ltd. www.sinoconsys.com 5 / 17... - Page 6 C2000-C2-SFI0101-BA1 User Manual Classification Parameter Specification Environmental Limits Operating Temperature -40℃ ~ 85℃ Storage Temperature -60℃ ~ 125℃ Ambient Relative Humidity 5% ~ 95% RH, non-condensing SinoCon Co., Ltd. www.sinoconsys.com 6 / 17...
-
Page 7: Apprearance
C2000-C2-SFI0101-BA1 User Manual 2.2. Apprearance SinoCon Co., Ltd. www.sinoconsys.com 7 / 17... -
Page 8: Indicators
Data from RS232 to Flashing：Data from RS232 to RS485/RS422 port RS485/RS422 Off：No data indicator Power Power indicator Steady on：Normal power supply Off：No power or abnormal power supply, please check if the voltage range is 9~27VDC SinoCon Co., Ltd. www.sinoconsys.com 8 / 17... -
Page 9: Port Description
Power supply input positive, power supply RVV 2*1.0 input negative Used for reliable grounding of the device, RVV 2*0.5 surge protection Serial R-、R+、GND、 R-、R+、GND、T-(485-)、T+(RS485+) RVSP 3*0.5/5*0.5 Interface T-、T+ RS232 RS232 DB9 Female Tips: SinoCon Co., Ltd. www.sinoconsys.com 9 / 17... -
Page 10: Product Dimensions
C2000-C2-SFI0101-BA1 User Manual 2.5. Product Dimensions unit: mm（inch） 2.6. Installation Method SinoCon Co., Ltd. www.sinoconsys.com 10 / 17... -
Page 11: Product Functions
Point-to-point / four-wire full-duplex Point-to-multipoint / four-wire full-duplex Point-to-point / two-wire half-duplex Point-to-multipoint / two-wire half-duplex 3.1. RS232 to RS422 3.1.1. RS232 to RS422 point-to-point / four-wire full-duplex 3.1.2. RS232 to RS422 point-to-multipoint / four-wire full-duplex SinoCon Co., Ltd. www.sinoconsys.com 11 / 17... -
Page 12: Rs232 To Rs422 To Rs232 Four-Wire Full-Duplex
C2000-C2-SFI0101-BA1 User Manual 3.1.3. RS232 to RS422 to RS232 four-wire full-duplex SinoCon Co., Ltd. www.sinoconsys.com 12 / 17... -
Page 13: Rs232 To Rs485
C2000-C2-SFI0101-BA1 User Manual 3.2. RS232 to RS485 3.2.1. RS232 to RS485 point-to-point / two-wire half-duplex 3.2.2. RS232 to RS485 point-to-multipoint / two-wire half-duplex SinoCon Co., Ltd. www.sinoconsys.com 13 / 17... -
Page 14: Rs232 To Rs485 To Rs232 Two-Wire Half-Duplex
C2000-C2-SFI0101-BA1 User Manual Note: Branch distance must not exceed 5 meters 3.2.3. RS232 to RS485 to RS232 two-wire half-duplex SinoCon Co., Ltd. www.sinoconsys.com 14 / 17... - Page 15 C2000-C2-SFI0101-BA1 User Manual SinoCon Co., Ltd. www.sinoconsys.com 15 / 17...
- Page 16 C2000-C2-SFI0101-BA1 User Manual 4. Package Contents Contents Device (contain mounting kit) * 1 Terminal block * 1 set Installation guide card * 1 SinoCon Co., Ltd. www.sinoconsys.com 16 / 17...
-
Page 17: Warranty Policy
8. Our company's responsibility for the manufacture, sale and use of the products shall not exceed the original cost of the products. The company does not assume any joint responsibility. 9. The right to interpret this clause belongs to the company. SinoCon Co., Ltd. www.sinoconsys.com 17 / 17...
