Summary of Contents for Electro Max AERO WAGGY
- Page 1 AERO Waggy - Airport LED Light WAGGY High Intensity Runway Guard Light INSTALLATION & MAINTENANCE INSTRUCTIONS SC ELECTRO MAX SRL tel.: +40 254 515 465 web: www.electromax.ro 36 Lunca Street, Petrosani mail: electromax@electromax.ro Hunedoara Country, Romania...
- Page 2 AERO - Waggy RECORD OF CHANGES Technical Approved Date of Issue Description of changes Author approval for issue issue www.electromax.ro Pag. 2...
- Page 3 AERO - Waggy SAFETY ADVICE 1. COMPLIANCE WITH INSTRUCTIONS IN THIS MANUAL The purchaser/user is advised to comply with the instructions and information in this manual and ensure that all personnel to be associated with the apparatus under this contract are made familiar with the information contained herein.
- Page 4 AERO - Waggy 4. VOLTAGES GREATER THAN 50V A.C./120V D.C. The purchaser/user is advised to ensure that apparatus operating on a voltage greater than 50V a.c./120V d.c. is isolated and made safe before any work is carried out upon it. 5.
-
Page 5: Table Of Contents
AERO - Waggy TABLE OF CONTENTS 1. Introduction ...........................6 1.1 Compliance with Standards ..................6 1.2 Packaging ........................7 1.3 Optional Accessories ....................7 2. Installation ..........................8 2.1 Low profile frangible bracket ................8 2.2 Standard 2” O.D. frangible coupling and base plate ..........9 2.3 Vertical Alignment ....................11 2.4 Electrical Installation ....................12 2.4.1 Connecting to a 6.6Amp AGL circuit ............12... -
Page 6: Introduction
AERO - Waggy INTRODUCTION The Waggy LED high intensity runway guard light consists of two high intensity yellow LED arrays, mounted side by side that flash alternately. Typically, runway guard lights are installed in pairs, one on either side of a taxiway and are used to clearly identify taxiway hold positions to pilots. The Waggy can be supplied in either in a 230/240V AC powered configuration Order code: AL-026- 48-AM, or a 6.6Amp AGL series circuit Order code: AL-037-48-AM. -
Page 7: Packaging
AERO - Waggy PACKAGING The Waggy LED high intensity runway guard light is supplied in a wooden crate 850mm x 440mm x 400mm. Net weight 41Kg. OPTIONAL ACCESSORIES Photocell (230/240V version only) Low Profile Frangible Bracket Standard 2” O.D. frangible coupling and base plate www.electromax.ro Pag. -
Page 8: Installation
AERO - Waggy INSTALLATION LOW PROFILE FRANGIBLE BRACKET A level concrete base should be constructed as appropriate for the size of the runway guard light. A mounting foot can then attached to the base using the appropriate bolts. 780,00 10,00 www.electromax.ro Pag. -
Page 9: Standard 2" O.d. Frangible Coupling And Base Plate
AERO - Waggy STANDARD 2” O.D. FRANGIBLE COUPLING AND BASE PLATE A level concrete base should be constructed as appropriate for the size of the runway guard light. A mounting foot can then attached to the base using the appropriate bolts. www.electromax.ro Pag. - Page 10 AERO - Waggy Base plate mounting dimensions Once the foot has been secured in place, the runway guard light can be inserted and fastened into place by tightening the bolts on the foot or coupling. Care should be taken to ensure that the runway guard light is upright and is aimed towards the centre of the taxiway as shown in figure below Guard Light to be orientated towards the taxyway center...
-
Page 11: Vertical Alignment
AERO - Waggy Vertical Alignment Installation tools required 10mm Wrench The high intensity runway guard light can be adjusted between 0-20 degrees vertically by: • remove the two locking screws located at either side of the mount • set the vertical setting to the desired position •... -
Page 12: Electrical Installation
AERO - Waggy Electrical Installation CAUTION: The Waggy LED runway guard light can be supplied in either a 230/240V AC powered configuration, OR a 6.6Amp AGL configuration. Please ensure that you connect the equipment to the correct supply. 2.4.1 Connecting to a 6.6Amp AGL circuit The 6.6A Waggy LED high intensity runway guard light is supplied with a 300mm flying lead and a factory fitted L-823 connector. -
Page 13: Maintenance
AERO - Waggy MAINTENANCE PREVENTIVE MAINTENANCE Interval Task Action Check that all the LEDS are illuminating and that the Daily Check basic operation unit is flashing approximately 45 times per minute. Check that the unit is aligned correctly and clean the Check fixture alignment Weekly disperser with warm water, mild detergent and a soft... -
Page 14: Spare Parts
AERO - Waggy SPARE PARTS SPARE PARTS ORDERING To order spare parts please call atg customer support or your local representative. For contact details please refer to our website www.electromax.ro SPARE PARTS LIST Description Qty per Fixture Imagine Lens – High intensity RGL Gasket –... - Page 15 AERO - Waggy SC ELECTRO MAX SRL Lunca 36, 332061, Petrosani, Hunedoara, Romania tel.: +40 254 515 465 web: www.electromax.ro mail: electromax@electromax.ro www.electromax.ro Pag. 15...
