Summary of Contents for Candour Communications 3130IS
-
Page 2: Safety Instructions
FEATURES FSK/DTMF auto-compatible; 60 (MAX.) groups of incoming / 67 (MAX.) groups of outgoing memories; 10 groups of 16-digit two-touch memories, 2 groups of 16-digit one-touch memories, 60 (MAX) groups of 16-digit VIP memories; Anti-paralleled ON/OFF adjustable; Ringer volume, handsfree volume adjustable; Local code, distance code, out of range code set ;... -
Page 3: Installation
• Do not place the phone near by bathtub, shower or similar environments, to avoid electrical shock. • Unplug the phone before cleaning it; do not use liquid cleaners or aerosol cleaners. • Do not use the telephone to report a gas leak in the vicinity of the leak. - Page 4 OUT LOOK 1. Music on hold 2-3. One-touch memory -EN 3-...
-
Page 5: Lcd Display
4. Flash 5. Pause 6. Speakerphone volume adjustment button 7. Redial 8. Outgoing memory and store 9. Set 10-11. Up/Down review 12. Delete 13. Auto 14. Handsfree button 15. Extension socket 16. Line cord socket 17. Ring volume Hi/Lo LCD DISPLAY: -EN 4-... - Page 6 SETTING SET button In on-hook mode press SET button to enter the setting mode, LCD will display root menu ‘–12345678—‘. Pressing menu number 1-8 to enter sub-menu, pressing DEL button to exit. Note: The sub-menu 5-8 is unavailable for such version. During sub-menu setting, press SET button to confirm present set value and return back to the root menu by turn.
- Page 7 -----‘, Input the number directly and press ‘*’ button to remove wrong input number if needed. Press 2 to enter long distance code setting. LCD displays ‘LCOdE -----‘. Input the number (Max. 5 digits) directly and press ‘*’ button to remove wrong input number if needed. (if no set, the default code is 0).
-
Page 8: Function Operations
Input the number (Max. 3 digits) directly and press ‘*’ button to remove wrong input number if needed. Press 4 to enter flash time and pause setting. LCD displays ‘SEL –12-‘. Press 1 to enter flash time setting. LCD displays ‘FLASH 600’... - Page 9 press the REDIAL button. The speakerphone is activated and the number is dialed out automatically. Redial Press the REDIAL button to redial the last dialed number. Auto-busy-redial While the dialed line is busy, press the REDIAL button and the unit redials it automatically every 10s. The unit rings to alert after it is connected.
- Page 10 Press OUT/STORE enter outgoing call review, then press OUT/STORE or UP button continuously to select the number to redial. Press the REDIAL button to call back the number. The speakerphone is activated. During reviewing, press DEL button twice, LCD displays ‘dEL OnE---‘, it means this displayed call record is deleted.
- Page 11 or to dial out the number with out of range code at the beginning (if the code is set). Press REDIAL twice to dial out the reviewed call with out of range code (if set and the incoming number is 7-digits above) and long distance code at the beginning (if no long distance code set, default distance code is “0”).
-
Page 12: Troubleshooting
memories In on-hook mode press AUTO button, LCD displays ‘ACCESS_‘, input the location number (0~9), the stored number displays on the LCD, press REDIAL button, the number is dialed out. If LCD displays nO COdE, it means there is no number stored at this number key yet. In off-hook mode press AUTO button and with digit number (0-9), the number stored there will be dialed out. - Page 13 • Check the power of the batteries and check if they are well placed in the compartment • Check if your local telephone operator provides the Caller ID function • When the phone is placed behind a PABX, check if the PABX supports the Caller ID function No function •...
