Mercedes-Benz GLE Series Brief Overview

GLE
Brief overview
Mercedes-Benz
Cockpit overview
$ WARNING Make sure that you read the entire Operator's Manual. Otherwise, you may not recognize dangers.
Cockpit overview
c MBUX multimedia system touchpad
Back button
Press: audio control menu
Swipe: next/previous track or radio
station
ò Displays the Home screen
d Buttons on the right of the touchpad
Sets the volume by turning
VOLUME
Press briefly: mute function
Press and hold: switches off the MBUX
multimedia system
Calls up Navigation
Calls up Radio or Media
% Calls up Telephone
e Offroad control panel
+ LOW RANGE off-road gear
x Manual gearshifting
Level control system
®
å ESP OFF
à DSR (Downhill Speed Regulation)
Controls on the steering wheel and Active Distance Assist DISTRONIC
P54.26-1408-00
1 Wipes the windshield once
Wipes with washer fluid
2 Sets the windshield wipers
Off, normal/frequent automatic wiping, slow/
fast continuous wiping
3 Rear window wiper
4 Turn signal, left/right
5 Headlamp flasher
6 Adaptive Highbeam Assist Plus
7 Switches the steering wheel heating on/off
8 Adjusts the steering wheel
$ WARNING Make sure that you read the entire Operator's Manual. Otherwise, you may not recognize dangers.
Climate control
P68.20-5192-00
Operating possibilities
You can adjust climate control using the buttons on
climate control panel 1.
If you change any settings, media display 2 briefly
shows the current settings of the climate control
system.
Buttons on the multifunction steering wheel
Operating the multifunction display and
Head-up Display
1 Back/Home button
i
Press and hold: shows the standard display
(speedometer, trip meter and rev counter)
2 Touch Control for multifunction display and
Head-up Display
Press: confirms your selection
Order no. P167 0141 13 Part no. 167 584 17 07 Edition C-2020
1 6 7 5 8 4 1 7 0 7
P68.00-8732-00-Farbe
f Buttons on the left of the touchpad
w DYNAMIC SELECT switch
c Active Parking Assist
Calls up vehicle functions (e.g.
assistance systems)
ß Favorites button
i
Press and hold: adds a favorite
g Start/stop button for starting the engine
Button for the ECO start/stop function
i
The ECO start/stop function cannot
be permanently deactivated.
h Instrument lighting
!
j Electric parking brake
k q Opens or closes the tailgate
l Door control panel with controls for power
windows, exterior mirror settings and the
override feature for the rear side windows
i
If the front passenger mirror is selected
and you engage reverse gear, the front
passenger mirror moves into the stored
parking position.
Note that your vehicle may not be equipped with all of the features described.
P54.26-1409-00
Active Distance Assist DISTRONIC
1 Active Distance Assist DISTRONIC
3 Active Distance Assist
Activates DISTRONIC with current speed
4 Activates with the stored speed/pulls
away with Active Distance Assist
DISTRONIC
Deactivates Active Distance Assist
DISTRONIC
Air conditioning control panel
w Sets the temperature
t
Calls up the air conditioning menu
Operation of further climate control
functions such as the temperature setting
for the 2nd row of seats, fragrancing,
ionization
i
If you press and hold the
for approximately 4 seconds, the air
conditioning will be reset to the basic
settings.
H Sets the air flow, switches climate control
off completely
à Sets climate control to automatic mode
¬ Defrosts the windshield
¤ Defrosts the rear window
Á Cooling with air dehumidification
Residual heat with the engine off
0 Synchronized operation of all zones
d Air-recirculation mode
The air in the interior is recirculated; the
windows may fog up more quickly.
Note that your vehicle may not be equipped with all of the features described.
P46.10-3634-00
Operating the MBUX multimedia system
ò
3 Home screen
4 Touch Control for the MBUX multimedia
system
Navigate in the menus with one-finger swiping
movements
Press: confirms your selection
5 Back button
Ends a dialog with the Voice Control
System
1 Door handle
& Locks the vehicle centrally
%
Unlocks the vehicle centrally
2 Seat functions
Adjusts the seats electrically
r Memory function and presets
45=
3 c Switches the seat heater on/off
s
Switches the seat ventilation on/off
w Adjusts the front passenger seat from
the driver's seat
4 a Light switch
Q
Rear fog lamp
5 Head-up Display
6 Multifunction steering wheel control panels
7 Multifunction display
8 DIRECT SELECT selector lever
9 MBUX multimedia system media display
a Climate control system control panel
b £ Hazard warning lights
P82.00-3435-00
Overhead control panel
1 Buttons for interior lighting and reading lights
;
2 Button for Mercedes me connect*
3 G SOS button*
(Mercedes-Benz emergency call system)
4 3 Opens/closes the sliding sunroof
Roller sunblind
* Not available in all countries
Changing the speed/distance
2 Reduces the specified minimum
distance
Increases the specified minimum
distance
3 Increases the speed
Decreases the speed
Active Distance Assist DISTRONIC maintains a
constant speed which has been stored.
The lowest speed that can be set is 12 mph
(20 km/h).
You can change the set speed:
1 mph increment (1 km/h): Briefly press rocker
X
switch 3 up or down.
5 mph increment (10 km/h): Press rocker
X
switch 3 up or down past the point of resistance.
Using rocker switch 2, you can change the
specified minimum distance to the vehicle in front.
The specified minimum distance depends on the
currently driven speed.
General notes
Optimum operation of the climate control system is
only achieved when the side windows and the roof
are closed.
To prevent the windows from fogging up, please
observe the following information:
Á Switch on the cooling function.
In warm weather, the air inside the vehicle
t
button
will be cooled. This function also dries the air
inside the vehicle.
H As far as possible, do not switch off climate
control
d Switch on air-recirculation mode only briefly
¬
If necessary, briefly switch on the windshield
defroster function
6 6 Accepts and makes a telephone call
~ Rejects a telephone call
Ends a call
Ends a dialog with the Voice Control
System
H
7 Sets the volume by turning
Press: switches sound on or off
?
8 Starts a dialog with the Voice Control
System
i
Press and hold: activates the voice control
system of the mobile end device currently
connected
ß
Displays favorites
