HAC-UM Series RF Module Manual
SHENZHEN HAC TELECOM TECHNOLOGY CO., LTD
Fl.6, Building 2, Jiuxiangling New Industry Park, No.4227, Xilihu
Address
:
Road, Nanshan, Shenzhen, China.
Tel
:
+86-755-23981078 23981077
Fax
:
+86-755-23981007
E-mail
:
webmaster@ rf-module-china.com
Website
:
http://www.rf-module-china.com
Version 2.3C

Advertisement

loading
Need help?

Need help?

Do you have a question about the UM Series and is the answer not in the manual?

Questions and answers

Related Manuals for HAC UM Series

Summary of Contents for HAC UM Series

  • Page 1 HAC-UM Series RF Module Manual Version 2.3C SHENZHEN HAC TELECOM TECHNOLOGY CO., LTD Fl.6, Building 2, Jiuxiangling New Industry Park, No.4227, Xilihu Address Road, Nanshan, Shenzhen, China. +86-755-23981078 23981077 +86-755-23981007 E-mail webmaster@ rf-module-china.com Website http://www.rf-module-china.com...

  • Page 2: Table Of Contents

    SHENZHEN HAC TECHNOLOGY CO., LTD. Catalogue Features of HAC-UM Series ................. 3 II. Applications of HAC-UM Series................4 III. How to use HAC-UM Series.................. 4 IV. Networking Application of HAC-UM Series............13 V. Technical specification of HAC-UM Series............14 VI. Description of type ....................14...

  • Page 3: Features Of Hac-Um Series

    Any false data generated in air can be filtrated automatically (What has been received is exactly what has been transmitted). Multi-channels HAC-UM transceivers offer 8 channels, if needed, 16 or 32 channels available to satisfy various configuration of communication under user’s demand at the same time 2 ports with three connection methods...

  • Page 4: Applications Of Hac-Um Series

    ﹡Traffic, Personnel positioning and alarm in the well III. How to use HAC-UM Series HAC-UM is a member of HAC series low power data radio modules, which provides RS-232, RS-485 and UART/TTL level interface port for direct connection with PC, RS485 devices, SCM and other UART components kind of applications.
  • Page 5 SHENZHEN HAC TECHNOLOGY CO., LTD. Power supply HAC-UM work with supply voltage +3.3~5.0 DC. By using better ripple factor, HAC-UM transceivers can also share power supply with other equipment. If possible, a voltage-stabilizing chip with 5V voltage is more recommended as the only power supply than Switch power supply.
  • Page 6 3. The connection schematic diagram of HAC-UM transceivers with terminal. 4. Setting of channel, interface and data format: Before using HAC-UM, the user needs to make simple configuration based on its own needs to determine the channel, interface mode and data format.
  • Page 7 0 =Plugging in circuiter b. Selection of interface mode: HAC-UM provides 2 serial ports. COM1 (Pin3 and Pin4 of JP1) is fixed as UART serial port of TTL level; COM2 (Pin6 and Pin7 of JP1) can choose non-standard RS232/485 interface mode...
  • Page 8 5µA. The default set of sleep function is usually closed to ensure the reliability of preventing transceivers from getting in wrong sleep mode. The sleep function can be opened by HAC after informed or by user via programming them software.
  • Page 9 The delay time of transceivers between the first bit sent by TxD to the first bit received by RxD. Due to a data processing will be made on user’s data by HAC-UM transceiver using FEC (Forward Error Correction) or other correction algorithm, when RxD of a HAC-UM transceiver ‘A’...
  • Page 10 SHENZHEN HAC TECHNOLOGY CO., LTD. d. Large-number data transmission In theory, when the interface data rate is faster than the RF data rate, HAC-UM transceivers can send unlimited-long data package, but any long packages more than 120B are not recommended.
  • Page 11 HAC-UM Series RF Module Manual SHENZHEN HAC TECHNOLOGY CO., LTD. 9. Antenna configuration: Many appropriative antennas for ultra low power RF modules are selected for meeting different user antenna configurations. Please ask our Sales office for further information about the antenna’s dimension and performance.
  • Page 12 HAC-UM Series RF Module Manual SHENZHEN HAC TECHNOLOGY CO., LTD. a. Exterior flagelliform rubber antenna with helical SMA joint i. LX433-10-SMA: 100mm helical SMA antennas with high gain and low cost, reach a long distance. ii. LX433-10-ZSMA: 100mm SMA helical antenna with folding joint, easy for adjusting the direction and fixing.

  • Page 13: Networking Application Of Hac-Um Series

    If the user has special demands on antennas, we can design and produce for them specially. IV. Networking Application of HAC-UM Series The communication channel of HAC-UM is half duplex, which is most suitable for the communication mode of point to multi-point. Under this mode, one master station must be set, and all of the rest are slave stations.

  • Page 14: Technical Specification Of Hac-Um Series

    Dimension:47×26×10mm VI. Description of type For product type HAC UM96, “HAC-”indicates the name of manufacturer ShenZhen HAC Technology Co., Ltd., “U” means ultra low power, i.e. transmission power is 10dBm, “M” indicates carrier frequency 402~470MHz, the factory default is 433.926MHz, and 96 indicates that interface baud rate is 9600bps.
