2
Installing the DSL Modem
2.1 Mounting the DSL Modem
The DSL Modem can be installed on desktops, shelves or mounted on
walls. The wall mounting requires two wall anchors (not included).
The feet located on the bottom of the modem are used to hang the
unit on the wall anchors.
Figure 2-1 shows a diagram of how to mount the DSL Modem.
4
Figure 2-1: DSL Modem Mounting Holes
Feet for
wall mounting
