- Page 1 ASSEMBLY INSTRUCTION SKU#:PF18264/PF18264-R Imported by Festival Trading Inc. www.festival-depot.com Made in China...
-
Page 2: Safety Information
2 /12 Safety Information WARING: One people are required for this assembly. Some parts may contain sharp edges. Wear Keep all children and pets away from assembly area. protective gloves. Children and pets should be supervised when they are When assembling and using this product, in the area of the Chair construction. -
Page 3: Exploded Drawing
3 /12 EXPLODED DRAWING... - Page 4 4 /12 Product Include Label Part Number Description Part Image PF18264/ High Swivel Chair PF18264-R Parts List（For 1 Chair） Label Part Number Description Part Image P30105A01108 Back P30009A01108 Handrail(Left) P30010A01108 Handrail(Right) P30206A01108 Seat P30702A01108 Turntable P31411A01108 P31902A01108 Pedal Pipe P00501G02109...
- Page 5 5 /12 Hardware Pack （For 1 Chair） Part Image Label Part Number Description H04015C11 Bolt M6* 15 Actual Size H04018C11 Bolt M6* 18 Actual Size H04028C11 Bolt M6* 28 Actual Size H12001C11 Washer M6 Flat Actual Size H22001C11 Nut M6 Actual Size H04030C11 Bolt M6*30...
- Page 6 6 /12 STEP 1:Assembly of Leg And Pedal Pipe Assembly Tips: Please use the hardware and accessories included in the set. DO NOT use other electrical or manual tools. In order to facilitate the assembly and make your final product firm and stable, please tighten by a few rounds each screw one by one.
- Page 7 7 /12 STEP 2:Assembly of Turntable P31902A01108...
- Page 8 8 /12 STEP 3:Assembly of Back And Seat P30206A01108 H04018C11...
- Page 9 9 /12 STEP 4:Assembly of Seat And Turntable P30105A01108 Please tighten the CC just a few rounds. Do not tighten the CC to the end.
- Page 10 10 /12 STEP 5:Assembly of Handrail(Left) P30009A01108 P30010A01108 Please connect ABCD well, then you start to tighten each screw to the end.
- Page 11 11 /12 STEP 6:Assembly of Handrail(Right) H04015C11...
-
Page 12: Care And Maintenance
12 /12 STEP 7:Assembly of Cushion And Back Cushion P00401G02104 P00501G02109 Care and Maintenance Before using, clean the Chair completely with a dry towel. When not in use, wipe free of any dirt or loose objects, wash with a mild s of soap and water;...
