Summary of Contents for evoheat PASRW360S-PS-BP
-
Page 2: Table Of Contents
EvoHeat Evo Command Manual Contents ____________________________________________________________________________________ 2 1. Introduction ________________________________________________________________________________ 3 2. Safety Precautions ________________________________________________________________________________ 4 3. Unit Specifications 3.1 Running Range ________________________________________________________________________________________ 4 3.2 Specification Data _____________________________________________________________________________________ 5 3.3 Dimensions __________________________________________________________________________________________ 6 _____________________________________________________________________________________ 6 4. Installation 4.1 Transit ______________________________________________________________________________________________ 6 4.2 Selecting an Installation Location _________________________________________________________________________ 6... -
Page 3: Introduction
BLUETEC COATED CONDENSER industrial facility. They have a compact design with easy EvoHeat’s Bluetec hydrophilic coating on the condenser maintenance access. fins is the latest technology in corrosion protection allowing your new heat pump to maintain it’s high 304 STAINLESS STEEL CABINET efficiency for many years to come. -
Page 4: Safety Precautions
EvoHeat Evo Command Manual 2. Safety Precautions Read the safety instructions carefully before operation. Incorrect handling could cause a serious hazard such as death, serious injury etc. with a high probability. • When an abnormality (smell of burning, etc.) occurs, stop the unit and disconnect the power or turn off the breaker. -
Page 5: Unit Specifications
EvoHeat Evo Command Manual 3. Unit Specifications The Evo Command series is reverse cycle, providing both heating or cooling. Air operation range -15°C to 43°C Water operation range 7°C to 50°C Used for Commercial: water & air heating/cooling Suitable for Hotels and resorts, commercial buildings, sporting & leisure facilities, industrial liquid heating and chilling... -
Page 6: Specification Data
EvoHeat Evo Command Manual 3.2 Specification Data Evo Command 70 Evo Command 140 Cooling Capacity* Heating Capacity** Power Consumption* 17.8 38.5 Power Consumption** 21.2 43.6 Current (Cooling/Heating) 32.5/38.0 70.3/78.4 Power Supply 380~400V/3N~/50Hz Compressor Quantity Compressor Type Scroll Fan Quantity Fan Motor Input... -
Page 7: Dimensions
EvoHeat Evo Command Manual 3.3 Dimensions Unit: mm Evo Command 70 2170 1065 1730 1020 2250 DN65 Evo Command 140 2500 1210 1860 1168 2320 DN80 4. Installation 4.1 Transit When the heat pump is transported the unit must be standing upright. If the unit is laid down, inner parts of the device may be damaged. -
Page 8: Installation Method
EvoHeat Evo Command Manual 4.3 Installation Method The heat pump can be installed onto the concrete basement by using expansion screws, or onto a steel frame with rubber feet which can be placed on the ground or the roof. Ensure that the unit is placed horizontally. -
Page 9: Water Connection Diagrams
When installed in a small room, measures should be taken to prevent leakage of the refrigerant. Once leakage • volume exceeds the limit concentration, it may cause suffocation. Contact EvoHeat for specific measures. 4.6 Water Connection Diagrams 4.6.1 Hot Water Circuit Diagram... -
Page 10: Heating (Cooling) Water Circuit Diagram
EvoHeat Evo Command Manual 4.6.2 Heating (cooling) Water Circuit Diagram • Be sure to install the Y filter at the water inlet of the unit. Pay attention to the installation position for easy removal and cleaning. • Ensure that the circulating water inlet of the unit is at least 100mm away from the bottom of the water tank, and that the customer’s hot water supply pipe is at least 80mm away from the circulating water inlet. -
Page 11: Trial Operation
EvoHeat Evo Command Manual 4.9 Trial Operation Beforehand Inspection Check the indoor unit, make sure that the pipe connection is done correctly, and the relevant valves are open. Check the water loop to ensure that the water inside of the expansion tank is filled to an appropriate level, and the water supply is working, and the water loop is full of water and free of trapped air. -
Page 12: Control & Operation
EvoHeat Evo Command Manual 5. Control & Operation 5.1 Main Interface Displays & Functions Electricity Connected Interface Main interface of power-off Power-on interface Button Function Power Switch the unit on or off. Setpoint Set the target temperature. Mode Selecting heating or cooling mode. -
Page 13: Power On/Off
EvoHeat Evo Command Manual 5.2 Power On/Off In the main interface, press the ‘Power’ button to power the unit on or off. 5.3 Mode Selection In the main interface, pressing the ‘Mode’ button will allow you to select heating or cooling mode. The status bar (8) will display the unit’s current operating state. -
Page 14: Settings Menu
EvoHeat Evo Command Manual 5.7 Settings Menu After pressing the ‘Setting’ button on the main menu, you can select from a range of functions. 5.7.1 Status Press Status (30) to choose from Running Status or Unit Status. Running Status See below image. -
Page 15: Failure
EvoHeat Evo Command Manual 5.7.3 Failure When a failure is occurring, the red failure alarm icon will be flashing from the main menu. From settings, press the Failure button to view the failure records. Once maintenance has been completed, press the ‘Clear’ button to delete the failure record history. -
Page 16: Display Calibration
EvoHeat Evo Command Manual 5.8 Display Calibration Enter the Unit status menu in the following order (see 5.7.1 Status for password): Main Interface Setting Status Unit Status Click the screen in the bottom left corner over 10 times within 4 seconds to bring up the display calibration interface. - Page 17 EvoHeat Evo Command Manual Syst1: Exhaust Air High Temp P182 The system compressor is overloaded Inspect whether the operation of System 1 Prot. compressor is normal Syst2: Exhaust Air High Temp P282 The system compressor is overloaded Inspect whether the operation of System 2 Prot.
- Page 18 EvoHeat Evo Command Manual Syst1: User Side Antifreezing 1 P191 The temperature sensor is open or Check and replace the system 1 use side Sensor Fault short circuited antifreeze 1 temperature sensor Syst2:Coil Temp Sensor1 Fault P250 The temperature sensor is open or...
- Page 19 EvoHeat Evo Command Manual Press 1 Bus Over Voltage Prot. F157 Voltage is too high Check if the input voltage is higher than 480V Press 1 Bus Under Voltage F158 Voltage is too low Check if the input voltage is lower than 250V Prot.
-
Page 20: Controller Interface Diagrams
EvoHeat Evo Command Manual 7. Controller Interface Diagrams 7.1 Wire Control Interface Diagram & Definition 7.2 Controller Interface Diagrams & Definitions... - Page 21 EvoHeat Evo Command Manual...
- Page 22 EvoHeat Evo Command Manual Note: (1) JP13_1 represents + 12V, 485_A1, 485_B1, GND on the JP13 terminal; (2) JP13_2 represents + 12V, 485_A2, 485_B2, GND on the JP13 terminal; (3) JP13_3 represents + 12V, 485_A3, 485_B3, GND on the JP13 terminal.
-
Page 23: Input & Output Interface Instructions
EvoHeat Evo Command Manual 7.3 Input & Output Interface Instructions Sign Meaning Sign Meaning AI/DI1 Water inlet temperature AI 55(50K) No use AI/DI2 Water outlet temperature 0-5V_IN1 System 1 Compressor current AI/DI3 No use AI/0-5V_IN2 System 2 Compressor current AI/DI4... -
Page 24: Appendix
EvoHeat Evo Command Manual 8. Appendix 8.1 Caution & Warnings The unit can only be repaired by qualified personnel or an authorised dealer. Children should be supervised to ensure that they do not play with the appliance. Please make sure that the unit and power connection have good earthing, otherwise there is a risk of electrical shock. -
Page 25: Cable Specifications
EvoHeat Evo Command Manual 8.2 Cable Specifications Single Phase Unit Phase Line Earth Line Creepage Protector Signal Line Nameplate Maximum Current < 10A 2 x 1.5mm 1.5mm 10~16A 2 x 2.5mm 2.5mm 16~25A 2 x 4mm 25~32A 2 x 6mm...
