Bottom Line Tournament 2100 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Introduction __________________________________________1
Installation ___________________________________________2
1. Mount the Display _____________________________________ 2
2. Mount the Transducer _________________________________ 2
Outside Hull Mount __________________________________________3
Inside Hull Mount ____________________________________________5
3. Route the Transducer Cable ____________________________ 5
4. Route & Connect the Power Cable _______________________ 5
Functions and Features ________________________________6
Power on and off, demo mode __________________________________6
Set and adjust features ________________________________________6
Fishing with the 2100 __________________________________9
How Your 2100 Works________________________________________9
Reading the Graph ___________________________________________9
Maintenance ________________________________________10
Specifications ________________________________________11
If You Are Having Problems____________________________11
Accessories and Replacement Parts ______________________13
Figure 1: Outside Hull Mount ______________________________________4
Figure 2. Tournament 2100 Display _________________________________8
Figure 3. SONAR beam (cross-section) ______________________________9
I
NTRODUCTION
Congratulations on your purchase of the Bottom Line
Your new SONAR includes Bottom Line's advanced high-clarity bottom
graph plus water temperature and boat speed (with optional sensor) to make
the most out of your boating and fishing experience.
Make sure that your package contains the following items:
Tournament 2100 display unit with mounting bracket
Transducer with mounting screws
Power cord
Warranty card (back page of this manual)
Tournament 2100
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tournament 2100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bottom Line Tournament 2100

  • Page 1: Table Of Contents

    Congratulations on your purchase of the Bottom Line Tournament 2100 Your new SONAR includes Bottom Line’s advanced high-clarity bottom graph plus water temperature and boat speed (with optional sensor) to make the most out of your boating and fishing experience.

  • Page 2: Installation

    Proper installation is essential in getting the best performance from your 2100. Please read these directions carefully. If you do not feel comfortable performing  the installation yourself, contact your authorized Bottom Line dealer for a professional installation. Here is what you will need to do in this order: 1.

  • Page 3: Outside Hull Mount

    2) Inside Hull Mount. This option is recommended for the best high- speed performance (above 40MPH or 65KHP), but reduces sonar sensitivity and temperature sensor responsiveness (see page 5). 3) Electric Trolling Motor Mount. This requires hardware #019107 EZ Mount Trolling Motor Bracket (not provided). 4) Transom Mount.

  • Page 4: Figures And Illustrations Figure 1: Outside Hull Mount

    STEP 3 – Mark and drill the holes Place the transducer at the chosen position and mark both hole locations with the pencil. Drill the holes, making sure not to drill deeper than the length of the screws provided. STEP 4 – Very important! Apply the silicone Fill the holes drilled in step 3 with silicone caulk.

  • Page 5: Inside Hull Mount

    Inside Hull Mount An in-hull mount only works on fiberglass boats. The transducer is bonded to the hull with a quality two-part epoxy (not included). Caution: If you do are not confident that you can do this yourself, consider contacting your boat dealer for a professional installation. STEP 1 –...

  • Page 6: Functions And Features

    Note: Connecting to the same circuit as other devices such as tachometers, radios or trim switches may cause electrical interference. Caution: To protect both the cable and the display unit, Bottom Line highly recommends that you install an in-line 1-amp fast-blow fuse (available at automotive stores) in series with the red wire at the battery.
  • Page 7 Contrast is the darkness or lightness of the display. Both your CONTRAST – viewing angle and the ambient temperature affect the contrast. The 2100 has a display backlight for use when there is not enough LIGHT – daylight to view the screen. The backlight also generates heat and can be used to help warm the display in cold weather.
  • Page 8 (there are no settings for it). Bottom graph range Boat speed (with optional sensor) Water (in auto-range mode) temperature Fish symbol depth Fish Symbol (fish alarm on) Weeds and Hard soft bottom bottom Bottom depth Figure 2. Tournament 2100 Display...

  • Page 9: Fishing With The 2100

    2100 ISHING WITH THE How Your 2100 Works The 2100 uses active SONAR, short for Sound Navigation and Ranging, to locate and identify objects in the water. The transducer sends out short bursts of ultrasonic sound waves into the water and then listens for echoes to come back from objects and the bottom.

  • Page 10: Maintenance

    Greyscale The 2100 display uses a grey checkered pattern to display the strongest signals, which are usually from a hard bottom (see Figure 2). Weaker signals above the bottom are displayed as black. This allows you to separate the bottom from weeds and to differentiate a hard bottom from a soft, muddy one.

  • Page 11: Specifications

    PECIFICATIONS Unit dimensions 5.0"W x 5.3"H x 2.5"D Power requirement 10.5-14V ¼ amp continuous, 1-amp peak Display viewing area 3.1" x 2.3" Display pixel matrix 160Vx104H Depth range Up to 240 feet Transducer frequency 455KHz Transducer cone angle 9° Computrol, Inc. reserves the right to change specification without notice. Notice: The bottom depth range specified above is under best conditions.
  • Page 12 Problem: Unit does not pass self-test. • Make sure that the power source has between 10.5-14V 1-amp and that the connector is fully inserted into the back of the unit. • If the test fails repeatedly, call our customer service number listed in the warranty.

  • Page 13: Accessories And Replacement Parts

    Bottom Line warrants that if the accompanying product (see exclusions below) proves to be defective in material or workmanship within one (1) year from the date of original retail purchase, Bottom Line will, at Bottom Line's option, either repair or replace same without charge (but no cash refunds will be made).
  • Page 14 Non-Warranty Repairs Bottom Line products for which the warranty does not apply, due to any of the above exclusions or warranty period expiration, will be repaired for a charge. All such repairs carry a 90 Day Limited Warranty, subject to the exclusions and limitations stated above.
