Summary of Contents for Toolots AD-005
- Page 1 Operating Manual Freezing Compressed Air Dryer Http://www.dryer.com.tw/ E-mail:dryer@dryer.com.tw...
- Page 2 1. Features 1. Introduction 2. Features of Product 2. Names of Exterior Parts And Functions 1. Names of Exterior Parts 2. Operating Panel 3. Points of Installation for Attention 1. Space for Installation 2. Places Avoided for Installation 4. Method of Installation (Piping) 1.
-
Page 3: Features Of Product
Features Introduction This manual mainly provides the instructions of operating this equipment and general maintenance tasks for the users. The purpose of this manual is to extend the operation life of this equipment and prevent failures so as to ensure the drying quality of the compressed air dryer. This manual provides information related to drying equipment for reference. -
Page 4: Names Of Exterior Parts
Names of Exterior Par ts And Functions Names of Exterior Parts Air Outlet: Air Inlet: Compressed air Wet compressed air after drying flows enters from here. out from here. Control Panel: Automatic Wat This panel is Drainer (rear): used for control, Precipitated moisture operation and of the dryer is removed... - Page 5 Points of Installation for Attention Space for Installation Space for cleaning and Space for cleaning and maintaining water drainer maintaining radiator 50 cm above. 50 cm above. Space for operation and Space for maintaining electric inspection and replacing parts 80 cm above. 80 cm above.
-
Page 6: Piping Method
Method of Installation (Piping) Diameters of Inlet And Outlet Pipes of Dryer MODE AD-005 AD-010 AD-015 AD-020 AD-030 AD-040 AD-050 AD-060 INCH 1/2" 3/4" 1" 1-1/2" 2" MODE AD-075S AD-100S AD-150S AD-200S AD-250S AD-300S AD-400S INCH 2" 2-1/2" 3" 3"... - Page 7 Method of Installation (Power Distribution) Electric Features of Dryer AD-005 AD-010 AD-005 AD-010 AD-015 AD-020 AD-030 AD-040 AD-050 AD-060 Model Running 4.5 A 2.3 A 3.6 A 11.0 A 5.5A 2.8 A 3.2 A 5.5 A 7.0 A 8.5 A...
-
Page 8: Method Of Operation
Method of Operation Inspection Items Before Operation 1. Inspect the voltage of power supply. 2. Inspect the environment temperature (not over 40 ). 3. Check if the condenser and the fin of the pre-cooler are clean. Operation 1. When the power switch is on 2. - Page 9 Temperature Range of Dew Point blue area According to ISO 8573.1, dew point temperature of a freezing dryer is based on 2 - 10 , as the blue area between two dotted lines shown in the figure on the right. dew point temperature Special Situation at a lower position...
-
Page 10: Daily Maintenance
Daily Maintenance Daily Maintenance 1. Check the automatic water drainer (Fig. 1) every day for any blocking or 1. Check the automatic water drainer (Fig. 1) every day for any blocking or leakage. When obstruction is spotted, remove the water drainer right leakage. -
Page 11: Protection Device
Protection Device And Troubleshooting Protection Device 1. Protection Device for control substrate Fuse (250V/3A) When over-high voltage is input or the part on the substrate breaks down, this fuse will be melted to prevent elements at rear like the compressor from being damaged. 2. -
Page 12: After-Sale Service
1. Can't start Failure Possible Reason Resolution Overload trip indicator on Rated air flow exceeds. Increase dryer equipment. Compressor malfunctions. Replace a new compressor. Refrigerant system is blocked. Replace the dryer and capillary. Vacuum and re-fill refrigerant. Supply power of 5% of rated voltage in accordance with Abnormal power supply the nameplate. -
Page 13: Appendix 1: Drawing Of Purification Equipment Application
Appendix 1: Drawing of Purification Equipment Application Foods, medicine processing, precision coating 0.01 0.003 Fast drilling, general coating, planned packaging 0.01 Cleaning, shipping, tooling, cutting processing By pass Freezing dryer Air compressor Air tank -12-... - Page 14 Drawing of Electric Wires -13-...
- Page 15 -14-...
- Page 16 -15-...
- Page 17 Footnote -16-...
- Page 18 Footnote -17-...
- Page 19 Footnote -18-...
