INTRODUCTION Thank you for purchasing this Elliott product. More than 100 years of experience have been employed in the design and manufacture of this control, representing the highest standard of quality, value and durability. Elliott tools have proven themselves in thousands of hours of trouble-free field operation.
• Know Your Elliott Tool. Read this manual carefully to learn your tool’s application and limitations as well as the potential hazards specific to this tool.
Page 6
SAFETY GUIDELINES • These tools are designed to operate on 90 psi (6.2 bar) maximum air pressure. If the tool is properly sized and applied, higher air pressure is unnecessary. Excessive air pressure increases the loads and stresses on the tool parts, sockets, and fasteners and may result in breakage.
Page 7
SAFETY GUIDELINES WARNING REPETITIVE MOTION: Repetitive work motions and/or vibration can injure hands and arms. Tasks should be performed in such a manner that the wrists are maintained in a neutral position, which is not flexed, hyperextended or turned side to side. Stressful postures should be avoided and can be controlled through tool selection and work location.
OPERATION INSTRUCTIONS WARNING HIGH TORQUE TOOL: Torque reaction bar is highly recommended. NOTE: The reaction bracket, PN: 445-6001, must fully engage the spline on the right angle head. Position the bracket forward on the small diameter of the head and then move it rearward to engage the spline.
Page 9
OPERATION INSTRUCTIONS CAUTION If the motor has stalled, do not attempt to apply additional torque by rotating the motor as if it were an air ratchet. This will break the rotor paddles and may damage the motor cylinder. Operational Check Grip tool securely and be prepared to counteract stall torque in case clutch is improperly adjusted.
PARTS LISTS & DIAGRAMS Optional Torque Reaction Bar Item Part Number Description 163CI Hex Head Cap Screw 445-6002 Reaction Bar Clamp 130CT Hex Head Cap Screw 170C Hex Jam Nut 445-6001 Reaction Bar Bracket 445-1700 Torque Reaction Bar 133C Lock Washer Stall Torque Right Angle Rolling Motor...
Page 12
PARTS LISTS & DIAGRAMS 90 RPM Head Assembly Item Part Number Description 445H0090 90 RPM Head 445-5011 Bearing Retainer PC80-6004ZZ Bearing 445-5003-90 90 RPM Gear PC80BH-1812 Needle Bearing 445-5001-90 Right Angle Head 445-5007-90 Drive Shaft PC80M-12121 Needle Bearing 41-4534K39 Plug PC80R16ZZ Bearing 445-5005-90...
Page 13
PARTS LISTS & DIAGRAMS 190 RPM Head Assembly Item Part Number Description 445H0190 190 RPM Head 445-5011 Bearing Retainer PC80-6004ZZ Bearing 445-5003-190 190 RPM Gear Set PC80BH-1812 Needle Bearing 445-5001-190 Right Angle Head 445-5007-190 Drive Shaft PC80M-10121 Needle Bearing 41-4534K39 Plug PC80-6905RS Bearing...
Page 14
PARTS LISTS & DIAGRAMS Lever Throttle Assembly ITEM PART 445-8 445-2 539R 445-1 P8309 445-1 P8309 445-1 P8384 445-1 445-1 P8309 445-1 445-1 37-TA 445-1 P8286 P8309 445-1 445-1 445-1 445-1 445-1 P8309 445-1 Item Part Number Description Item Part Number Description TOLERANCES MAT'L SPEC MAT'L R...
Page 15
PARTS LISTS & DIAGRAMS 90 RPM Gearbox Assembly Item Part Number Description 445-4000-90 90 RPM Gearbox Assembly 445-4001 Gear Case 445-4005 Second Stage Spider 445-4008 Second Stage Planet Gear P8573-27 Needle Roller 445-4013 Gear Pin 445-4004 First Stage Spider 445-4007 First Stage Planet Gear Stall Torque Right Angle Rolling Motor...
Page 16
PARTS LISTS & DIAGRAMS 190 RPM Gearbox Assembly Item Part Number Description 445-4000-190 190 RPM Gearbox Assembly 445-4001 Gear Case 445-4012 Second Stage Spider 445-4011 Second Stage Planet Gear P8573-27 Needle Roller 445-4013 Gear Pin 445-4010 First Stage Spider 445-4007 First Stage Planet Gear Stall Torque Right Angle Rolling Motor...
Page 17
PARTS LISTS & DIAGRAMS Air Motor ITEM PART PC80-6 445-20 445-20 445-20 445-20 P8382 445-20 P8263 128P 445-20 Item Part Number Description TOLERANCES MAT'L SPEC MAT'L REQUIRED MARKING METHOD PC80-6000ZZ Radial Ball Bearing UNLESS OTHERWISE SPECIFIED 445-2007 Front Bearing Plate .XX = ±.02 .XXX = ±.005 HARDNESS...
MAINTENANCE INSTRUCTIONS The proper performance and service life of every machine depends on how well it is maintained. The following should become a regular routine of operations. 1. It is recommended that the right angle gears receive a generous amount of No. 2 moly grease through the grease plug (located on top of right angle head) after 40 hours of operation.
WARRANTY Should any part, of Seller’s own manufacture, prove to have been defective in material or workmanship when shipped (as determined by Seller), Seller warrants that it will, at its sole option, repair or replace said part f.o.b., point of manufacture, provided that Buyer notifies, in writing, of such defect within twelve (12) months from date of shipment from the manufacturing plant.
