Summary of Contents for Durabuilt EasySHED
- Page 1 Durabuilt Gable Roof Quality Garden Shed EasySHED 5 Step Assembly Economical solutions designed for style, durability and function. Model 3.00m x 3.00m x 2.10m Gable Roof Shed...
- Page 2 COMPONENT CHECK LIST - EasySHED 6x Plain Sheets (Step 1 4B 5) 8x Gable Sheets (Step 2) 1x U Channel with Hinges • 780 x 1800mm ∆ ◊ 780mm wide 1740mm ◊ (Step 4A) 8x Roof Sheets (Step 3) 780 x 1600mm #...
- Page 3 Optional Extras. If your shed includes options, refer to the separate assembly instructions for the installation sequence. The only tool required for assembling your Durabuilt EasySHED® is a Power Drill Two people are recommended when handling the with a Phillips Head attachment.
- Page 4 Assembly Side Panels x2 Height at shed corner 1800mm Height at apex 2090mm Left and right Side Wall Panels Assembled Sheeting to be the same are identical length as the Channel (E) and (K) Side Panel Components • 8x Gable Sheets (I) 780mm • 2x U Channel (E) 3000mm long • 2x Gussets for Gable apex (J) •...
- Page 5 Door Assembly/Hanging the Door (4A) Components • 1x Door Sheet (C) 780 x 1740mm • 2x U Channel (F) 780mm long • 1x U Channel (G) 1740mm long • 1x Door Strap (N) 780mm • 1x U Channel with Hinges (O) 1740mm Step 1 Position U Channel (F) on top of the Door Sheet (C).
- Page 6 5 STEP INSTALLATION - EasySHED When installed, ribs in sheeting face outward for all panels. If desired, 3.2mm pop rivets can be used instead of the self tapping screws provided. Sheds installed without adequate anchoring to the ground or concrete could be extensively damaged in windy weather.
- Page 7 Temporary & permanent anchoring Please note: It is essential to firmly anchor your Durabuilt EasySHED® as soon as assembly is complete, otherwise there is a risk of damage to panels, property or persons. The installation site for the shed must be reasonably level. Check that the shed is rectangular at floor level (the diagonal measurements should be equal).
- Page 8 & function Durabuilt sheds are supplied as PANELplus® (modular panel form) for convenience and efficiency, or EasySHED® (boxed) for ease of transport and handling. Both the “easy to install” pre-assembled modular sheds and the “easy to assemble” boxed sheds are engineered for extra strength and security.
