AVANT A2808 Operator's Manual

Rotary hoe for 200, 300-700-series loaders
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operator's manual for Attachment
Operator's
Operator's
Operator's
Product number:
Please read this manual carefully before using the equipment, and follow
all instructions.
Keep this manual for later reference.
manual for Attachment
manual for Attachment
manual for Attachment
R
o
t
a
r
y
H
R
o
t
a
r
y
H
300-700-series loaders:
200-series loaders:
o
e
o
e
A2808
A21163
A21102
Rotary Hoe 2012 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A2808 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVANT A2808

  • Page 1 Operator’s manual for Attachment manual for Attachment Operator’s Operator’s manual for Attachment manual for Attachment Product number: 300-700-series loaders: A2808 A21163 200-series loaders: A21102 Please read this manual carefully before using the equipment, and follow all instructions. Keep this manual for later reference.

  • Page 2: Table Of Contents

    Rotary Hoe 2012 1 CONTENTS 1. Foreword ..............................3 2. Designed purpose of use ........................3 3. Safety instructions for the rotary hoe .....................3 4. Rotary Hoe specifications........................5 5. Assembly of the rotary hoe........................6 5.1. Mounting the rotary hoe to the loader ....................6 5.2.

  • Page 3: Foreword

    3(12) 1. Foreword Avant Tecno Oy would like to thank you for your purchase of this AVANT attachment. It has been designed and manufactured on the basis of years of product development and experience. By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure the reliable operation and long service life of the equipment.
  • Page 4 4(12) • Beware of the sharp rotating blades of Rotary Hoe. Never leave the driver’s seat if the rotary hoe is running. Lower the hoe flat on the ground and wait until the blades have stopped completely before going near the attachment. •...

  • Page 5: Rotary Hoe Specifications

    22,5 MPa (225 bar) (300) (528) Suitable Avant loader* 216, 218, 220 420-528 630-750 Suitability recommendations are based on the width of the machine and the sufficiency of the loader's hydraulic power. For more information, contact your AVANT dealer.

  • Page 6: Assembly Of The Rotary Hoe

    6(12) 5. Assembly of the rotary hoe The rotary hoe is ready for use as delivered. Mount the attachment and its hydraulic hoses to the loader as instructed. Read the instructions related to using the equipment and begin the practise of use at a safe area. 5.1.

  • Page 7: Connecting And Disconnecting The Hydraulic Fittings

    The attachment is equipped with either standard quick couplings or the multiconnector system. If you want to change the type of the hydraulic couplings, contact your Avant dealer or service point for instructions or installation services. On 200-series loaders only conventional quick couplings are available.

  • Page 8: Field Roller

    Field roller Field roller is an option for the rotary hoe available from your AVANT dealer. The roller is mounted on front of the rotary hoe. Its purpose is to compress the cultivated soil for more even surface. The roller also makes the working height adjustment more consistent and as the roller compresses the soil, more even surface can be achieved.

  • Page 9: Storage Of The Rotary Hoe

    9(12) 5.4. Storage of the rotary hoe Store the rotary hoe in a way that it is not left on its blades or on its roller. Ensure that the hoe is properly supported against any movement by placing it on appropriate means, such as on blocks of wood, for example.

  • Page 10: Direction Of Rotation

    10(12) If the rotary hoe stops rotating, the driving speed has been too high or the hoe has hit a rock. If blades hit a rock, lift the hoe slightly off the ground to avoid wearing or damaging the blades. If an obstacle on the ground cannot be removed, try to go around it, as the rotary hoe should not be used to chop obstacles on the ground.

  • Page 11: Cleaning And Lubricating The Rotary Hoe

    If there are signs of leaking, to check the component, hold up a piece of cardboard in the area where a leak is suspected. Finding any of these faults means that the hydraulic hose or component must be replaced. Spare parts are available from your nearest AVANT retailer or service point.

  • Page 12: Rotary Hoe Blades

    12(12) 7.2. Rotary hoe blades The condition of the blades should be checked after every few uses. When the blades are in good shape, they penetrate to the ground surface better and therefore the hoe needs less power to operate. If the performance of the rotary hoe has weakened from the original, the blades have probably become very blunt or some of the blades have been damaged.

  • Page 13: Warranty Terms

    Do not over tighten the chain. Too much tension on the chain damages the hydraulic motor and the bearings. 8. Warranty terms Avant Tecno Oy grants a warranty of one-year (12 months) for the rotary hoe from the date of purchase. The warranty covers repair costs as follows: •...
  • Page 14 SFS-EN ISO 12100-1, SFS-EN ISO 12100-2, SFS-EN 982, SFS-EN 708 Kuvaus: Avant-kuormainten kanssa käytettävä hydraulitoiminen jyrsin Beskrivning: Hydraulisk jordfräs; arbetsredskap för Avant lastare Description: Hydraulic rotary hoe; attachment for Avant loaders Beschreibung: Hydraulische Bodenfräse; Anbaugerät für Avant Radlader Mallit / Modeller / Models / Modellen: Avant 200 series...
