Grifco E840G Quick Start Manual

GRIFCO FRONT PANEL

PROGRAMMING - S-Drive

1. Press the learn bu�on
2. Enter a 4-digit code on
3. The operator will auto
grifco.com.au
grifco.co.nz
1. UP - Moves the door upwards
2. DOWN - Moves the door downwards
STOP - Stops the door
3.
4. SET -
5. POWER ON - Shows when the unit is
mains powered
6. STATUS - Shows the status of the unit
7. LIMIT ERROR – When lit indicates limits
are not set

PROGRAMMING - LS-Drive

on the main PCB
the E840G keypad and
press enter
exit learn mode
1. Press the learn bu�on on the rear of
the operator
2. Enter a 4-digit code on the E840G
keypad and press enter
3. The operator will auto exit learn mode
To prevent possible SERIOUS INJURY or DEATH from a moving door:
• Install Wireless Keypad within sight of the door, out of reach of children at a minimum height of 1.5m, and away
from all moving parts of door.
• ALWAYS keep remote controls out of reach of children. NEVER permit children to operate, or play with remote
controls.
Ac vate door ONLY when it can be seen clearly, is properly installed, and there are no obstruc ons to the door travel.
•
•
ALWAYS keep the door in sight un l completely closed. NEVER permit anyone to cross the path of a moving door
•
NEVER allow small children near ba eries. If ba ery is swallowed, immediately no fy your doctor.

PROGRAMMING - eDrive +2.0

KEYPAD
ENTER key
E840G Wireless Keypad
Indicator LED
Learn Button
WIRELESS KEYPAD – MODEL E840G

WARNING

To program the E840G Wireless Keypad ensure the radio lock is
removed then perform the following steps:
1. Press and hold the SET bu on on the GRIFCO front panel,
then
2. While holding the SET bu on, press the STOP bu on 5 mes
(the green status light will light then con nue flashing,
indica ng learn mode)
3. Let go of the SET bu on
4. Enter a 4-digit code into the E840G keypad.
Press the E840G ENTER key
5.
Press STOP bu on on the GRIFCO front panel to exit learn
6.
mode.
Install the RADIO LOCK key on the eDrive2 board to prevent
7.
any further wireless entry devices being learned.

PROGRAMMING - LR-Drive

1. Press & Release the "S" Bu�on on the operator
2. Enter a 4-digit code of your choice on the Wireless Keypad
3. Press & hold the Enter Bu�on on the Wireless Keypad un�l
the operator light flashes
4. A�er the lights flash release the Enter Bu�on
"S" Button
