Summary of Contents for Greenway Home Products 8907644
- Page 1 Instruction Manual for E-bikes SKU#:8907644 SKU#:8907636 BIKE ELECTRIC FOLDING 20 IN BIKE ELECTRIC 26 IN...
-
Page 2: Table Of Contents
Table of contents 1. Your E-Bike …………………………………………………………………..2—3 1.1 Introduction 1.2 General presentation of the vehicle 2. Function Display …………………………………………………………..4—8 2.1 Displayer Introduction 2.2 Operation 3. Using the bike ………………………………………………………………..8 3.1 Riding the bike 4. The battery ……………………………………………………………….……..8—10 4.1 Installing and removing the battery 4.2 Charging the battery 4.3 Battery autonomy and lifespan 4.4 Battery safety instructions... -
Page 3: Your E-Bike
Use the e-bike according to the user guide, or it may shorten the life cycle. Have a pleasant ride! 1.2) General presentation of the vehicle 1.2.1) General information 8907644 8907636 SKU#. Weight of bike with battery: 26KG... - Page 4 1.2.2) Spare parts spec Spare parts name 8907644 8907636 Motor BAFANG BAFANG 36V,350W （20”） 36V,350W（26”） Battery 36V 10.40AH 36V 10.4AH LG Lithium battery cells LG Lithium battery cells Display KUNTENG, KT-LCD5 KUNTENG, KT-LCD5 Front fork Strong suspension fork with lock...
-
Page 5: Function Display
2. Function Display 2.1) Display Introduction UP button Riding speed(metric) Km/H Riding speed (imperial) SW button MAX speed DOWN button Average speed ASSIST Pas level Battery capacity indicator Distance(metric) CRUISE Cruise function Distance (imperial) Power-assisted function Trip distance Single trip time Total distance Total trip time Battery voltage... -
Page 6: Operation
2.2) Operation ON/OFF Press and hold (POWER BUTTON) to turn the power off and on. When the motor stops driving and when the e-bike is not used for a consecutive 5 minutes, it will automatically shut down. 1. Display 1 Hold button to start up and enter display 1. - Page 7 Turn on throttle, THROTTLE display. 2.4 PAS display When Power-assisted riding, PAS display. 2.5 Cruise function After the cruise function is turned on, the trip riding speed is greater than 7 km/ h, Press and hold button long to enter cruise mode.
- Page 8 4 Display 3 Hold button shortly in display 2 to enter display 3. In the riding condition, five seconds later, a single maximum speed (MXS) display automatically returns to the real riding speed (KM/H). In display 3, hold button shortly (SW) and the display will re-enter display 1.
-
Page 9: Using The Bike
The metric units will be set after finishing setting wheel diameter, KM/H and Km flash. Hold button shortly and select metric units of speed and mileage in synchronization. Metric Imperial Display Riding speed KM/H Total distance 4. KM/H and Km stop flash after metric unit setting is completed. Hold button shortly again to re-enter the maximum riding speed setting interface;... -
Page 10: The Battery
4.The battery 4.1) Installing and removing the battery To remove the battery, unfasten the lock which is located along the battery’s box. Remove the battery by pulling it out. To put the battery back into place, insert the battery along to the guide rails. -
Page 11: Safety Maintenance And Recommendations
Always keep it away from children Do not take it apart or hit, pierce or submerge it Keep it away from temperatures exceeding 60° Never create a connection between the contacts located at the bottom of the battery Never let the battery charge unattended Never sleep near a battery that is charging Only use the charger that came with your bike or that was supplied by your dealer.
