1/4 Inch Extendable Port
將Micro USB插入手柄上的充電Micro USB 。
Plug Mirco USB plug into Charging Micro
USB Hub on the handle.
Micro USB 充電口
Micro USB Hub
PAN AXIS
Clip smartphones and balance 安裝手機和配重片
1
水平位置
Balance position
若無法達至水平 ，需安裝平衡配重件 。
Use the Balance Plugin if it can't be balanced.
1/4 寸孔
Android
M4 Lite 快速啟用指南
M4 Lite Quick Start Guide
PITCH AXIS
平衡配重片蓋
Balance Plugin Cover
藍芽指示燈
Bluetooth Indicator
方向鍵
Joystick
開關
Power Button
指示燈
Indicator
先在手機夾裡往上置入手機 ，再把手機往上
推開上半部夾子 ，把手機推進手機夾內固定 。
Hold the smartphone to push the upper
clip upwards and install the
smartphone on it.
裝妥手機後 ，需要左右移動手機至
約水平位置 。
Before power on, adjust the smartphone
laterally to a balance position.
尺寸較大的手機需要裝上配重片以增加
穩定性和使用時間 。
Put on the provided Balance Plugin as
shown as to increase the durability and
stability of the stabilizer.(For large size
or heavier smartphone only)
e.g. iPhone 7+, Samsung S8+ , SONY XZ Premium, LG V20 etc.
Download APP
Swiftcam.com
模式轉換
MODE SWITCH
方向上 UP
方向下 DOWN
方向右 RIGHT
方向左 LEFT
平衡配重件
Balance Plugin
平衡配重片蓋
Balance Plugin Cover
iSO
Advertisement
Table of Contents
Summary of Contents for SwiftCam M4 Lite
- Page 1 M4 Lite 快速啟用指南 M4 Lite Quick Start Guide Swiftcam.com PITCH AXIS 平衡配重片蓋 Balance Plugin Cover 1/4 寸孔 藍芽指示燈 1/4 Inch Extendable Port Bluetooth Indicator 方向鍵 Joystick 將Micro USB插入手柄上的充電Micro USB 。 Plug Mirco USB plug into Charging Micro 開關 模式轉換 USB Hub on the handle.
- Page 2 SwiftCam shall exercise its sole and absolute discretion to determine and SwiftCam’ s decision shall be final, whether to charge a service fee for the repair works or not tocarry out the repair work : - Where damage was caused by a product which is altered from the product structure or specification as...
