Datex-Ohmeda S/5 G-AO Technical Reference Manual

Datex-Ohmeda S/5 G-AO Technical Reference Manual

Airway module gas interface board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Datex-Ohmeda Inc.
3030 Ohmeda Drive
53707-7550 MADISON, WIS
USA
Tel. +1-608-221 1551, Fax +1-608-222 9147
www.us.datex-ohmeda.com
TM
S/5
Airway Module, G-AO (rev. 06)
TM
S/5
Airway Module, G-AiO (rev. 05)
TM
S/5
Airway Module, G-AiOV (rev. 04)
TM
S/5
Airway Module, G-AOV (rev. 04)
TM
S/5
Gas Interface Board, B-GAS (rev. 01)
Technical Reference Manual Slot
Datex-Ohmeda
All specifications are subject to change without notice.
Document No. 800 1005-1
Tel. +358 10 394 11 Fax +358 9 146 3310
 Instrumentarium Corp. All rights reserved.
June 2001
Datex-Ohmeda Division,
Instrumentarium Corp.
P.O. Box 900, FIN-00031
DATEX-OHMEDA, FINLAND
www.datex-ohmeda.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S/5 G-AO and is the answer not in the manual?

Questions and answers

Related Manuals for Datex-Ohmeda S/5 G-AO

Summary of Contents for Datex-Ohmeda S/5 G-AO

  • Page 1 Gas Interface Board, B-GAS (rev. 01) Technical Reference Manual Slot All specifications are subject to change without notice. Document No. 800 1005-1 June 2001 Datex-Ohmeda Inc. Datex-Ohmeda Division, 3030 Ohmeda Drive Instrumentarium Corp. 53707-7550 MADISON, WIS P.O. Box 900, FIN-00031 DATEX-OHMEDA, FINLAND Tel.

  • Page 3: Table Of Contents

    Table of contents TABLE OF CONTENTS S/5 Airway modules and S/5 Gas Interface Board, B-GAS TABLE OF CONTENTS TABLE OF FIGURES INTRODUCTION Specifications 1.1 General specifications ..........................2 1.2 Typical performance ..........................2 1.2.1 CO ..............................2 1.2.2 Respiration rate..........................2 1.2.3 O ..............................2 1.2.4 N O ..............................2 1.2.5 Hal, Iso, Enf............................2...
  • Page 4 6.1.4 G-AO rev. 04, G-AiO rev. 03, G-AOV rev. 02, G-AiOV rev. 02, G-O rev. 00, G-OV rev. 00 .....67 6.1.5 G-AO rev. 05, G-AiO rev. 04, G-AOV rev. 03, G-AiOV rev. 03, G-O rev. 01, G-OV rev. 01 .....67 6.1.6 S/5 G-AO rev. 06, G-AiO rev. 05, G-AOV rev. 04, G-AiOV rev. 04 ............67 6.1.7 Panel stickers ..........................67 6.1.8 S/5 panel stickers .........................68...

  • Page 5: Table Of Figures

    Table of contents APPENDIX A Service check FORM TABLE OF FIGURES Figure 1 O/AA gas absorption spectra.....................5 Figure 2 measurement principle ........................6 Figure 3 Anaesthetic Agents gas absorption spectra....................7 Figure 4 Airway module block diagram .......................9 Figure 5 Gas sampling system block diagram ....................12 Figure 6 Gas sampling system layout........................13 Figure 7...
  • Page 6 Datex-Ohmeda S/5 Anesthesia Monitor Document No. 800 1005-1...

  • Page 7: Introduction

    S/5 Airway modules INTRODUCTION The S/5 Airway Modules, G-AO, G-AiO, G-AOV and G-AiOV are designed for use with the S/5 Anesthesia Monitor and provide airway and respiratory parameters. Later in this manual modules can be called w/o system name S/5. This Technical Reference Manual Slot provides information for the maintenance and service of the airway modules.

  • Page 8: Specifications

    Datex-Ohmeda S/5 Anesthesia Monitor SPECIFICATIONS 1.1 General specifications Module size, W × D × H 135 × 410 × 135 mm/5.3 × 15.0 × 5.3 in Module weight 6 kg/13 lbs. 1.2 Typical performance Sampling rate 200 ml/min nominal (180...220 ml/min)

  • Page 9: Des

    S/5 Airway modules 1.2.7 Des Measurement range 0 to 18 % Extended range 18 to 30 % (unspecified) Resolution two decimals when the AA concentration below 1.0 % If AA concentration is below 0.10 %, 0.00 % is displayed. 1.2.8 Agent identification Identified agents HAL, ENF, ISO, SEV, DES Identification time...

  • Page 10: Technical Specification

    Datex-Ohmeda S/5 Anesthesia Monitor 1.3 Technical specification 1.3.1 CO Measurement rise time <360 ms (from 10 to 90 %) Gain stability ≤0.2 %CO /24 h (0 to 8 %) ≤0.4 %CO /24 h (8 to 10 %) Gain temperature drift ≤0.2 %CO...

  • Page 11: Functional Description

    S/5 Airway modules FUNCTIONAL DESCRIPTION 2.1 Measurement principle 2.1.1 CO O and Agent measurement The CO O, and anesthetic agent gas measurements are based on absorption of infrared light as it passes through the gas sample in measuring chamber in the photometer. The light absorption is measured at three wavelengths using an infrared detector.

  • Page 12: Measurement

    Datex-Ohmeda S/5 Anesthesia Monitor 2.1.2 O measurement The differential oxygen measuring unit uses the paramagnetic principle in a pneumatic bridge configuration. The signal picked up with a differential pressure transducer is generated in a measuring cell with a strong magnetic field that is switched on and off at a frequency of 110 Hz.

  • Page 13: Agent Identification

    S/5 Airway modules 2.1.3 Agent identification The anesthetic agent identification bench identifies Halothane, Enflurane, Isoflurane, Desflurane and Sevoflurane. The bench measures the spectrum of the gas between 3.24 µm and 3.39 µm. Because the spectrum of each of the anaesthetic agents is different it is possible to identify them. The bench consists of an infrared source, a measuring chamber, a rotating filter and a detector.

  • Page 14: Patient Spirometry

    Datex-Ohmeda S/5 Anesthesia Monitor 2.1.4 Patient Spirometry In anesthesia, CMV (Controlled Mechanical Ventilation) is the mostly used ventilation mode. In this mode, mechanical breaths are delivered to the patient by a ventilator with a proper tidal volume (TV), respiration rate (RR), and inspiration/expiration ratio in time (I:E) determined by the settings of the ventilator.

  • Page 15: Main Components

    S/5 Airway modules Patient Spirometry sensor, D-lite Patient Spirometry is measured with a specific sensor, D-lite or Pedi-lite. D-lite and Pedi-lite sensors are designed to measure kinetic pressure by two-sided Pitot tube. The pressure reduction caused by measuring cross is taken into account, too, especially in small flows. Velocity is calculated from pressure difference according to Bernoulli's equation.

  • Page 16: Gas Sampling System

    Datex-Ohmeda S/5 Anesthesia Monitor 2.2.1 Gas sampling system The gas sampling system samples the measured air to the module, and removes water and impurities from it. A sampling line is connected to the water trap on the front panel. The pump draws gas through the sampling line to gas measuring units.
  • Page 17 S/5 Airway modules Gas measuring units, ACX-200 and O unit After the zero valve, the gas passes through the ACX-200 and O measuring units. In the ACX-200 measuring unit, infrared light is passed through chambers containing the main flow gas (measurement) and a chamber containing reference gas.

  • Page 18: Figure 5 Gas Sampling System Block Diagram

    Datex-Ohmeda S/5 Anesthesia Monitor Figure 5 Gas sampling system block diagram In G-AO, -AOV models, tube A is Teflon, B and C Nafion. In G-AiO, -AiOV models, tubes A and C are Nafion, B is Teflon. See new tubing since autumn 1998 in figure 7.

  • Page 19: Figure 6 Gas Sampling System Layout

    S/5 Airway modules Figure 6 Gas sampling system layout See new sampling system layout since autumn 1998 in figure 8. Pressure valve Sample pump Ref IN Filter Pressure ASX-200 transducer Room AIR in G-AiO/AiOV Sample absorber Gas OUT Zero valve sensor ACX-200 main flow...

  • Page 20: Figure 8 Gas Sampling System Layout

    Datex-Ohmeda S/5 Anesthesia Monitor Figure 8 Gas sampling system layout Figure 8 is valid for modules manufactured since autumn 1998. Document No. 800 1005-1...
  • Page 21 S/5 Airway modules Table 2 Flow cassettes Flow Code cassette 50/26.0 878048 50/19.0 873800 50/16.3 878047 50/15.3 873801 50/14.1 878046 50/13.1 873802 50/12.4 878045 50/11.2 874770 50/10.4 873803 50/9.2 874509 50/8.7 873804 50/7.4 873805 50/6.5 878044 50/5.8 873806 50/5.1 878043 50/4.4 873807 50/3.8...

  • Page 22: Acx-200 Measuring Unit

    Datex-Ohmeda S/5 Anesthesia Monitor 2.2.2 ACX-200 measuring unit The ACX photometer is of dual path type. The infrared light beam passes through a measuring chamber containing the gas to be analyzed, and a reference chamber, which is free of CO and AA.

  • Page 23: Om Measuring Unit

    S/5 Airway modules Figure 10 O/AA measurement block diagram 2.2.3 OM measuring unit The oxygen measurement is based on the paramagnetic susceptibility, which is a unique property of oxygen among all gases generally present in a breathing gas mixture. The gas to be measured and the reference gas, which usually is room air, are conducted into a gap in an electromagnet with a strong magnetic field switched on and off at a frequency of approximately 110 Hz.

  • Page 24: Acx Measuring Board

    Datex-Ohmeda S/5 Anesthesia Monitor 2.2.4 ACX measuring board The measuring electronics can be divided into a few functional blocks, which are described below (see the block diagram in figure 11). The ACX Measuring board controls gas measurements. It converts the photometer signal into digital data, calculates results and transmits it to Gas mother board.

  • Page 25: Figure 11 Acx Measuring Board Block Diagram

    S/5 Airway modules Figure 11 ACX measuring board block diagram Document No. 800 1005-1...

  • Page 26: Asx Agent Identification Bench

    Datex-Ohmeda S/5 Anesthesia Monitor 2.2.5 ASX agent identification bench The ASX-200 agent identification bench has one measuring chamber. Background compensation is done by subtracting the background spectrum from the measured signal. Background spectrum is measured simultaneously with the zeroing of the ACX-200 unit. The resulting spectrum is analyzed to identify the agent.

  • Page 27: Figure 13 Asx Measuring Board Block Diagram

    S/5 Airway modules EEPROM is a 64 x 16 bit serial chip. It is partly protected so that if jumper X1 is installed the processor can erase or write the protected registers by serial communication commands. The protected section contains permanent factory calibrations. Figure 13 ASX measuring board block diagram Document No.

  • Page 28: Pvx Board

    Datex-Ohmeda S/5 Anesthesia Monitor 2.2.7 PVX board When Patient Spirometry is used, special sensors, D-lite or Pedi-lite, replaces the normal airway adapter in the patient circuit. The spirometry tubing is attached to the two connectors on the sensor and on the module front panel.

  • Page 29: Figure 14 Pvx Board Block Diagram

    Press PRESS Sense Gas Pressure and Flow IN (from Front Panel) Reset Temp sense Con- Room Pressure TEMP Zero verter Valve FLOW1 Room Pressure Zero Press Valve Diff. FLOW0 Sense SRAM Gas Pressure EEPROM EPROM and Flow 8051FA IN (from Front Panel) OFFSET Serial In Con-...

  • Page 30: Gas Mother Board

    Datex-Ohmeda S/5 Anesthesia Monitor 2.2.8 Gas mother board The Gas mother board controls power supply to each measuring unit, as well as the serial communication between the units and the module processor. There are connectors for the pump, valves and gas measuring units on the board. The board contains a processor which controls the functions within the module.

  • Page 31: Figure 15 Gas Mother Board Block Diagram

    S/5 Airway modules Valves, pump and infrared lamps control Valves are controlled by ACX Measuring board from which the control signals are ran through buffer IC to the valve connector. OCCLUS signal controls the pressure (occlusion) valve and ZERO signal controls the zero valve.

  • Page 32: Gas Interface Board

    Datex-Ohmeda S/5 Anesthesia Monitor 2.2.9 Gas interface board The Gas interface board, B-GAS is used for connecting an Airway Module to the Central Unit. The board connects Airway Module signals to the module bus and supplies voltages from the module bus to the Airway Module.

  • Page 33: Gas Mother Board Connectors

    S/5 Airway modules 2.3.2 Gas mother board connectors Module connector. Serial communication bus to the main CPU board. Supply voltages. ACX Measuring board PVX board Oxygen measuring unit ASX Measuring board Sampling pump X8, X9 Power supply for infrared lamps (ACX, ASX) Module front panel keys Valves Document No.
  • Page 34 Datex-Ohmeda S/5 Anesthesia Monitor ACX measuring board (X1) - Gas mother board (X2) Pin No. +15 V AGND -15 V +10 VREF AOUT6 AOUT5 AA AOUT4 VL AOUT3 CO 2 AOUT2 O 2 AOUT1 N 2 O DAC1 FLOW DAC0 PRES...
  • Page 35 S/5 Airway modules ASX board (X5) - Gas mother board (X5) Pin No. Signal Analog ground +15 V -15 V DIRB (not used) TXDB -RESET +5 V +15 VDIRTY Digital ground Document No. 800 1005-1...
  • Page 36 Datex-Ohmeda S/5 Anesthesia Monitor PVX board (X1) - Gas mother board (X3) Pin No. +15 V AGND -15 V +10 VREF DAC1 FLOWY DAC0 PRES FLOW PRESS -RESET TxDP +5 V +15 VDIRTY +5 V GND DIRTY DGND Document No. 800 1005-1...

  • Page 37: Service Procedures

    Field service of the airway modules is limited to replacing faulty circuit boards or mechanical parts. The circuit boards should be returned to Datex-Ohmeda for repair. Datex-Ohmeda is always available for service advice. Please provide the unit serial number, full type designation, and a detailed fault description.

  • Page 38: Service Check

    Datex-Ohmeda S/5 Anesthesia Monitor 3.2 Service check These instructions include complete procedures for a service check. The service check is recommended to be performed after any service repair. However, the service check procedures can also be used for determining possible failures.
  • Page 39 S/5 Airway modules All modules Remove the airway module case, the top protection cover and the bronze plate from the • side of the O sensor, if installed. Detach the ACX measuring board and the PVX board with the support plate, if installed. •...
  • Page 40 (order code 64001) Replace the D-fend and the sampling line. • NOTE: Use only Datex-Ohmeda sampling lines in order to ensure proper functioning. Connect the module to the Central Unit with a long gas interface cable and switch the •...
  • Page 41 S/5 Airway modules If the module contains a membrane key on the front panel, press the key at least for one second and check that it is identified, i.e. the text for Button changes from OFF to ON in the menu.
  • Page 42 Datex-Ohmeda S/5 Anesthesia Monitor Perform the sampling system leak test. Block the tip of the sampling line with your finger until the ‘Amb-Work’ -value becomes stable. If the value does not reach 110, replace the sampling pump and repeat the leak test.
  • Page 43 S/5 Airway modules Perform gas calibration: AIRWAY GAS - GAS CALIBRATION NOTE: For maximum accuracy, a warm-up time of 30 minutes is recommended. NOTE: If the module contains the agent identification unit, the ASX-100 or ASX-200, keep feeding gas at least 15 seconds after the message ‘Adjust’ appears in the menu. This way the agent identification unit has enough time for calibration.
  • Page 44 Datex-Ohmeda S/5 Anesthesia Monitor Agent identification option Check that the ‘ACX_ASX Delay’ -value in the ACX service menu is within 400-800. If the value is not within the range, readjust the flows and repeat the fall time measurement. Enter the ASX service menu: •...
  • Page 45 S/5 Airway modules Patient spirometry option Switch the monitor off and install the PVX board, then switch the monitor back on. • Preset gas measurement settings: • Airway Gas - Spirometry Setup - Paw Scale - 20 Flow Scale - 15 Check that the patient spirometry connectors on the front panel are clean and intact.
  • Page 46 Datex-Ohmeda S/5 Anesthesia Monitor All Airway modules Switch the monitor off, disconnect the gas interface cable and reassemble the module. • NOTE: When reassembling the module, make sure that the tubes and cables are not pinched between the PC boards and covers.

  • Page 47: Disassembly And Reassembly

    S/5 Airway modules 3.3 Disassembly and reassembly The airway module (G-AiOV) is disassembled in the following way. See the exploded view. Remove three screws from the rear panel. Remove one thumb screw and one 5 mm cross recess screw from the bottom of the airway module case.

  • Page 48: Adjustments And Calibrations

    • Gas response is slow • NOTE: Adjust the flows with a new, clean D-fend water trap and original Datex-Ohmeda sampling line. NOTE: Before adjusting the flows, make sure that there is no leakage in the sampling system. NOTE: Let the monitor warm up for 30 minutes before measuring flow rates.

  • Page 49: Figure 16 Gas Sampling System Adjustment Chart

    S/5 Airway modules Figure 16 Gas sampling system adjustment chart See also chapter “Gas sampling system” to see gas sampling system block diagrams for modules manufactured since autumn 1998. Document No. 800 1005-1...

  • Page 50: Oxygen Measurement Unit Adjustments

    The only field service procedures for the O measuring unit are the offset (zero), gain, and frequency adjustments. In case of any other trouble, the measuring unit should be replaced and the faulty one sent to Datex-Ohmeda for repair. Document No. 800 1005-1...
  • Page 51 S/5 Airway modules Offset (zero) adjustment Because the oxygen measuring unit is a differential sensor, which actually measures the difference between the O concentrations in the sample and reference gases, its output must be adjusted to equal zero when atmospheric air is present at both inputs. Connect a digital voltmeter to the output of the O measuring unit at pin 7 of connector X4 on the Gas mother board.

  • Page 52: Flow Calibration

    Datex-Ohmeda S/5 Anesthesia Monitor ZERO TEMP.COMP. GAIN FREQUENCY Gas connectors OUT IN Vibration insulation Figure 17 measuring unit adjustments 3.4.4 Flow calibration PVX board is calibrated at the factory and due to the board’s design calibration is not regularly needed. The calibration data is saved into the board’s EEPROM memory and if the software EPROM of the board is changed the calibration must be performed.

  • Page 53: Troubleshooting

    S/5 Airway modules TROUBLESHOOTING 4.1 Troubleshooting chart Trouble Possible Cause/Treatment No response to breathing Sampling line or water trap blocked or loose, or improperly attached. Water trap container full. Interface cable to monitor disconnected. See chapter “ Gas sampling system troubleshooting .” SENSOR INOP.

  • Page 54: Supply Voltage Troubleshooting

    Datex-Ohmeda S/5 Anesthesia Monitor 4.1.1 Supply voltage troubleshooting Trouble Possible Cause Treatment “Gas module removed” +5V lost Gas module CPU not running. Check Gas Interface No Gas module exists after turning the cable. monitor on. Check +5V from module mother board and timeout value from module service page.

  • Page 55: Gas Sampling System Troubleshooting

    NOTE: If any liquid has entered the ACX-200 measuring unit due to water trap filter failure, contact Datex-Ohmeda technical services. 4.2.1 Sampling system leak test Connect power cord and sampling line. Turn the power on and wait until the initialization is over.

  • Page 56: Om Measuring Unit Troubleshooting

    Because of the complex and very sensitive construction of the oxygen measuring unit no repairs should be attempted inside the unit. Instead, if the fault has been found in the measuring unit itself, it should be replaced and the faulty unit be sent to Datex-Ohmeda for repair. In cases of no response to O or strong drift, check the tubing for loose connections, blockages and leaks.
  • Page 57 S/5 Airway modules Cleaning procedure Tools needed 10 ml syringe • water glass • 2 pcs 30 cm silicon tubes with inner diameter of 3 mm • screwdriver • Detach the measuring unit from the monitor or gas module. Attach the silicon tubes to the tube connector on the unit. Attach the 10 ml syringe to one of the tubes.

  • Page 58: Asx Agent Identification Unit Troubleshooting

    Datex-Ohmeda S/5 Anesthesia Monitor 4.5 ASX agent identification unit troubleshooting NOTE: Please read also troubleshooting section in User’s Reference Manual . CAUTION The agent identification bench ASX-200 can only be repaired and calibrated only at the factory. Trouble Possible Cause/Treatment AGENT MIXTURE-message when Repeat calibration.

  • Page 59: Pvx Board Troubleshooting

    S/5 Airway modules 4.6 PVX board troubleshooting CAUTION The measuring unit PVX-100 can be repaired and calibrated only at the factory. NOTE: Never apply DIFFERENTIAL pressure higher than 25 cmH O to the spirometry tubing. Make sure that both spirometry tubes are always connected. NOTE: Never apply overpressure or negative pressure of more than 300 cmH O to the spirometry tubing.

  • Page 60: Error Messages

    Datex-Ohmeda S/5 Anesthesia Monitor 4.8 Error messages Message Explanation Occlusion The sample tube inside or outside the monitor is blocked or water trap is occluded. If occlusion persists, measured gas values disappear. Air leak - the water trap is not connected - the gas outlet is blocked - there is a leak in the sampling line inside the module.

  • Page 61: Service Menu

    S/5 Airway modules SERVICE MENU Monitor Setup Press the key. Select Install/Service (password 16-4-34). Select Service (password 26-23-8). Select Parameters - Gas Unit . Document No. 800 1005-1...

  • Page 62: Gas Mother Board

    Datex-Ohmeda S/5 Anesthesia Monitor 5.1 Gas mother board Service Data Oper State Internal operation state of the module: 0...9 function performed, if staying on, failure is indicated 10...29 Initialization 30...39 Normal operation state 40...49 Zeroing 50...59 Calibrating ERR status Indicates measuring unit malfunction:...
  • Page 63 S/5 Airway modules Serial Comm(unication) Serial Communication indicates a state of serial communication between the module processor and a measuring unit. GAS: FFFF Continuously ACX: FFFF Continuously ASX: Value is for factory use only. PVX: Value is for factory use only. Rep status Rep status is a four-digit number, where all digits, abcd , can have different values.
  • Page 64 Datex-Ohmeda S/5 Anesthesia Monitor PVX rep status FFFF continuously General Status Normal operation state 8000 Initialization If not 0 or 8000, replace the gas mother board. Timeouts is a cumulative number that indicates how many times the module has not responded to the monitor's inquiry.

  • Page 65: Acx Service Menu

    S/5 Airway modules 5.2 ACX service menu Pump ctrl Turns pump on/off Zero valve ctrl Turns zero valve on/off Pres valve ctrl Turns pressure valve on/off Noise Meas Noise measurement. Fall time Meas Fall time measurement. Service Data Fall time Fall time indicates the response time of the measuring units.
  • Page 66 Datex-Ohmeda S/5 Anesthesia Monitor Calib zero and gain These values are calibration constants of zero and gain for each gas. The zero values may change at gas zeroing, the gain values at gas calibration. When the monitor performs gas zeroing, the main software will write zero constants for the gases O, AA, O ) to the ACX memory.

  • Page 67: Pvx Service Menu

    S/5 Airway modules 5.3 PVX service menu Service Data Aw Pres Zero...The value of airway pressure zero is changing within the range of 1000 to 2400. *) Aw Pres Gain...Gain of pressure measurement. This value should be fixed to 8662. Flow Zero..The value corresponds to the pressure transducer B1 output during PVX zeroing.

  • Page 68: Flow Calibration

    Datex-Ohmeda S/5 Anesthesia Monitor 5.3.1 Flow calibration Flow calibration PVX board is calibrated at the factory and due to the board’s design calibration is not regularly needed. The calibration data is saved into the board’s EEPROM memory and if the software EPROM of the board is changed the calibration must be performed.

  • Page 69: Temp & Hum Service Menu

    S/5 Airway modules 5.3.2 Temp & Hum service menu If circumstances noticeably differ from normal, or additional accuracy is required, the use of Temp & Humidity menu may be advisable. Especially small errors in tidal values may indicate that temperature and humidity settings of the monitor differ too much from the used system.

  • Page 70: Asx Service Menu

    Datex-Ohmeda S/5 Anesthesia Monitor 5.4 ASX service menu NOTE: The ASX service menu in monitor software S-xxx94 or newer supports only modules equipped with the ASX-200. Service Data ID result displays the identified gas or mixture Total % is the anesthetic agent concentration measured by ASX bench.

  • Page 71: Spare Parts

    S/5 Airway modules SPARE PARTS 6.1 Spare parts list NOTE: Only changed part numbers are listed under later revisions. To find the desired part: check first the list of the revision that corresponds your device. If the part is not listed there, check the previous revision, etc.

  • Page 72: G-Ao Rev. 02, G-Aio Rev. 01, G-Aov Rev. 00, G-Aiov Rev. 00

    Datex-Ohmeda S/5 Anesthesia Monitor Item Item description Order No. Cover, top protection 878859 Latch for flow cassettes 880343 Valve, zero 58534 Valve, pressure *58534 Internal sampling tubings incl. system plate *880375 Absorber, Airway Module *880067 Damping chamber / Filter 880068...

  • Page 73: G-Ao Rev. 04, G-Aio Rev. 03, G-Aov Rev. 02, G-Aiov Rev. 02, G-O Rev. 00, G-Ov Rev. 00

    Those should be added separately according to the Airway module type and revision. The Flow cassette’s and their order numbers can be found listed in the section Gas sampling system. 6.1.6 S/5 G-AO rev. 06, G-AiO rev. 05, G-AOV rev. 04, G-AiOV rev. 04 Item Item description Order No.

  • Page 74: S/5 Panel Stickers

    Datex-Ohmeda S/5 Anesthesia Monitor Front panel sticker (small), item No. 17 Adaptation G-AO, G-AOV other modules Order No. Order No. -23- (Eng) 880376 880471 -26- (Fin) 888876 880471 -31- (Jpn) 888313 880471 -33- (Ger) 880546 880471 -40- (Spa) 884405 880471...

  • Page 75: Planned Maintenance (Pm) Kits

    S/5 Airway modules Front panel sticker (small), item No. 17 Adaptation S/5 G-AO, G-AOV other modules Order No. Order No. 8000202 8000204 8000193 8000204 8000192 8000204 8000196 8000204 8000199 8000204 8000194 8000204 8000197 8000204 8000389 8000204 8000201 8000204 8000195 8000204...

  • Page 76: Earlier Revisions

    Datex-Ohmeda S/5 Anesthesia Monitor EARLIER REVISIONS This manual supports all the other Airway Module revisions except the following ones. For further information on those revisions see corresponding manual. Revision Manual slot/main manual Note G-AO Module revision 01 Service Manual p/n 880850...
  • Page 77 APPENDIX A, Service check form, S/5 Airway modules APPENDIX A Document No. 800 1005-1...
  • Page 78 Datex-Ohmeda S/5 Anesthesia Monitor Document No. 800 1005-1...
  • Page 79 APPENDIX A, Service check form, S/5 Airway modules SERVICE CHECK FORM S/5 Airway modules Customer Service Module type Service engineer Date OK = Test OK N.A. = Test not applicable Fail = Test Failed All modules N.A. Fail N.A. Fail 1.
  • Page 80 Datex-Ohmeda S/5 Anesthesia Monitor 16. Flow rates Sampling flow 180-220 ml/min Side flow 10-27 ml/min meas. in flow 45-60 ml/min ref. in flow 25-42 ml/min absorber flow 180-220 ml/min 17. Pressures Amb-Work 50-75 mmHg OM (in-ref) > 4 mmHg 18. O sensor output voltage min.
  • Page 81 APPENDIX A, Service check form, S/5 Airway modules N.A. Fail N.A. Fail 24. Calibration gas I.D. Notes Patient spirometry option 25. Spirometry connectors 26. Spirometry leak test 26. Flow waveform 27. Spirometry tester Notes All modules 29. Fan filter 30. Electrical safety check 30.
  • Page 82 Datex-Ohmeda S/5 Anesthesia Monitor A-4(3) Document No. 800 1005-1...
