INDUSTRIAL DIRECT AND INDIRECT/DIRECT EVAPORATIVE COOLING
Engineer designed to satisfy your design requirements.
Modular Components
• Air Handling Modules in side, down or up
discharge and single or dual inlet design.
• Evaporative Media Modules with standard 8" or
Hi-Performance 12" media.
• Indirect Cooling Modules for added cooling
with no moisture added (optional).
Durable Construction
• Galvanized steel with our exclusive
POLYBOND® polyester epoxy powder
based coating ensures years of dependable
service.
Effi ciency
• Choice of media modules allows cooling
effi ciencies tailored to your design
requirements.
Dual Inlet
Models MD628, MS628, and MU628
Shown with 12" media modules DM120
Models UD980 and US980
Shown with 12" media modules UM120
AdobeAir, Inc. certifies that the evaporative air cooling products
shown herein are licensed to bear the AMCA Seal. The ratings
shown are based on tests and procedures performed in
accordance with AMCA Publication 211 and comply with the
requirements of the AMCA Certified Ratings Program.
Cost Effectiveness
• Competitive fi rst cost combined with substantial
energy savings over refrigerated air units results in
quick payback. Plus, the simplicity of design allows
low maintenance requirements.
Other Features
• Precision balanced blower wheel.
• Solid shaft for rugged durability.
• AdobeAir motors and pumps are U.L. Recognized.
• City of Los Angeles (C.O.L.A.) approved.
• AMCA Licensed ratings
• U.L. Classifi ed
• U.L. Listed
Single Inlet
U.L. Classified
Models MD524 and MS524
Shown with 12" media modules DM080
Models UD960 and US960
U.L. Listed
Shown with 12" media modules UM080
U.L. Classified
U.L. Listed
Advertisement
Related Manuals for AdobeAir MasterCool MD524
Summary of Contents for AdobeAir MasterCool MD524
-
Page 1: Other Features
Shown with 12” media modules DM120 Models UD980 and US980 Shown with 12” media modules UM120 AdobeAir, Inc. certifies that the evaporative air cooling products shown herein are licensed to bear the AMCA Seal. The ratings shown are based on tests and procedures performed in accordance with AMCA Publication 211 and comply with the requirements of the AMCA Certified Ratings Program. - Page 2 SINGLE-STAGE INDUSTRIAL EVAPORATIVE COOLING Direct Evaporative Cooling Process Direct evaporative cooling exchanges sensible heat for latent heat, and follows upward along a constant wet-bulb temperature line on the Psychrometric Chart. The result is a dry-bulb temperature of the leaving air (B) approaching the wet-bulb temperature of the...
- Page 3 Industrial MasterCool units. For more accurate sizing, and for sizing indirect/direct units, we recommend the use of KoolKalk... an IBM compatible computer program designed specifi cally for AdobeAir Evaporative Coolers. For more information please visit the AdobeAir, Inc. website at www.AdobeAir.com.
-
Page 4: Dimensions And Specifications
Note: Pumps are available in 115 volt and 230 volt models. As a result, transforming or separate circuiting may be required for other voltages. MD524 or UD960 (Down Discharge) and MS524 or US960 (Side Discharge) Side View Drain Media Blower... -
Page 5: Front View
Dual Inlet Model Dimensions Top View MD/MS/MU628 or UD/US980 Media Section Cabinet Duct Location Model Number 1 Required Side Down DM080 ½ ¾ ¾ ¼ ¾ or UM080 51 DM120 ½ ¾ ¾ ¼ ¾ or UM120 51 1. Drain is 3/4” male hose thread. 2. - Page 6 Certifi ed Air Delivery CFM at Various External Static Pressures Inches Water Gauge. AMCA Licensed Ratings. Operating Model Weight Quantity 524 with DM080 or 960 with UM080 — 8” Media ¾ 1½ 524 with DM120 or 960 with UM120 — 12” Media ¾...
- Page 7 5320 4850 4200 6080 5720 5280 7250 6930 6630 8140 7880 7590 9050 9050 9050 5170 4720 4070 5910 5540 5130 7040 6740 6430 7920 7650 7380 9050 9050 8820 8030 7380 6670 9700 9160 8600 10980 10510 10010 313 12960 12540 12130 345...
- Page 8 Your local MasterCool Representative of AdobeAir, Inc., is ready to assist you in unit selection and application. The world leader in evaporative cooling technology, AdobeAir, Inc. is continually involved in the process of product improvement. AdobeAir, Inc. therefore reserves the right to change specifi...
