Summary of Contents for Curv360 CURVRV01
- Page 1 CURVRV01 Instructions...
-
Page 2: Main Features
Wireless Radiator Valve Designed for independent controlled heating with remote monitoring via smart phone (requires Cürv gateway) and can be fitted to new or existing thermostatic radiator valves (TRV). Main Features • 7 days independent programming • Monitoring by phone •... -
Page 3: Technical Specification
Technical Specification Thermostat Type Programmable electronic radiator valve controller Power Supply 2 x 1.5V AA alkaline batteries Battery Life Up to 1 year (Lithium batteries recommended) Ambient Temperature 0°C ~ 50°C Storage Temperature Range -10°C ~ 60°C Accuracy ±0.5°C Dimensions L:85mm, Ø... - Page 4 Dimensions / Buttons and Display 22.0 C...
- Page 5 Dimensions / Buttons and Display Auto / Manual mode switch button Program / Date / Time set button Comfort / Economic temperature setting button Raise the temperature / time setting Lower the temperature / time setting Show when the controller is in Auto mode Show when the controller is in manual setting or holiday mode Show when the controller is in program setting mode Shows current set temperature or time clock...
- Page 6 Fitting the Radiator Valve Inserting / replacing the batteries (Please note: before you change the batteries, keep the valve completely open). Remove the battery cover and insert the two batteries. Ensure that the batteries are correctly inserted before use. After installing the batteries, the screen will display the software version, finally the symbol (TEST) will blink, and now the connector will retract entirely.
- Page 7 Mounting the RA and Caleffi adapter Tighten the RA adaptor using the screw. Tighten the Caleffi adaptor by hand. Screw the thermostat onto the adaptor and hand tighten (max.4.5mm).
- Page 8 Wireless Radiator Valve The Wireless Thermostat has been designed for independent zone controlled heating with remote monitoring via smart phone, if paired with Curv Gateway CURVWG01. It must be used in conjunction with existing thermostatic radiator valves (TRV). Default Temperature And Time Settings 1 - 7 To change the default temperature of day ( ), press the...
-
Page 9: Factory Reset
Factory Reset Press ‘PROG’ then hold ‘+’ and ‘-’ for 3 seconds. All programs will reset and the display will show ‘dEF’. This will reset all user settings to factory default. Low Battery Indicator When the battery is low, the screen will show “ “... -
Page 10: Program Settings
Program Settings You can set 2 high ( ) temperature modes and 2 low ( ) temperature modes for each day of the week that are numbered from 1 to 7 (Monday to Sunday) in the timer program. 1 - 7 To make the same setting for all 7 days of the week press the “PROG”... -
Page 11: Manual Operation
Manual Operation Press the “AUTO/MANU” button to switch to manual mode, press ‘+’ and ‘-’ to set the temperature. Press the “AUTO/MANU” button again to return to automatic mode. Temporary Override In auto operation, if you want to change the current program setting temperature press the “+”... -
Page 12: Open Window Function
Open Window Function If you open a window the temperature will drop dramatically. The TRV closes the valve to save energy. The screen will show the message “OPEN”, the radiator controller will reopen the valve when the temperature rises again or after 45 minutes. You can override this by pressing any button. - Page 13 Download The Free APP From Full Smart Control For smart control access, please combine this product with the Cürv Gateway CURVWG01. Power...
