TRP-C07
User's Manual
RS-422/485 Isolated Repeater
Printed Feb. 2007 Rev 1.1
Trycom Technology Co.,Ltd
1F, No.2-11,Sihu street ,Yingge Township, Taipei, Taiwan ROC
Tel: 886-2-86781191 , Fax: 886-2-86781172
Web: www.trycom.com.tw
Copyright
Copyright Notice: The information in this manual is subject to change without prior notice in order to improve
reliability, design and function and dosed not represent a commitment on the part of the manufacturer. No part of this
manual may be reproduced, copied, or transmitted in any form without the prior written permission of manufacturer.
Acknowledgment Products mentioned in this manual are mentioned for identification purpose only. Products manes
appearing in this manual may or may not be registered trademarks or copyright of their respective companies.
Advertisement
Table of Contents
Related Manuals for Trycom Technology TRP-C07
Summary of Contents for Trycom Technology TRP-C07
- Page 1 TRP-C07 User’s Manual RS-422/485 Isolated Repeater Printed Feb. 2007 Rev 1.1 Trycom Technology Co.,Ltd 1F, No.2-11,Sihu street ,Yingge Township, Taipei, Taiwan ROC Tel: 886-2-86781191 , Fax: 886-2-86781172 Web: www.trycom.com.tw Copyright Copyright Notice: The information in this manual is subject to change without prior notice in order to improve reliability, design and function and dosed not represent a commitment on the part of the manufacturer.
- Page 2 1. Introduction TRP-C07 is designed to extend the RS-422 and RS-485 signals to another 4000ft (1200m) distance and increase the maximum number of connected nodes up to 32 sets. Aside from extension function TRP-C07 provides with auto configuration features in data format detecting, baud rate setting and RS-485 data direction flow control.
- Page 3 2. TRP-C07 Hardware description 2-1. Panel Layout 2-2. TRP-C07 block diagram 2-3. LED indicators PWR LED: System is ready. RX LED: RS-422/485 receiving. TX LED: RS-422/485 transmitting.
- Page 4 3. Install TRP-C07 Connect power source with TRP-C07 The TRP-C07 has a two pins terminal block and power jack. Power can be supplied from terminal block or external power adapter and supports wide input range from +10~30V. When power is correctly supplied the PWR LED will lighting and indicate the system is up and running.
- Page 5 Trycom Technology Co., Ltd offers demo and test utility, these utilities may help user to demo and test TRP-C07 fast and easily. User may find the utilities in Trycom support CD or download from Trycom web www.trycom.com.tw. The testing utility includes.
- Page 6 The wiring connection is as below. Step1. Install TRPCOM utility. TRPCOM is a test utility which may help user to test TRP-C07 with RS485 device easily. Double click “Setup.exe”, the install Wizard will guide you to complete the installation. Step2. Configure COM port and baud rate, after configuration press “OK” to the next screen.
- Page 7 Step3.Send command “$01M” and press “Send”. Step4. Data response received. Test complete.
