AIR SEEDER PASTURE PLANTER A member of PASTURE PLANTER ASSEMBLY, OPERATORS & PARTS MANUAL GPN 215645 REVISION A 06/14 COPYRIGHT Neither this manual or part thereof may be reproduced or published without the prior permission of AF Gason Pty Ltd...
Fig. 1 Pasture Planter mounted on a Front Tow Air Seeder While every effort has been made to ensure the accuracy of the information in this manual, A.F.Gason Pty. Ltd. Reserves the right to delete, change or add information without notice.
If you DO NOT adjust hydraulic fittings while under feel you need help or advice on the operation of pressure. the Seeder, contact your local authorized Gason DO NOT remove any safety guards while the Dealer. seeder is operating.
BOLT SPECIFICATIONS Page 3 CAUTION: Loose bolts can cause elongation of holes and part failures resulting in dangerous operating conditions and equipment breakdown. Check all bolts and nuts periodically during equipment operation and keep them tightened to the specified torque. If hardware replacement becomes necessary, replace with equivalent metric grade number.
Subject to any applicable Federal, State or Territory laws or ordinances, which may apply from time to time, A. F. Gason Pty Ltd reserves the right to make changes in design and specifications without notice or obligation and to change or discontinue models at any time without incurring any liability to any Purchaser thereof.
The Combiner ‘Y’ System allows the operator to the rear row of the implement, light rates of seed combine product from the pasture planter into a can be evenly scattered across the ground. number or all of the main primary distribution hoses.
DISTRIBUTION KITS & FITMENT INFORMATION Page 8 Broadcast Distribution Fitment Connect the outlets of the primary manifold Instructions (refer fig. 7 and 8.) (Item 29) to the secondary manifold support pipes (Item 22) using the 25mm grey hose Attach the primary manifold support and (Item 10).
Page 13
DISTRIBUTION KITS & FITMENT INFORMATION Page 9 Fig. 8 Pasture Planter Broadcast Distribution System Note: Refer to spare parts section for all part numbers DISTRIBUTION SYSTEM COMPONENTS SUPPLIED IMPLEMENT WIDTH PRIMARY SECONDARY SEED SPREADER GPN: MANIFOLD MANIFOLD SPREADER EXTENSION (ITEM 29)
This central location will reduce supplied by the owner or to a dedicated the length of the 25mm secondary hose Gason sowing boot with the aid of an that needs to be routed across the adaptor (item 7). machine.
2. Ensure any open 25mm inlet pipes on the Combiner ‘Y’s are capped with the supplied If operators are wishing to combine material from the pasture planter down all of the black plastic cap (item 6). Two are supplied tines on a single shoot system, they would select with each kit.
Disengaging Pasture Planter – Ground Drive Planter if required. Only Contact your Gason dealer for specific When the pasture planter is not in use, set the information about Pasture Planters air flow. variator to zero. This effectively disengages the metershaft.
Step 3. Fit wing nut and tighten and then refit window assembly. To achieve very low rates with small seeds a reducer plate is fitted to the Pasture Planter meterbox. This reduces the meterwheels output to approximately 1/3. The following steps are for fitment of the reducer plate, removal is a reversal of this procedure.
Pasture Planter Meterbox - Adjustments Page 14 Removal of Meterwheel Cover Plate It may be necessary to remove the meterwheel cover plate from inside of the meterbox for lightweight and large seed if high rates are required. To remove the cover plate you will need to have the bin empty.
For more detail on calibration refer: Air Seeder Operator’s Manual, Ground Drive – Calibration. When calibrating, ensure that there is enough material in the Pasture Planter Bin. In most cases 1/2 a bag will be sufficient. Fig.17 Bottom door on pasture planter.
Page 20
Ground Drive - Calibration Page 16 Step 4. Rotate calibration handle for the correct number of turns to simulate 1/20 of a NOTE: It is recommended that when adjusting hectare (see table page 14). Rotate the variator setting the operator goes past the handle anti-clockwise.
Page 21
For this example operator to mark the position of the variator we find we have a seed collection of: handle after the pasture planter has been calibrated. The stop will be a useful tool to Seed collected = 0.16kg...
Pasture the ‘RESET’ key twice to clear previous trip Planter although some points may differ. information. The Pasture Planter bin on the 3000 Canlink monitor is shown as AUX. Calibration Procedure 1. It may be necessary to make adjustments to the pasture planter meterbox when metering low or high rates of seed.
Page 26
VRT Hydraulic Drive – Calibration Page 22 b) Open the bottom door on the Pasture Planter meterbox. c) Fit the calibration sample bag to the bottom of the Pasture Planter meterbox. d) Prime the system to ensure that the new product is fully surrounding the meterwheels.
Page 27
You can change the status of each bin by holding the soft key directly to the left of the product down for 3 seconds. NOTE: If a product has previously been calibrated in the pasture planter bin but for a NOTE: After completing calibration different trip, a pulses/kg figure will be displayed.
Page 43
P/Planter Adjustment Assembly Page 39 ITEM PART NUMBER DESCRIPTION QTY. 1/8” Rivet S/S Sealed (not required with current decal) 207095 Ref. DU Bush ½” X 3/8” Long 207613 211411 Contour Grip 19 ID X 100mm 215567 Knob 4 Star M8 Through Decal –...
Page 44
Distribution System - Broadcast Page 40 ITEM PART NUMBER DESCRIPTION QTY. 209050 Spreader Kit P/Planter 208994 Spreader Plate 209035 Clamp Plate-Spreader Hose 213801 U Bolt M10 Suit 100 X 100 903406 Nut Nyloc M10 Cl8 (AS1285 906404 Washer Flat 3/8x3/4x16Gzp 209051 Extension Kit Spreader 209044...
Page 45
Distribution System - Broadcast Page 41 211281 Support Pipe Sec. Low 221373 Bracket Support 902301 Nut M8 917309 Screw Set M8 X 25 X 1.25 215333 Manifold Sec - 5 Port P/Planter (Standard) 215894 Manifold Sec - 4 Port P/Planter (Option) 215896 Manifold Sec - 6 Port P/Planter (Option) 208999...
Page 46
Distribution System – Individual Placement Page 42 ITEM PART NUMBER DESCRIPTION QTY. 215663 Manifold P/P Dia51-3 Port 215664 Manifold P/P Dia51-4 Port 215665 Manifold P/P Dia51-5 Port 215666 Manifold P/P Dia51-6 Port 215667 Manifold P/P Dia51-7 Port 215668 Manifold P/P Dia51-8 Port 215669 Manifold P/P Dia51-9 Port 215670...
Page 47
Distribution System – Combiner ‘Y’ Page 43 ITEM PART NUMBER DESCRIPTION QTY. Kit Manifold Support – Std. 51 Dia. 213628 215663 Manifold P/P Dia51-3 Port 215664 Manifold P/P Dia51-4 Port 215665 Manifold P/P Dia51-5 Port 215666 Manifold P/P Dia51-6 Port 215667 Manifold P/P Dia51-7 Port 215668...
Page 78
Mount Kit – 2120/50FT (600L) Page 74 Post Nov. 2011 ITEM PART NUMBER DESCRIPTION QTY. 203914 Screw Tek 14-20 x 22mm 205828 Buffer - Black Rubber Mushroom 206274 Bolt M12x170 Gr.8.8 Z/P 206309 Washer Flat M6 X 12.7 Z/P 207095 Rivet Seal S/S 1/8"...
Page 79
Mount Kit – 2120/50FT (600L) Page 75 209115 Front Platform Support 209116 Floor Panel Assy 211198 Hose 25mm Grey Suction Ref. 211293 Hose 50mm Grey Suction 211761 Handle - Bin 1220/30 Air Seeder 215540 Meterbox Assembly Ref. 215541 Gasket - M/Box To Bin Ref.
Page 80
Mount Kit – 2120/50 LQ (600L) Page 76 Post Nov. 2011 06/14...
Page 81
Mount Kit – 2120/50 LQ (600L) Page 77 ITEM PART NUMBER DESCRIPTION QTY. 203914 Screw Tek 14-20 x 22mm (CAD) Ref. 204791 Decal - Grease Gun Ref. 207095 Rivet Seal S/S 1/8" Ref. 207955 Clamp Hose No1 Ref. 211198 Hose 25mm Grey Suction Ref.
Page 82
Mount Kit – 2120/50RT (380L) Page 78 Pre Nov. 2011 ITEM PART NUMBER DESCRIPTION QTY. Support – Rear 211369 211372 Platform Assembly 220239 Support L/H 2150 Ref. 220267 Support L/H 2120 SR Ref. 220240 Support R/H 2150 (Not Shown) Ref. 220268 Support R/H 2120 (Not Shown) Ref.
Page 83
Ref. 1/8” Rivet S/S Sealed 207095 Ref. 8001095 Tek Screw 907413 Washer Flat M10 X 30 X 3 Meterbox Assy – Pasture Planter 215540 Ref. 215485 Bin Assembly Ref. Hose Clamp – Worm NO.3 811195 Connector 2” BSP X 2” Brass 215652 Ref.
Page 84
Mount Kit – 2120/50FT (380L) Page 80 Pre Nov. 2011 ITEM PART NUMBER DESCRIPTION QTY. Ladder – Lower Extended 217886 Plate – Door Holder Mount 209102 220239 Support L/H 2150 Ref. 220267 Support L/H 2120 SR Ref. 220240 Support R/H 2150 (Not Shown) Ref.
Page 85
907201 Washer Flat M6 X 25mm 903202 Nut Nyloc M6 917203 Set Screw M6 X 25 203914 Tek Screw 12-20 X 22mm Meterbox Assy – Pasture Planter 215540 Ref. 215485 Bin Assembly Ref. Ball – Valve 2" Brass 215651 Ref.
Page 86
Ground Drive Kit – 1730/50-1830/50RT Page 82 ITEM PART NUMBER DESCRIPTION QTY. 215700 Variator Support 215701 Cover Plate Variator Adjustment 215493 Clamp Plate Variator Adjustment Stop – Variator Adjustment 215660 215658 Lock Bolt - Variator Adjustment Roll Pin 1/8” X 5/8” 811421 Washer –...
Page 87
Ground Drive Kit – 1730/50-1830/50RT Page 83 ITEM PART NUMBER DESCRIPTION QTY. 215659 Knob - Variator Adjustment Decal – Calibration 215703 1/8” Rivet S/S Sealed 207095 907203 Washer Flat M6 X 20mm 903202 Nut Nyloc M6 917605 Set Screw M12 X 40mm 207468 Bearing Assy Pillow Block 215699...
Page 88
Ground Drive Kit - 1850FT Page 84 ITEM PART NUMBER DESCRIPTION QTY. 215843 Variator Support 215701 Cover Plate Variator Adjustment 215493 Clamp Plate Variator Adjustment Stop – Variator Adjustment 215660 215658 Lock Bolt - Variator Adjustment Roll Pin 1/8” X 5/8” 811421 Washer –...
Page 89
Ground Drive Kit - 1850FT Page 85 1/8” Rivet S/S Sealed 207095 907203 Washer Flat M6 X 20mm 903202 Nut Nyloc M6 Cl8 917605 Set Screw M12 X 40mm 207468 Bearing Assy Pillow Block 208461 Lay Shaft 917404 Set Screw M10 X 30mm GR8.8 Clamp Plate –...
Page 90
Ground Drive Kit - 1860 Page 86 ITEM PART NUMBER DESCRIPTION QTY. 217601 Variator Support 217602 Cover Plate Variator Adjustment 215493 Clamp Plate Variator Adjustment Stop – Variator Adjustment 215660 215658 Lock Bolt - Variator Adjustment Roll Pin 1/8” X 5/8” 811421 Washer –...
Page 91
Ground Drive Kit - 1860 Page 87 1/8” Rivet S/S Sealed 207095 907203 Washer Flat M6 X 20mm 903202 Nut Nyloc M6 CL8 917605 Set Screw M12 X 40mm 207468 Bearing Assy Pillow Block 208134 Lay Shaft Grub Screw ¼” UNC X ½” Long 923202 Clamp Plate –...
Page 101
VRT Drive Kit - 1880/90 & 2120/2150 Page 97 QTY. ITEM PART NUMBER DESCRIPTION 1880/90 2120/50 211422 Motor Hydraulic VRT Seeder 210687 Sprocket 13T X 26P Target 210666 Sensor Prox. 12mm 215734 Support Bracket - Hydraulic Motor VRT 210527 Mount Bracket - Hydraulic Motor VRT 913610 Bolt M12 x 35 Hex Z/P 8.8 903605...
Page 102
VRT Drive Kit- 2120/2150 LQ Page 98 Refer Page 96 for Fitment Instructions of Hydraulic Components ITEM PART NUMBER DESCRIPTION QTY. 207457 Sprocket-14T Nylon x 15.875 ID 207476 Key Steel 1/4" x 1/4" x 25mm 207477 Key Steel 3/16" x 3/16" x 25mm Nip.
Page 103
VRT Drive Kit- 2120/2150 LQ Page 99 ITEM PART NUMBER DESCRIPTION QTY. 211422 Motor Hyd. VRT Seeder 212601 Hose Assy - 1/2" x 3800mm 215540 Meterbox Assembly Ref. 903406 Nut Nyloc M10 Cl8 903605 Nut Nyloc M12 Cl8 907413 Washer Flat 10 x 30 x 3 Z/P 913610 Bolt M12 x 35 Hex Z/P 8.8 917404...
Page 104
VRT Drive Kit- 2170/2210 FT Page 100 Refer Page 96 for Fitment Instructions of Hydraulic Components ITEM PART NUMBER DESCRIPTION QTY. 207457 Sprocket - 14t Nylon X 15.875 Id 207476 Key Steel 1/4" X 1/4" X 25mm 207477 Key Steel 3/16" X 3/16" X 25mm 207586 Nipple 1/2BSPPM X 3/4JICM 208302...
Page 105
VRT Drive Kit- 2170/2210 FT Page 101 ITEM PART NUMBER DESCRIPTION QTY. 903406 Nut Nyloc M10 Cl8 As1285 903605 Nut Nyloc M12 Cl8 As1285 906301 Washer Flat 5/16 x 7/8 x 16 ZP 907303 Washer Flat M8x19 Harden Z/P 907400 Washer Flat 18x10x1.2mm 907413 Washer Flat M10x30x3 Z/P...
