Rebound Damper (Rear Suspension); Compression Damper (Rear Suspension) - AGUSTA Turismo Veloce 800 LUSSO User Manual

5
ADJUSTMENTS

5.8.2. Rebound damper (rear suspension)

The adjustment is obtained from the reference
position, which is found by fully turning the screw
clockwise and then counterclockwise until you
reach the standard position (see enclosed table).
Rotate clockwise to increase the damping action
or counterclockwise to decrease it.
5

5.8.3. Compression damper (rear suspension)

The adjustment is obtained from the reference
position, which is found by fully turning the screw
clockwise and then counterclockwise until you
reach the standard position (see enclosed table).
Rotate clockwise to increase the damping action
or counterclockwise to decrease it.
- 118 -
