- Page 1 ProCart II Mobile Treatment Console OPERATION MANUAL © Copyright 2011 DNTLworks Equipment Corporation 09/20/2011 All Rights Reserved DNTLworks Equipment Corporation 7300 South Tucson Way Centennial, Colorado 80112 USA Toll Free: (800) 847-0694 Main: (303) 693-1410 Fax: (303) 693-6189...
-
Page 2: Table Of Contents
Contents Introduction ..............................3 Customer Service ............................4 DNTLworks Limited Warranty ........................4 Returns ..............................5 Description of Unit ............................5 Air System ..............................5 Water System ............................5 Vacuum System ............................5 Electrical System ............................5 Specifications ..............................5 Unit Features .............................. -
Page 3: Introduction
Compressor Will Not Recycle or Stalls ....................33 Introduction Thank you for purchasing the ProCart II Mobile Treatment Unit from DNTLworks Equipment Corporation. The information contained in the manual should answer any questions regarding service and operation of your ProCart II unit. -
Page 4: Customer Service
Customer Service In the event you require assistance with your unit, please call 1-800-847-0694 or 303-693-1410 and speak with one of our customer service representatives. Our service hours are from 8:00 a.m. to 5:00 p.m., Mountain Standard Time, Monday through Friday. In most instances, service problems may be solved over the telephone. -
Page 5: Returns
to, any interruption of services, loss of business or anticipatory profits or consequential damage arising out of or connected with the sale, lease, use, or anticipated use of equipment. Notwithstanding the above limitations and warranties, DNTLworks liability hereunder for damages incurred by customer or other will not exceed the amount paid by customer for the particular equipment involved. -
Page 6: Unit Features
Width 21” (53cm) Adjustable Height 30” (76cm) to 34” (86cm) Total Weight 100lbs (45.5 Kg) Electrical Voltage 115 or 220Vac Frequency 60 or 50 Hz Wattage 1200 to 1440 W Compressor Horsepower 1/3 Hp Working Pressure 70 to 100psi Flow Rate 2.5scfm @ 40psi Air Tank 1 Gallon (4 Liter) -
Page 7: Front View
Front View Air/Water Syringe Saliva Ejector Handpiece Tubings Handpiece Water Adjustment Knobs Water Toggle Foot Control... -
Page 8: Back View
Back View Power Switch Circuit Breaker Air/Water Accessory QD’s Accessory Outlet Outlet Air Tank Purge Power Receptacle Waste Purge Power Cord & Waste Purge Line Cooling Fans... -
Page 9: Operation
Operation Setup Place foot control near Install handpieces. the operator. Plug power cord into power receptacle and into wall outlet. Install saliva ejector Make sure the ProCart II tip. Install HVE tip. is the only unit on the circuit. Connect waste Turn on power purge tubing. -
Page 10: Handpiece Operation
Remove handpiece from holder. Depress foot control and adjust handpiece water. Test air and water Repeat for other on syringe. handpieces. Turn toggle on holder Remove HVE or saliva to the ON position. ejector from holder. Handpiece Operation Remove handpiece from holder. -
Page 11: Three-Way Syringe
Three-way Syringe Water only. Air only. Air and water (mist). You can use disposable syringe tip kits. (A-dec type disposable tip kit) Always clean syringe between patients. See Dental Office Infection Controls Guidelines CDC, below. Vacuum System When using either saliva ejector or HVE, make sure the other valve is closed. - Page 12 Never adjust vacuum relief valve. When using saliva ejector, vacuum relief valve will have an air leak sound. Purge Vacuum System Make sure purge tubing is installed. Always clean vacuum system between patients. See Dental Office Infection Controls Guidelines CDC, below. To clean vacuum system, use a non-foaming vacuum system cleaning solution.
-
Page 13: Water Bottle
Water Bottle Depress red pressure relief valve. Disconnect red air line. Make sure o-ring is not missing and is seated in the groove. Lubricate o-ring as Disconnect blue water line. needed. Fill about 3/4 full. We recommend distilled water Reconnect only. -
Page 14: Dental Office Infection Control Guidelines (Cdc)
The outside outlet is used for external accessories use. Never use more than 2 amps between the inside and outside outlets. The air 1/4”QD is used for accessories that require air. The pressure will be between 70 to 100psi. The accessory should not be used at the same time you are using one of the handpieces. -
Page 15: Cleaning And Disinfection Of Dental Unit And Environmental Surfaces
Reusable and/or disposable gowns, laboratory coats or uniforms should be worn when street clothing may be soiled with blood or other body fluids. Gowns should be changed at least daily or when visibly soiled with blood. Cleaning and Disinfection of Dental Unit and Environmental Surfaces After treatment of each patient and at the completion of daily work activities, countertops and dental unit surfaces that may have become contaminated with patient material should be cleaned with disposable toweling, using an appropriate cleaning agent and water as necessary. -
Page 16: Other Important Issues
Highspeed handpieces should be run to discharge water and air for a minimum or 20-30 seconds after use on each patient. Handpieces, in addition, should be heat sterilized between uses on patients. This procedure is intended to aid in physically flushing out patient material that may have entered the turbine and air or water lines. - Page 17 Place handpieces over container and depress foot control until all water is purged. Open all water valves. Remove all Depress syringe handpieces and water button until vacuum all water is purged. attachments. Mix non-foaming vacuum cleaning solution and run solution through HVE valve.
- Page 18 Turn on waste Wipe water purge. container dry. Turn off power switch. Place paper towel under air regulator bowl. Depress pin valve at the bottom of bowl to drain moisture. Unit must be pressurized. Depress tank purge valve Place air tank until all air (red) purge line and moisture...
-
Page 19: Maintenance
Maintenance The following visual checks should be performed before operating the unit: 1) Look for mechanical damage that could affect safe operation, including, but not limited to, the following: a. Cracks in power cord. b. Splits or kinks in air or water lines. c. -
Page 20: Electrical Diagram
Electrical Diagram... -
Page 21: Air Diagram
Air Diagram... -
Page 22: Water Diagram
Water Diagram... -
Page 23: Vacuum Diagram
Vacuum Diagram... -
Page 24: Back, Inside View
Back, Inside View Air/Water Accessory QD’s Power Switch Circuit Breaker Accessory Outlet Air Tank Purge Power Receptacle Waste Purge Cooling Fans... -
Page 25: Pumps, Inside View
Pumps, Inside View Mufflers Compressor Pump Vacuum Pump Check Valve Solenoid Capacitors... -
Page 26: Air And Vacuum Tanks, Inside View
Air and Vacuum Tanks, Inside View Vacuum... -
Page 27: Shelf, Inside View
Shelf, Inside View Inside Outlet Waste Purge Pump Pressure Switch Timer Solid State Relay... -
Page 28: Control Panel, Inside View
Control Panel, Inside View Handpiece Pressure Water Regulator Tri-Block Vacuum Solids Trap Air Regulator Water Relay Inside Outlet Regulator Bowl Regulator Drain Port Caution The air regulator is factory set. Adjusting this knob may damage the compressor system and void the DNTLworks Equipment Corporation unit warranty. -
Page 29: Troubleshooting Flow Charts
Troubleshooting Flow Charts Handpiece Water Check for full water container. Check QD’s on water container. Check QD’s on water container. Check foot control toggle is on. ater container. Check needle valves are open. Depress red button on water container to Go To Air System Flow Chart. -
Page 30: Syringe Water
Syringe Water Check water container is full. Check QD’s on water container. Depress red button on water Go To Air System Flow Chart. container and check for air. Adjust water regulator. Turn knob up and down several times. Done Check water on syringe. Change syringe tip. -
Page 31: Waste Leak
Waste Leak Vacuum Pump Shelf Check vacuum solids trap Purge unit. for missing plug and cracks. Suction water into unit and check for leakage. Check back panel waste purge bulkhead connection. Clean vacuum container. Flush again. Check float balls and gasket. Check bulkhead, collets, o-ring and stem barb for cracks. -
Page 32: Compressor Will Not Shut Off Or Will Recycle Often
Compressor Will Not Shut Off or Will Recycle Often Use soapy water to Check for air leaks. help locate leaks. Listen to foot control for air leaks. Check handpiece holders for leaks. Air regulator relief hole under locking knob. Regulator bowl and tees close to air regulator. QD’s on back panel and control panel. -
Page 33: Compressor Will Not Start
Compressor Will Not Start Check power cord is plugged into wall and unit. Check power switch is on and lighted. Check to see if air tank is empty. Check circuit breaker. Are cooling fans working. Open back door. Check back panel Open back door.
