Looping
You have up to 8 loops per track in Serato DJ, and the choice between either
manual or auto loops. You can choose whether you have 4 loops (and 4 cuepoints)
showing on screen, or 8 loops. To switch between Manual and Auto looping, click
(Manual) or (Auto) onscreen. You can also half or double the loop length in
either manual or auto modes. Press the 1/2X button to half the loop legnth, hold the
2X button to double the loop legnth, or you can use the Loop Legnth Knob to do
the same.
NOTE The IN/OUT buttons are shift functions of the 1/2X and 2X buttons. You will
need to hold SHIFT while pressing these buttons to use IN/OUT for manual loops.
Manual Mode
Reloop Terminal Mix 4 Control
1/2X + SHIFT
1/2X + SHIFT
2X + SHIFT
2X + SHIFT
Loop Length (Click Knob)
NOTE The best way to edit the in and out points of a manual loop is with the jog
wheel/platter on your Reloop Terminal Mix 4.
Auto Mode
Reloop Terminal Mix 4 Control
Loop Length (Click Knob)
Loop Length (Twist Knob)
NOTE You can also save a loop to the next available free loop slot in the software.
To do this, either click the button in the manual/auto loop tab or click
available loop slot. Your loops are saved to the file and recalled the next time it is
loaded. They are not lost if the file is moved or renamed.
Serato DJ Function
Set loop in point (Loop not active)
Adjust loop in point (Loop active)
Set loop out point (If loop in point is set)
Adjust loop out point (Loop active
Exit Loop (Loop Active)
Serato DJ Function
Auto Loop ON/OFF
Half Auto Loop Length
DJ-FX
The DJ-FX in Serato DJ are powered by iZotope™. Click the FX tab
to open the FX panel. Select either 1, 2 or M in the Deck Assign area
to assign the selected effect bank to a deck or Master Output. To activate an effect,
click the ON button on your FX UNIT in the software, or the FX1 ON button on your
controller. You can adjust effect parameters by using either software controls, or
the FX1/FX2/FX3 knobs/buttons on the controller.
Reloop Terminal Mix 4 Control
FXSEL1 Button
SHIFT + FX1-3 Button
FX1 Knob
FX2 Knob
FX3 Knob
FXSEL 2 Button
FXSEL 3 Button
The effect time is set using the tracks BPM value, but by applying the Beats
Multiplier you can increase or decrease the effect timing. Modify this by using the
BEATS knob on the controller. Automatic tempo requires that the track on the deck
assigned to the FX Unit has BPM information. Manual tempo mode allows you to
tap in the tempo yourself.
NOTE To change to MANUAL mode, simply tap the TAP button until a desired rate
is established. To return to AUTO mode, click and hold TAP for 1 second.
Reloop Terminal Mix 4 Control
TAP (Button) hold for 1 second
Tap the TAP (Button) to the desired rate
on an
BEATS
Serato DJ Function
Effect On/Off
Choose Effect
FX Dial 1
FX Dial 2
FX Dial 3
FX Button 1
FX Button 2
Serato DJ Function
Auto
FX Tap Tempo
Beats Multiplier Dial
