COBHAM AEM AA35-001 Quick Start Manual

Audio mixer panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Digitally signed by Barb Page
Date: 2020.02.12 11:25:07 -07:00
Reason: Certify Document
Location: Prescott Arizona, USA
SPECIAL NOTICE
Ownership of this product has been transferred to Cobham Aerospace Communication
from Anodyne Electronics Manufacturing (AEM) and Northern Airborne Technology
(NAT). Cobham is responsible for all matters related to this product, including sales,
support and repair services.
Please note the transition to convert product manuals and supporting documentation is
an ongoing process and is being addressed on an 'as needed' basis.
All references to AEM and NAT product part numbers (and associated images) are
equivalent to Cobham product part numbers.
Contact info:
Cobham Aerospace Communication,
6400 Wilkinson Drive, Prescott, Arizona, 86301.
Telephone: (928) 756-1615 or refer to the following website:
www.wulfsberg.com
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number(ECCN) EAR99. When exporting, diversion contrary to U.S. law is prohibited.
for more information.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEM AA35-001 and is the answer not in the manual?

Questions and answers

Summary of Contents for COBHAM AEM AA35-001

  • Page 1 Ownership of this product has been transferred to Cobham Aerospace Communication from Anodyne Electronics Manufacturing (AEM) and Northern Airborne Technology (NAT). Cobham is responsible for all matters related to this product, including sales, support and repair services. Please note the transition to convert product manuals and supporting documentation is an ongoing process and is being addressed on an ‘as needed’...
  • Page 2 This document contains confidential and proprietary information and is the property of Chelton Avionics, Inc., a subsidiary of Cobham plc. It is to be provided in confidence on the condition that by receipt it is not reproduced or copied in whole or in part, or used to furnish such information to others, or to make use of it for purposes other than specified by the Usage Statement.
  • Page 3 SM25 AA35-001 Audio Mixer Panel INSTALLATION AND OPERATION MANUAL Rev: 2.00 May 8, 2012 Anodyne Electronics Manufacturing Corp. 15-1925 Kirschner Road Kelowna, BC, Canada. V1Y 4N7 Telephone (250) 763-1088 Facsimile (250) 763-1089 Website: www.aem-corp.com © 2012 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
  • Page 4 AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual COPYRIGHT STATEMENT © 2012 Anodyne Electronics Manufacturing Corp. (AEM), All Rights Reserved This publication is the property of AEM and is protected by Canadian copyright laws. No part of this document may be reproduced or transmitted in any form or by any means including electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AEM.
  • Page 5 AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual Prepared By: Checked By: Approved By: Loen Clement Tom Betzelt Tony Pearson Product Support Designer Designer Manager May 8, 2012 Jun 06/12 June 11, 2012 The status of this installation and operation manual is controlled by the revision shown on the title page. The status of each section is controlled by revision shown in the footer of each page.

  • Page 6: Table Of Contents

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual Table of Contents Section Title Page Description Introduction Purpose of Equipment Design Features Specifications 1.4.1 Electrical Specifications 1.4.2 Physical Specifications 1.4.3 Environmental Specifications Unit Nomenclature Installation Introduction Unpacking and Inspection 2.2.1 Warranty Continued Airworthiness Installation Procedures...

  • Page 7: Description

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual Section 1.0 Description Introduction Information in this section consists of product description, design features and specifications for the AA35-001 Audio Mixer Panel. All derivative product information shall be contained in the applicable manual supplement, which may be obtained from AEM as required.

  • Page 8: Physical Specifications

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual Input Signals Channels 6 independent channels Impedance 4.0 kΩ +/- 10% Audio level 2.5 or 7 Vrms. Selectable by DIP switch Circuitry Type Differential input for high common mode noise rejection Coupling <-40 dB input to input Crosstalk Output Signals...

  • Page 9: Environmental Specifications

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual 1.4.3 Environmental Specifications Operating Temperature -45 C. to +70 C Survival Temperatures -55 C. to +85 C Humidity Altitude 35,000 feet max Vibration/Shock DO-160C, Cat. N/B/M Unit Nomenclature These products are included for reference only. For more detailed information on these and other AA35 products, contact the Product Support Department at AEM.

  • Page 10: Installation

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual Section 2.0 Installation Introduction Information in this section consists of unpacking and inspection procedures, installation procedures, post- installation checks and installation drawings for the AA35-001 Audio Mixer Panel. Review all notes, warnings and cautions. Unpacking and Inspection Unpack the equipment carefully.

  • Page 11: Cautions

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual 2.4.2 Cautions CAUTION: Do not bundle any lines from this unit with transmitter coax feedlines. Do not bundle any logic, audio, or DC power lines from this unit with 400 Hz synchro wiring or AC power lines.

  • Page 12: Adjustments And Connections

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual 2.4.4.2 Power On Checks Power up the aircraft’s systems and confirm normal operation of all functions of the AA35-001. Refer to Section 3.0 (Operation) for specific operational details. Check for the correct audio output on each channel. Upon satisfactory completion of all performance checks, make all required log book entries, electrical load, weight and balance amendments and other documentation as required by your local regulatory agency before releasing the aircraft for service.

  • Page 13: Composite Output Level Adjustment

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual 2.5.3 Composite Output Level Adjustment The output level of the composite audio can be adjusted from the right hand side of the AA35. Rotating the trim potentiometer from fully counter clockwise to clockwise will increase the output over a 40 dB range.
  • Page 14 These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification Control Number(ECCN) EAR99. When exporting, diversion contrary to U.S. law is prohibited.
  • Page 15 These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification Control Number(ECCN) EAR99. When exporting, diversion contrary to U.S. law is prohibited.
  • Page 16 2.00 OCT 25/11 RAS #8 - CHANGED TO AEM LOGO, UPDATED HOLE SCHEDULE. AA35 MAX OFF KELOWNA BC CANADA (250)-763-1088 WWW.AEM-CORP.COM Oct 25/11 27 Oct/11 AUDIO MIXER PANEL SIZE AA35-001 2.00 L9015 These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification 905-0 SHEET 1 of 3...
  • Page 17 PRODUCT LABEL Reviewed/Approved Date Initial Tony Pearson 03/07/2011 Designer Mar 7, 2011 Reviewed/Approved Tony Pearson Designer Oct 27, 2011 NAT LOGO REMOVED RAS# 8 AEM LOGO ADDED These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification Control Number(ECCN) EAR99.

  • Page 18: Operation

    AA35-001 Audio Mixer Panel SM25 Installation and Operation Manual Section 3.0 Operation Introduction Information in this section consists of the functional and operational procedures for the AA35-001 Audio Mixer Panel. General Information The AA35-001 Audio Mixer Panel is a six channel summing amplifier with independent level control for each input.
