- Page 1 AI-70 / AI-100 / AI-120 Quick installation guide Schnellinstallationsanleitung Snelle installatiehandleiding Wall Speaker Wandlautsprecher Wandluidspreker...
- Page 2 Package Contents Lieferumfang Inhoud verpakking ø3.0 x 30mm ø3.0 x 12mm 2 x 3m A. 2 x Speakers B. Wall Bracket C. Wall screw D. Speaker screw E. Wall plug F. Speakercable (2 x 3m) G. Manual H. Wall installation template I. Cable lug A.
- Page 3 Wall speaker installation method How to install the wall speaker Before mounting the wall speakers on the wall, please plug in the speakercables (See next pages). Lautsprecher Installationsmethode Installation des Wandlautsprechers Bevor Sie die Wandlautsprecher an die Wand montieren, schließen Sie bitte die Lautsprecherkabel an (siehe nächste Seiten).
- Page 4 Wall bracket installation Wandhalterung installation Muurbeugel installatie 2. Drill the holes in the wall 2. Bohren Sie die Löcher in die Wand 2. Boor de gaten in de muur 1. Please keep the “wall installation template” to the wall where you want to mount the speakers and mark the screw position on the wall.
- Page 5 Speakercable installation Lautsprecherkabel installation Luidsprekerkabel installatie When using the Fred crossover lter* connect the other end of the speaker cables to the "OUT-L" (left speaker) and "OUT-R" (right speaker). Use the plugs supplied with the lter and pay attention to the polarization. If you have an ampli er with a built-in crossover lter, you can connect the cables directly to the ampli er.
- Page 6 ø3.0 x 12mm 2. Insert the screw to the wall speaker & bracket hole, then using a screwdriver to x it tighten. 1. Insert the wall speaker softly between the brackets in the direction of the arrow. 2. Führen Sie die Schraube in die Wandlautsprecher- 1.
