Wildlife Materials International TRX-1000S Quick Start Manual

TRX – 1000S RECEIVER UNIQUE INFORMATION

Important precautions:

• Do NOT expose to water, fire or excessive dust. The aluminum box is water
resistant, but the interior is NOT guaranteed waterproof. In rain, snow, fog, etc.,
please cover the receiver, place inside a plastic bag or use it only inside a vehicle.
Water inside the receiver will void the warranty.
• Before the DC external power cord is used, turn the receiver off. Always insert the
cord's plug in to the receiver's DC external power jack before plugging the cigarette
lighter cord into a vehicle. Failure to follow this procedure can cause the fuse in the
cigarette lighter power plug to blow.
• Do not charge batteries for more than 24 hours.
Operation: Please see the "Operation & Tips For Your Radio Recovery Equipment"
sheet for general operating instructions.

Unique Instructions:

1. Turn the POWER SWITCH to INT for internal battery usage, or to EXT for
external power source. If the DC external power cord will be used, insert the cord's
plug in to the receiver's DC external power jack before plugging the cord's cigarette
lighter end into a vehicle.
2. Preset the GAIN control to "12 o'clock" position.
3. Preset the A E Tune to 0 position.
4. Dial the desired frequency of a transmitter on the 3 FREQUENCY SWITCHES.
Push the small buttons marked with "+" or "-" until numbers represent the last 3
digits in the transmitter frequency. Example- A transmitter marked 217.650 would
require the switch number to register 650.
5. Attach antenna cable to ANTENNA JACK by pushing the cable's connector plug
down and twisting clockwise to the right until it clicks into place.
6. Activate transmitter now. You should hear a beeping signal through the receiver's
speaker.
7. A E Tune can now be adjusted to give the most pleasant tone.
8. Advance the GAIN control slowly in a clockwise motion only as far as necessary to
receive a clear signal. Keep the GAIN as low as possible while locating.
9. If the signal sounds loud or distorted, turn the GAIN control counterclockwise until
the signal is clear and acceptable in volume.
10. If the A E Tune control cannot bring in the signal clearly and with a pleasant pitch,
the last FREQUENCY SWITCH on the right can be moved up or down 1–2 digits
TRX-1000S RECEIVER 1 of 4
