Clothes Rail With Lower Swing Out Rail
Assembly Instructions -
359/1815
Please keep for future reference
Dimensions
Width - 84cm
Depth - 44cm
Height -
113-187.5cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Issue 1 - 12/11/2014
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 359/1815
Summary of Contents for Argos 359/1815
- Page 1 Clothes Rail With Lower Swing Out Rail Assembly Instructions - 359/1815 Please keep for future reference Dimensions Width - 84cm Depth - 44cm Height - 113-187.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce components and tools listed on or put weight on the product, the likelihood of the following pages.
-
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: 03456 400800 Please check you have all the fittings listed below Black Coated Tube x 1(872 mm) Black Coated Tube x 1 (900 mm) Black Coated Tube x 1 (968 mm) Chrome Plated Tube x 2 (840 mm) Chrome Plated Tube x 1 (500 mm) Chrome Plated Tube x 2 (950 mm) - Page 4 Assembly Instructions Step 1 Connect the Black Coated Tube with Plastic Base Import Note: Ensure that tubes are tightly connected with Plastic Base See fig 1 fig 1 Step 2 Connect Black Coated Tube along with another Black Coated Tube then insert them with Plastic Bases Insert Black Coated...
- Page 5 Assembly Instructions Step 3 Connect Pole Locker along with Chrome Plated Tube Insert Plastic Connector to Chrome Plated Tube Connect Chrome Plated Tube with Black Coated Tubes Insert Chrome Plated Steel Tube into Black Coated Tube See fig 3 fig 3 Step 4 Connect Chrome Plated Tube...
- Page 6 Assembly Instructions Step 5 After you have followed each step mentioned above, you can adjust the height to desired position by loosen Plastic Clipper each Black Coated Tube screw them tightly. Finally, the assembly is complete. See fig 5 fig 5 Important Note: The Maximun Safe Load for long rail is 15 kg...
