- Page 1 Operating Manual for Dispenser “OE” “OE S” “OE HF” Please study carefully and follow step by step! witeg Labortechnik GmbH Am Bildacker 16 D-97866 Wertheim/Main Phone: +49 (0)9342 / 9301-0 Fax: +49 (0)9342 / 9301-77 Email: info@witeg.de www.witeg.de Version 06042009...
- Page 2 Table of contents 1 Safety- and user precautions 1.1 General safety precautions 1 Safety- and user precautions ........1 In order to put the device into operation as quickly as possible and free from 1.1 General safety precautions ..........1 defects, it is imperative that you read this manual carefully before using this 1.2 To be considered before initial operation ......
- Page 3 Labmax is used in the manner described in this manual and for the purpose for which it is designed. witeg is not responsible for consequential damages resulting from the misuse of First push the ejection cannula into the this equipment.
- Page 4 4 Functional characteristics 5 Cleaning and maintenance 5.1 Description of the components Air purging Before starting to pump, it is essential to place a collecting Cylinder Set (16) Fix screw (1) vessel under the cannula. The valve axle has to be in the dispensing position (arrow up).
- Page 5 5.2 Cleaning Closing cap (13) Cleaning is necessary if you want to use the Labmax for another chemical or if Valve axle (12) you don’t want to use it for a longer time. Follow the safety instructions! O-Ring a (14 a) Push the plunger downwards until it stops and then turn the O-Ring b (14 b) valve axle (12) to the left stop (Safety-Lock).
- Page 6 Place the device horizontally and mount the volume rocker switch into 5.4 Disassembly the slot. Than clip the adaptor ring (4) onto the outer housing (2). Follow the safety instructions! Labmax 100 ml Push the outer housing (2) down until it stops and then turn the valve axle (12) to the left stop (Safety-Lock).
- Page 7 6 Spare parts O-Ring a (14 a) 2,5 - 100 ml 5.370.381 O-Ring b (14 b) 2,5 - 10 ml 5.370.387 Part Size Article no. Only for version Cylinder set (16) 2,5 ml 5.370.255 “OE” Fix screw (1) 2,5 - 10 ml 5.370.251 (includes 4, 5, 18) 5 ml...
- Page 8 7 Optional accessories 1. Borosilicate glass one-way valve with plastic coating, avoids emitting of gases and strong smells Article-No. 5.377.300 2. Borosilicate glass tube with plastic coating for calcium chloride, ensures dry atmosphere in storage vessel Article-No. 5.377.310 3. Filter against dust and bacteria in storage vessel pore size 2 µm / 4,5 µm Article-No.
