Cisco Touchpad 10 Quick Reference Manual

Touchpad Basics

Tap the
touchpad
to wake up
the system.
Call (access
to Directory/
Favourites)
The Home screen should always be displayed prior to connecting to a site; if not, this may mean that a previous call was not
disconnected. If you do not see the Home screen, press End to disconnect prior to connecting to your site.

Camera Control and Selfview

Tap Camera
Tap the desired
to invoke the camera
Camera Preset.
adjustment menu.
Selfview options
a
b
• Multi-site sessions will be connected automatically at the scheduled start time.
• If you are registered for the event and it is already in progress and you are NOT connected, you can join
by using the connection information shown on the Whiteboard.
• Multi-site sessions will be automatically disconnected at the scheduled end time.
Rev 04Apr2019
Volume
Mute/unmute
Microphone
Turn Selfview
On and Off.
Pan/tilt
controls.
(arrows)
Zoom in
and out.
(+/-)
During a call: Tap Camera (a) and
then tap Selfview (b) to turn it on
(you may now resize the selfview
image or control the camera)
www.mbtelehealth.ca
Quick Reference Guide
Touchpad 10
Service Desk 204-940-8500 Option 4, Option 1
or toll-free 1-866-999-9698 Option 4, Option 1
Camera -
camera settings
and Selfview
option

Site to Site Call

1
1. Tap Call.
2. Tap in the search/dial field and enter the 5 digit number
using the keypad. (Tap the keypad icon
left corner of the screen if required.)
3. Tap Call to connect.
Out of Province/Network Calls
1. Tap Call.
2. Tap in the search/dial field and enter the phone number
using the keypad. (Tap the keypad icon
left corner of the screen if required.)
3. Tap Call to connect.

Multi-Site Call

You will be automatically connected (see note below).
Press End to disconnect at the end of every call
(Site to Site and Multi-site).
-
SX10/20/80, Room Kit Plus
Tap a button to
Scroll in lists like
activate its function.
a smart phone.
Press, drag and release
Tap outside the
to move a box.
menu to exit.

Make a Call

2
Keypad icon
... ...
in the bottom
... .
... ...
in the bottom
... .
3
Page 1 of 2
