TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 1
TP814
Triple Round Wood
Multiplay
INSTRUCTIONS FOR ASSEMBLY
MAINTENANCE AND USE.
PLEASE RETAIN FOR FUTURE REFERENCE.
IMPORTANT
This is the UPDATED
Instruction Manual.
Please destroy any
other instructions
included with this
Important!
These instructions must be followed
for safe assembly and use.
Please retain for future reference.
For assembly advice, please view the assembly video for this product on www.smythstoys.com,
email directsales@tptoys.com or call 01525 722769 (office hours).
WARNING!
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN
UNDER 36 MONTHS. SMALL PARTS. CHOKING HAZARD.
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
WARNING! ONLY FOR DOMESTIC USE. FOR OUTDOOR USE. ADULT SUPERVISION IS REQUIRED.
WARNING! THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 3 TO 12 YEARS.
WARNING! MAXIMUM COMBINED USER WEIGHT FOR SWING FRAME 200KGS
SINGLE SEAT USER WEIGHT - 60KGS
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE FITTED BEFORE USE.
.
product
Assembly Build Recommended
GLIDE RIDE USER WEIGHT - 2 X 35KGS
2 Person
25/09/2017 10:41

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the active fun TP814 and is the answer not in the manual?

Questions and answers

Related Manuals for TP Toys active fun TP814

Summary of Contents for TP Toys active fun TP814

  • Page 1 TP814 Triple Round Wood Multiplay INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE. PLEASE RETAIN FOR FUTURE REFERENCE. IMPORTANT This is the UPDATED Instruction Manual. Please destroy any other instructions included with this product Important! These instructions must be followed for safe assembly and use. 2 Person Please retain for future reference.
  • Page 2 TP Triple Round Wood Multiplay TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 2 25/09/2017 10:41...
  • Page 3 4. SUPERVISION Children should always be supervised while they are playing on TP toys and should be instructed not to use the toy in an inappropriate or hazardous manner. We recommend that they do not wear loose-fitting clothing or jewellery that may catch or snag during play.
  • Page 4 KNOW ABOUT ROUND WOOD Round timbers tend to come from younger smaller trees and are complete tree poles, stripped of any bark and other rough materials but subject to no further processing apart from the application of a suitable environmentally friendly preservative. As a natural material, every pole is different but they are predominantly heartwood surrounded by sapwood.
  • Page 5 TP802 Double - TP803 Triple Round Wood Swing IN7046-C 02 15.qxp_TP802 Double - TP803 Triple Round Wood Swing IN7046-C 02 15 12/02/2015 11:52 Page 5 Instruction Guide Instruction Guide Read Instructions Before Starting Hidden Lines Read Instructions Before Starting Sort Fixings Sort Parts Hidden Lines Sort Fixings...
  • Page 6 Stage Stage TP814 Triple Round Wood Multiplay Also Tools - You will need: Required: Not Supplied Mallet Tape Measure Step Ladder Spirit Level 3mm & 5mm Drill Bits Shovel Screwdriver Spanner Sockets Wrench Pozi #2 Combi Drill 10 & 13mm 10 &...
  • Page 7 Pack - 4 Pack - 5 Fixings - SP0076 Slide PM9752 4.5 x 40mm Woodscrew 5 x 60mm Woodscrew FA4517 FA9768 5 x 80mm Woodscrew FA4521 6 x 155mm Woodscrew FA9784 4 x 16mm Plastic Toggle Woodscrew PM8387 FA4527 M8 x 120mm Bolt FA9771 M8 x25mm Washer...
  • Page 8 Stage Triple Roundwood Deck Top bar MW0228 795mm Bracket Roundwood 70mm Coachscrew 90 Degrees FA8439 FB6052 30mm 125mm 125mm Drill 5mm Pilot holes 120mm 70mm Coachscrew Stage Legs (Deck) MW0222 2668mm IMPORTANT ASSEMBLY TIP Do not use screws IMPORTANT ASSEMBLY TIP TOP is stamped on the wood.
  • Page 9 Stage Legs (Deck) MW0222 2668mm ASSEMBLY IMPORTANT ASSEMBLY TIP Ensure legs are assembled this way. 1300mm 1300mm dimension is from the ground. 1300mm IMPORTANT ASSEMBLY TIP IMPORTANT ASSEMBLY TIP TOP is stamped on the wood. Do not use screws Take the pieces with TOP on them until Stage 8.
  • Page 10 Stage IMPORTANT ASSEMBLY TIP 2 People required to rotate frame into the upright postion. Stage Roundwood Multiplay Deck Cross Beams MW0225 612mm 6 x 155mm Woodscrew FA9784 Roundwood Multiplay Deck Supports MW0226 1550mm IMPORTANT ASSEMBLY TIP MW0225 Drill 3-5mm pilot holes in CENTRE of each end.
  • Page 11 Stage M8 x 120mm Bolt M8 x25mm FA9771 Nylon Insert Nut Washer FA5174 FA8440 IMPORTANT ASSEMBLY TIP Fully tighten these 4 bolts. Stage 70mm Coachscrew FA8439 ASSEMBLY TIP Step ladders required. Drill 5mm Pilot holes TP Triple Round Wood Multiplay TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 11 25/09/2017 10:41...
  • Page 12 Stage Roundwood Multiplay Deck Boards MW0223 700mm 4.5 x 40mm Woodscrew FA4517 ASSEMBLY TIP TP Branding Badge Swing Arm End to face SLIDE END of Platform IMPORTANT ASSEMBLY TIP DECKBOARD COULD OVERHANG HERE SLIGHTLY 13mm Deckboards - Spacing Space evenly with a minimum gap of 13mm between boards 13mm SLIDE END TP Triple Round Wood Multiplay...
  • Page 13 Stage Multiplay ladder Rung MW0224 850mm 5 x 80mm Woodscrew FA4521 WARNING 70mm IMPORTANT ASSEMBLY TIP Branding badge is on this side. IMPORTANT ASSEMBLY TIP Drill 3mm pilot holes 25mm Approx 25mm Approx 310mm 236mm 236mm 236mm TP Triple Round Wood Multiplay TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 13 25/09/2017 10:41...
  • Page 14 Stage Roundwood Barrier Board_1 Roundwood Barrier Board_3 MW0218 1400mm MW0220 1015mm 4.5 x 40mm Woodscrew FA4517 Roundwood Barrier Board_2 Roundwood Barrier Board_4 MW0219 1210mm MW0221 825mm ASSEMBLY IMPORTANT ASSEMBLY TIP Fit Barrier boards in this order Space evenly Space evenly WARNING 600mm Space evenly...
  • Page 15 Stage 4 x 16mm Plastic Toggle Woodscrew PM8387 IMPORTANT FA4527 ASSEMBLY TIP TOGGLES MUST BE ATTACHED AS SHOWN. THESE ARE TO ELIMINATE POTENTIAL TRAPS ie: CLOTHING WITH ASSEMBLY TIP STRAPS/TOGGLES. TP Branding Badge to face SLIDE END of Platform IMPORTANT ASSEMBLY TIP SLIDE END TP Triple Round Wood Multiplay...
  • Page 16 Stage Triple Roundwood Extension Top bar - section MW0227 2865mm 70mm Coachscrew FA8439 Bracket Roundwood Swing Leg FB6051 Drill 5mm Pilot holes 30mm 2 holes must face downwards IMPORTANT ASSEMBLY TIP Ensure pre-drilled holes in MW0227 are vertical. Stage Legs ( Swing Arm) MW0200 2700mm 70mm Coachscrew FA8439...
  • Page 17 Stage ASSEMBLY TIP Step 70mm Coachscrew ladders FA8439 required. Drill 5mm Pilot holes TP Triple Round Wood Multiplay TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 17 25/09/2017 10:42...
  • Page 18 Stage Slide PM9752 5 x 60mm Woodscrew FA9768 Space Space equally equally IMPORTANT ASSEMBLY TIP ENSURE FIXINGS SCREW INTO DECKBOARD AND ALSO DECK CROSS BEAM TP Triple Round Wood Multiplay Space Space equally equally TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 18 25/09/2017 10:42...
  • Page 19 Stage M8 Hook bolt FA9774 Swing Seat M8 x25mm FC5220 Nylon Insert Nut Washer FA5174 FA8440 Seat with ‘S’ hook IMPORTANT ‘S’ hook Attach swing seat ‘S’ hook to M8 Hook bolt before inserting Hook bolt to top bar (see left). Glide Ride Swing Swing Seat Swing Seat...
  • Page 20 Stage 40mm 35mm 350mm Stage Glider Downtube Bottom MT0521 Glider Seat Tubes FA2830 Male/female Bolt Set MT0522 M8 x 73mm MT0521 MT0521 IMPORTANT ASSEMBLY TIP All fixings should only be done to finger tight during assembly. Spring washer Plastic washer Plastic washer MT0522...
  • Page 21 40mm Stage 35mm FA2828 Bolt/washer/locknut Set M6 x 35mm Glider Foot Rest PM0519 Stage 40mm FA2827 Bolt/washer/locknut Set Glider Seat M6 x 40mm 35mm PM0520 TP Triple Round Wood Multiplay TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 21 25/09/2017 10:42...
  • Page 22 40mm 35mm Stage Glider Downtube Top MT0523 FA2829 Male/female Bolt Set M8 x 21mm MT0523 MT0523 Spring washer IMPORTANT ASSEMBLY TIP CHECK ALL BOLTS ARE FULLY TIGHTENED. TP Triple Round Wood Multiplay TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 22 25/09/2017 10:42...
  • Page 23 Stage M8 x 25mm Bolt Glide Ride Bracket FA8381 PR5070 Nylon Insert Nut FA5174 ASSEMBLY TIP ASSEMBLY TIP ASSEMBLY TIP Step Position brackets using Use Socket tool provided. pre-drilled hole on topbar ladders for guidance. required. Drill 5mm Pilot holes ASSEMBLY TIP ASSEMBLY TIP Level...
  • Page 24 Stage 40mm Coach screw FA8380 40mm Coach Screw ASSEMBLY TIP Step oles ladders Drill 5mm required. Pilot holes Drill 5mm Pilot holes ASSEMBLY TIP IMPORTANT ASSEMBLY TIP Gap between Brackets may vary Fully tighten bolts. Drill 5mm Pilot holes Fully tighten bolts.
  • Page 25 Stage FA2826 Bolt/locknut Set Spacer M6 x 40mm Bush (Bracket) PM1989 ASSEMBLY TIP Step ladders required. IMPORTANT ASSEMBLY TIP CHECK ALL BOLTS ARE FULLY TIGHTENED. TP Triple Round Wood Multiplay TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 25 25/09/2017 10:42...
  • Page 26 Stage 70mm Coachscrew Stake FA8439 PR5069 45° 45° 45° 45° TP814 300mm 300mm Dig holes: 300mm x 300mm 300mm x Mark leg/hole position. 300mm deep. Ensure the stakes are positioned into the setting Post-Mix concrete. Drill 5mm Pilot holes Warning: Never set the legs of the Supplied.
  • Page 27 Stage Stage Freespace/Safe Play Diagram Freespace/Safe Play Diagram Recommended Free Space: The Safe Play Area refers to the zone extending 200cm (2 metres) beyond the toy on all sides and 250cm (2.5 metres) above the toy. The Safe Play Area must be free from all structures, landscaping, trees and branches, rocks, wires, sprinkler heads and other similar obstacles to safe play.
  • Page 28 Thank you. Your TP Guarantee Number/Product Batch No is Designed in the UK by Robovision Ltd t/a TP Toys Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England www.tptoys.com TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 28...
