Manual
Video endoscope PCE-VE
320, 330, 340
Advertisement
Related Manuals for PCE Health and Fitness PCE-VE 320
Summary of Contents for PCE Health and Fitness PCE-VE 320
- Page 1 www.pce-industrial-needs.com Tursdale Technical Services Ltd Unit N12B Tursdale Business Park Co. Durham DH6 5PG United Kingdom Phone: +44 ( 0 ) 191 377 3398 Fax: +44 ( 0 ) 191 377 3357 info@tursdaletechnicalservices.co.uk http://www.industrial-needs.com/ Manual Video endoscope PCE-VE 320, 330, 340...
- Page 2 info@tursdaletechnicalservices.co.uk CONTENT Parts function ......................... 3 Interface Overview ......................3 Operation function ......................3 Menu ..........................4 Operation ........................4 SD Card Routes ......................6 Troubleshooting ......................6 Caution ..........................6 Specification ........................6 10. Specification ........................6...
-
Page 3: Parts Function
info@tursdaletechnicalservices.co.uk 1. Parts function A. Power button B. PHOTO button C. REC button D. PREV button E. NEXT button F. Multi-selector G. Escape H. Light switch SD jack J. AV jack K. USB jack L. DC IN jack M. Main unit N. - Page 4 info@tursdaletechnicalservices.co.uk 4. Menu Main Menu Under the preview mode: Press MENU button to display the various optional functions as follows: DELETE ALL VIDEO OUTPUT DATE / TIME SETUP LANGUAGE VIDEO FORMAT AUTO POWER OFF DELETE ALL set up Displays a frame which includes two options as in picture 2. Use ”PREV”...
- Page 5 info@tursdaletechnicalservices.co.uk Operation DATE / TIME SETUP 1. Press OK to select 2. Press or to set Date (YY/MM/DD), Time (HR/MIN/SEC). 3. Press for adding or for decreasing the numbers (date / time) and further pressing will go to “DISPLAY” option and press or for “ON ” / “OFF” DISPLAY option. Display date Conceals date Operation...
-
Page 6: Troubleshooting
info@tursdaletechnicalservices.co.uk 6. SD Card Routes When you get the product, recommend you set up the time and date for the future management of the files. The product press time is YEAR 2007, January 1 . If file name shows first two codes are 11, it indicates the time is preset time. - Page 7 info@tursdaletechnicalservices.co.uk System SPEC. Power DC5V Display 3.5”TFT LCD Monitor 320*240 Pixels Interface Mini usb 1.1/ AV out / AV in/ Battery Rechargeable Li-Polymer Battery (3.7V) Video Out Format NTSC & PAL Recording medium SD card (the capacity can be used up 2G) Compression Format MPEG4 Still Image Storage Format...
