DOOR PHONE MD-4900CFA
ACMA Supplier's Code N468
ISO9001 Certified
Document G/01141E
Issue 1, 27/04/2012
CAT 5 SPLIT-SYSTEM
Design Two Thousand Pty Ltd
ABN: 45 005 014 639
9-11 Rose Street
Upper Ferntree Gully
Melbourne Victoria 3156 Australia
Telephone: +613 9758 5933 Facsimile: +613 9758 5560
Email:
gen@design2000.com.au
Web Site:
www.design2000.com.au
All Rights Reserved,
Copyright Design 2000 Pty Ltd © 2012
Operator Handbook for CFA Door Phone
G/01141E
Issue 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD-4900CFA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Design 2000 MD-4900CFA

  • Page 1 9-11 Rose Street Upper Ferntree Gully Melbourne Victoria 3156 Australia Telephone: +613 9758 5933 Facsimile: +613 9758 5560 Email: gen@design2000.com.au Web Site: www.design2000.com.au All Rights Reserved, Copyright Design 2000 Pty Ltd © 2012 Operator Handbook for CFA Door Phone G/01141E Issue 11...
  • Page 2 G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 PAGE LEFT BLANK __________________________________________________________________________________________________ Operator Handbook for CFA Door Phone G/01141E Issue 11...
  • Page 3 G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 Document Control Document ID G/01141 Document Name CFA Door Phone MD-4900CFA Handbook Security Commercial In Confidence Circulation Design 2000 Pty. Ltd., CFA Prepared By P. Zeug Reviewed By R. Kells Approved By Version Control...

  • Page 4: Table Of Contents

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 CFA DDOR PHONE MD-4900CFA DOOR / WALL SPLIT-SYSTEM HANDS-FREE TELEPHONE USER HANDBOOK SECTION CONTENTS PAGE Introduction Overview Description Features Installation Installation Block Diagram Mounting details Connections Wiring Diagram For Door Latch & Output Mode...
  • Page 5 27/04/2012 MD-4900CFA Handbook Edition 1 DESIGNED & MANUFACTURED BY DESIGN TWO THOUSAND PTY LTD www.design2000.com.au gen@design2000.com.au AUSTRALIAN OFFICE Design 2000 Pty Ltd 9-11 Rose Street Upper Ferntree Gully Melbourne Victoria 3156 Australia Sales/Service Contact: 03 9758 5933 03 9758 5560...

  • Page 6: Introduction

    OVERVIEW The CFA Door Phone Model MD-4900CFA looks and sounds similar to a conventional intercom plate. When you press the button at the front door, you hear dialing tones coming from the doorplate followed by telephone service tones, eg.

  • Page 7: Description

    (pins 2 & 6 on a 610 socket or centre pins 3 & 4 on an RJ12 jack). RJ style plugs are provided. The MD-4900CFA is telephone line powered so the unit continues to operate in the event of mains power failure.

  • Page 8: Installation

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 2. INSTALLATION INSTALLATION BLOCK DIAGRAM CFA DOOR PHONE – MD-4900CFA MASTERCALL DOOR PHONE MD-4900 Switched Output (eg Door Latch) MASTERCALL DOOR PHONE Alarm Input RS232 CALL Hide-away Unit Front Door Plate with push button, mic &...

  • Page 9: Mounting Details

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 MOUNTING DETAIL 2.2.1 DOOR PLATE The stainless steel front plate is surface mounted. An exploded view of the assembly is shown here: 2.2.2 DOOR PLATE DIMENSIONS The stainless steel front plate is surface mounted. Mounting holes are spaced at standard electrical socket outlet dimensions.
  • Page 10 G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 2.2.2 HIDE-AWAY UNIT DIMENSIONS HIDE-AWAY UNIT WALL MOUNTING OPTION 110 mm Disconnect all wiring from Hide-away unit. Drill holes for mounting screw as shown in diagram. Fit mounting screw to mounting surface and check that screw does not protrude more than 7mm from surface Locate Hide-away unit onto mounting screw.

  • Page 11: Connections

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 CONNECTIONS ON THE MD-4900CFA HIDE-AWAY UNIT DOOR OPENER / ALARM CONNECTOR POWER 12V DC ALARM (IF REQUIRED) ALARM DOOR - DOOR TELEPHONE DOOR + PLATE LINE RELAY CONNECTOR 2.3.1 DOOR PLATE CABLE The cable supplied that interconnects the Door Plate and Hide-Away Unit is shown here.

  • Page 12: Wiring Diagram For Door Latch & Output Mode

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 2.4 WIRING DIAGRAM FOR DOOR LATCH & SWITCHED OUTPUT MODE HIDE-AWAY UNIT PIN 4 DOOR+ POWER SUPPLY FOR DC DOOR STRIKE PIN 3 DOOR- Open Collector Switch & Isolation Circuit 10 - 30 V DC...

  • Page 13: User Instructions

    2. A star (*) can be entered by pressing * *. 3. A hash (#) can be entered by pressing # #. 4. If no number is entered, the MD-4900CFA will ‘hotline’ when the push button is pressed.  Summary: <* [PIN] 2 nnn…#>...

  • Page 14: Speaker Volume

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 How to Change the Speaker Volume 1. While talking to the door phone party, simply press * 2. Enter your PIN (normally none). 3. Press 3 to turn up the volume or 4 to turn down the volume, and listen for the confirmation tone.

  • Page 15: Pin

    7. Press # to store the new PIN number, and a confirmation tone is heard.  Summary <* [PIN] 1 pppp…#> 3.10 Automatic Disconnect The MD-4900CFA will disconnect the telephone line if:  Four busy tones are detected.  DTMF *9 is detected.

  • Page 16: Busy Tone Detect Selection

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 3.14 Busy Tone Detect Selection Brief IP based telephone switches and VoIP analogue terminal adaptors can provide either North American busy tone or Australian busy tone. All MD-4900 Series Door Phones can be set to detect either “US” or “AUS”...

  • Page 17: Specifications

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 SPECIFICATIONS Enclosures Stainless steel (Grade 316) and powder coated zincalume Dimensions Door Plate 129 mm x 80 mm x 30 (fits standard GPO). Hide-away Unit 215 mm x 105 mm x 35 mm. Mounting Spacer Block...
  • Page 18 G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 DOOR PHONE MD-4900CFA HANDS-FREE DOOR TELEPHONE “Communication for Emergency Services” MADE IN AUSTRALIA BY Est. 1968 TELEPHONE: (03) 9758 5933 FAX: (03) 9758 5560 E-MAIL: gen@design2000.com.au WEB SITE: www.design2000.com.au __________________________________________________________________________________________________ Operator Handbook for CFA Door Phone...

  • Page 19: Packing List

    G/01141E 27/04/2012 MD-4900CFA Handbook Edition 1 PACKING LIST CFA DOOR PHONE MD-4900CFA Quantity Item Front door plate assembly Grille, speaker, mic, push button etc. Grub screws Securing grille to base plate Mounting block incl. 2 screws Surface mounting option Hide-away unit...
