SimLab P1-X Instruction Manual page 11

Parts list - Variants
Front mount
FR1
FR2
FR3
FR4
FR5
FR6
FR7
FR8
FR9
FR10
FR11
FR12
FR13
FR14
Wheeldeck plate
WH1
WH2
WH3
WH4
WH5
WH6
Fanatec Podium mounting bracket
DD1
DD2
DD3
DD4
DD5
DD6
DD7
DD8
DD9
DD10
Parts list - Feet (optional kit)
BOX D
F1
F2
F3
F4
F5
F6
Front Mount Bracket [ALU 15mm]
Front mount Side plate (Left)
Front mount Side plate (Right)
Bolt - DIN 912 (Black steel, 20mm, M6)
Bolt - DIN 912 (Black steel, 20mm, M8)
Bolt - DIN 912 (Black steel, 40mm, M8)
Spacer - male / female (10mm, M6)
Corner Bracket (40x40)
Cover cap for corner bracket (40x40)
Nut (M8, DIN 985 locknut, Galvanised)
Washer (Black steel, M8, Plain black)
Slot 8 nut (M8)
Bolt - DIN 7991 (Black steel, 30mm, M8)
Bolt - DIN 7991 (Black steel, 20mm, M8)
Side plate wheeldeck
Wheeldeck top plate
Bolt - DIN 912 (Black steel, 16mm, M8)
Slot 8 nut (M8)
Bolt - DIN 912 (Black steel, 20mm, M8)
Washer (Black steel, M8, Plain black)
Fanatec DD sidemount base holder (Left)
Fanatec DD sidemount base holder (Right)
Fanatec DD sidemount profile holder (Left)
Fanatec DD sidemount profile holder (Right)
Profile 40 mm slot 8 (Black/Grey, 40x80L) - 194mm
Slot 8 nut (M8)
Bolt - DIN 7991 (Black steel, 20mm, M8)
Bolt - DIN 912 (Black steel, 20mm, M8)
Bolt - DIN 912 (Black steel, 20mm, M6)
Washer (Black steel, M8, Plain black)
Sim Feet (Optional)
Leveling feet Diameter 80mm - M16x125
Nut (M16, DIN 934 nut, Galvanised)
Washer (Galvanised, M16, Plain black)
Slot 8 nut (M8)
Bolt - DIN 912 (Black steel, 25mm, M8)
Feet Support [alu 15mm]
1 Units
1 Units
1 Units
4 Units
6 Units
4 Units
4 Units
4 Units
4 Units
12 Units
4 Units
4 Units
4 Units
4 Units
2 Units
1 Units
4 Units
6 Units
6 Units
4 Units
1 Units
1 Units
1 Units
1 Units
2 Units
8 Units
8 Units
8 Units
4 Units
4 Units
1 Units
4 Units
8 Units
8 Units
8 Units
8 Units
4 Units
