Lightning Strike!
Professional Trigger 4.0
The AEO Lighting Strike! Professional is a Lightning Shutter Trigger. Enhancements in our "Pro" series
triggers include sensitivity override adjustment, as well as a locking hot shoe / tripod mount, improved
ambient noise filtering (shutter hammer from 60Hz sources), and rechargeable Li-Ion battery usage and
a built-in USB charging system.
IF YOUR TRIGGER SHIPPED FROM A DISTRIBUTOR AND YOU DID NOT RECEIVE A CABLE, OR YOU WERE
NOT OFFERED TO SELECT A CABLE AT TIME OF PURCHASE, PLEASE CONTACT AEO PHOTO AT
sales@aeophoto.com
WE WILL ASSIST YOU IN OBTAINING THE CORRECT CABLE FOR OUR CAMERA.
BEFORE TESTING YOUR DEVICE READ THIS ENTIRE MANUAL, ESPECIALLY THE SECTION ON

Lightning Mode:

Test your new device right out of the box: Set the mode switch to "Lightning". Turn the power on. The
red LED will flash every time the device triggers. It's normal for it to trigger once on power up. If it
continues to trigger, check for light sources leaking into the room. (If you cover the window of the
device with your hand, it should not trigger). Set off a camera flash (using another camera or a flash
attachment). The flash should trigger the device.
Manual adjustment of the sensitivity is accomplished by adjusting the "trim screw" accessible on the left
side of the device (looking from above). The port in the most aft position is the sensitivity adjustment.
(The "forward port" is your cable connection). The Sensitivity Trim is a SINGLE TURN adjustment.
CAUTION: DO NOT ATTEMPT TO FORCE THE ADJUSTMENT BEYOND IT'S MECHANICAL STOPS. DOING SO
MAY DAMAGE THE SENSITIVITY ADJUSTMENT. Use a small jeweler's screwdriver, standard or Phillips) to
make the adjustments. Full CLOCKWISE sets the sensitivity at 120% of the factory set point. Full
COUNTER CLOCKWISE sets the sensitivity at 20% of the factory set point. We recommend for most
situations to use the normal set point which is approximately ¼ turn CCW from the full sensitivity point.
Other photography scenarios may dictate different settings at the professional photographer's
discretion.

Photographic Capture of Lightning:

The device triggers on the first bolt it detects and activates the shutter release of your camera within
0.3ms. Most lightning events last several hundred milliseconds.
Photographing Lightning is as much Art as it is Science. Getting the right conditions and settings can be
challenging, and some folks have a better knack for it than others. But to get you started, here are some
basic "recommendations":

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lighting Strike! and is the answer not in the manual?

Questions and answers

Summary of Contents for AEO Photo Lighting Strike!

  • Page 1 USB charging system. IF YOUR TRIGGER SHIPPED FROM A DISTRIBUTOR AND YOU DID NOT RECEIVE A CABLE, OR YOU WERE NOT OFFERED TO SELECT A CABLE AT TIME OF PURCHASE, PLEASE CONTACT AEO PHOTO AT sales@aeophoto.com WE WILL ASSIST YOU IN OBTAINING THE CORRECT CABLE FOR OUR CAMERA.
  • Page 2 Lightning Strike! Professional Trigger 4.0 1. The camera should be mounted on a tripod. You want it stable during the exposure. 2. Mount the device in your camera’s hot shoe mount with the red semi-clear window facing the direction you are photographing. Insert the supplied plug into your camera remote shutter interface.
  • Page 3 Lightning Strike! Professional Trigger 4.0 INSTALLING NEW BATTERY: AEO RECOMMENDS THAT YOU NEVER OPEN THE BATTERY COMPARTMENT ON OUR PRO MODELS. THE BUILT-IN CHARGER NEGATES THE NEED TO REMOVE THE CELL FOR CHARGING. IF THE CELL IS REMOVED AND RE-INSERTED REVERSED POLARITY, THE DEVICE WILL BE DAMAGED AND NOT COVERED BY WARRANTY.
  • Page 4 Lightning Strike! Professional Trigger 4.0 If you have questions, or if you wouldn’t mind sending us some of your photographs, contact us at sales@aeophoto.com or by mail at 1435 Tally Ho Lane, Norco, CA 92860. HAVE FUN!
