XP24-3 &
XP24-6 Series
Scissor Lifts
Installation, Operation
and Service Manual
Model Number ___________________
Serial # _________________________
Date placed in service _____________
IMPORTANT: READ CAREFULLY
BEFORE INSTALLING OR OPERATING LIFT
Part orders are subject to a $50 minimum charge.
September 2014
Advertisement
Related Manuals for Presto XP24-3 Series
Summary of Contents for Presto XP24-3 Series
- Page 1 XP24-3 & XP24-6 Series Scissor Lifts Installation, Operation and Service Manual Model Number ___________________ Serial # _________________________ Date placed in service _____________ IMPORTANT: READ CAREFULLY BEFORE INSTALLING OR OPERATING LIFT Part orders are subject to a $50 minimum charge. September 2014...
- Page 2 This manual was current at the time of printing. To obtain the latest, most updated version, please contact Presto Lifts Customer Service Department or go to our website: www. owner’s manuals to print. Page 2 — PRESTO OWNER’S MANUAL: XP24-3 & XP24-6 SERIES...
-
Page 3: Table Of Contents
RESTOCKING POLICY & RMA POLICY ..............13 RETURN GOODS AUTHORIZATION (RMA) PROCEDURES ........14 WARRANTY ........................15 LIST OF FIGURES: Fig. 1 Foot pedal ..................... 8 Fig. 2 XP24 Assembly ................... 10 Page 3 PRESTO OWNER’S MANUAL: XP24-3 & XP24-6 SERIES —... - Page 4 This manual provides all the information for the safe and proper assembly, operation and mainte- nance of the Presto Lift Inc. Model XP24-3 and XP24-6 lifts. It is important that this manual be read by all personnel involved with the installation, maintenance or operation of the scissor lift. These models are designed for in-plant and non-hazardous locations.
-
Page 5: Responsibility Of Owners And Users
Responsibility of Owners and Users Inspection and Maintenance The device shall be inspected and maintained in proper working order in accordance with Presto’s owner’s manual. Removal from Service Any device not in safe operating condition such as, but not limited to, excessive leakage, missing rollers, pins, or fasteners, any bent or cracked structural members, cut or frayed electric, hydraulic, or pneumatic lines, damaged or malfunctioning controls or safety devices, etc. -
Page 6: Safety Alert Symbols And Signal Words
SAFETY INSTRUCTIONS (or equivalent) signs indicate safety- S A F E T Y related instructions or procedures. I N S T R U C T I O N S (Green Background) Page 6 — PRESTO OWNER’S MANUAL: XP24-3 & XP24-6 SERIES... - Page 7 The safety of all persons installing, using, servicing, or working near the unit is of paramount concern to Presto Lifts. The lift is a powerful machine with moving parts, and is capable of causing personal injury if proper precautions are not taken. Therefore, throughout this manual, Presto Lifts has identi- instructions or precautions that should be taken to avoid these hazards.
-
Page 8: Unpacking And Assembly
All routine inspection maintenance should be performed Figure 1: Foot Pedal on a monthly basis. with a medium weight oil or light grease. Recommended hydraulic oil: Super Hydraulic 32 Conoco Page 8 — PRESTO OWNER’S MANUAL: XP24-3 & XP24-6 SERIES... - Page 9 It is very important to keep the hydraulic oil free of dirt, dust, metal chips, water, and other contamination. Most of the problems with hydraulic systems are caused by contamination in the oil. Page 9 PRESTO OWNER’S MANUAL: XP24-3 & XP24-6 SERIES —...
-
Page 10: Fig. 2 Xp24 Assembly
Part numbers are accurate for machines shipped prior to 2005. For machines shipped in 2005 or later, contact Presto Parts with the model and serial number. Figure 2: XP24 ASSEMBLY 300 and 600 LB Item No. Part No. Description 1011-017... - Page 11 Part numbers are accurate for machines shipped prior to 2005. For machines shipped in 2005 or later, contact Presto Parts with the model and serial number. Item No. Part No. Description 1011-097 Release Knob 1011-090-02 Release Rod 1011-010 Roller “...
-
Page 12: Ordering Replacement Parts
Ordering Replacement Parts Presto Lifts has carefully chosen the components in your unit to be the best available for the purpose. Replacement parts should be identical to the original equipment. Presto Lifts will not be responsible for equipment failures Presto Lifts can supply all replacement parts for your lift. With your order, please include the model number the scissors mechanism. - Page 13 Should you feel there is a quality problem, please contact the seller to ask ques- tions and gather information on how to rectify the issue. Presto Lift Inc. reserves the right to determine potential credits, as a result of factory defects, based on its inspection of the merchandise.
- Page 14 Canada, or Mexico have thirty (30) days from date of RGA issue to have the product arrive at Presto Lifts’ facility. All merchandise must arrive Free on Board at Presto Lifts’ facility or the shipment will be refused and returned to the sender. All credits are issued less restocking and refurbishing charges, regardless if the merchandise was damaged in transit.
- Page 15 Presto Lifts Limited Warranty Policy Presto Lifts warrants all of its products against defects in the welded structural frame and, if ap- the date of invoice. All other components have a limited warranty against defects in faulty material and workmanship for a two (2) year period from the date of invoice date of invoice and 30 day limited warranty on labor.
- Page 16 MANY NEEDS REQUIRE MANY OPTIONS... LET PRESTO MEET THOSE NEEDS! Call Presto Sales for stock or customized lift inquiries: 800-343-9322 Email: sales@prestolifts.com...
