Sun Stand
HEAVY DUTY H.I.D. AND FLUORESCENT LIGHT STAND
This unit contains:
Parts to Assemble Sun Stand
Qty
Description
1 ea
Top bar (A)
2 ea
Side upright bars (B)
2 ea
Feet (C)
36 ea ¼-20 x
⁄
" screws
3
8
4 ea
Foot support gussets (D)
You will need a #3 Phillips screwdriver to assemble this Sun Stand™ 2.
Step 1. Place foot over top of outer leg and slide towards bottom.
Step 2. Place a foot support gusset with flat surface out in corner of leg and attach each gusset with
four screws. Then attach the foot to the outer leg with two screws.
Step 3. Repeat step 2 for other side.
STEP 1
ASSEMBLY INSTRUCTIONS
™
2
Parts to hang column
Qty
Description
2 ea
Grow Yo-Yo's
2 ea
Hanging shuttles
STEP 2
A
DETAIL A
2
™
A
B
D
C
STEP 3
Repeat step 2 for
the other side.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Sun System Sun Stand 2
- Page 1 Sun Stand ™ HEAVY DUTY H.I.D. AND FLUORESCENT LIGHT STAND ASSEMBLY INSTRUCTIONS This unit contains: Parts to Assemble Sun Stand ™ Parts to hang column Description Description 1 ea Top bar (A) 2 ea Grow Yo-Yo’s 2 ea Side upright bars (B) 2 ea Hanging shuttles 2 ea...
- Page 2 Step 4. Slide inner leg into outer leg pulling back the spring STEP 4 loaded pin to allow it to slide all the way down. Lift inner leg to set pin into hole. PULL THIS PIN OUT Step 5. Repeat step 4 for other side leg. WHILE INSERTING INTO OUTER LEG Step 6.
