Summary of Contents for Teknobil Thuraya Vehicle Docking Adaptor
- Page 1 Thuraya Vehicle Docking Adaptor Installation Manual and User Guide...
- Page 2 Adaptor Installation Manual and User Guide Information in this document is subject to change without notice. Please refer to Teknobil web site at www.teknobil.com.tr for the latest information on your product. April 2003 Teknobil, Teknobil Next, Teknobil Next Thuraya VDA, Thuraya Manager and SVTS are trademarks of Teknobil A.S.
-
Page 3: Table Of Contents
By purchasing the Teknobil Next Vehicle Docking Adaptor (VDA), you have made an excellent choice toward getting the best from your Thuraya phone on the move. We appreciate your FEATURES business, and we would like your experience with Teknobil Next VDA to be as smooth and beneficial as possible. COMPONENT PARTS... -
Page 4: Features
Features Component Parts Your unit extends the seamless connectivity provided by your Thuraya phone to vehicles on Carefully unpack the equipment and ensure that all component parts are present. If any the move. Enriched with features that are designed to make your journeys more comfortable component part is missing, please do not proceed with installation and contact your local dealer immediately. -
Page 5: Installation
Installation Fuse Before You Install Should be connected between the battery and the red lead of the Car Interface Cable. For Please read the Safety Precautions carefully and strictly adhere to the following points: maximum safety, place the fuse as close to the battery as possible. •... -
Page 6: Installing The Vda Holder
FIGURE 2 Positioning of VDA Components in Your Vehicle FIGURE 3 Cable Routing for the External Antenna Take your time to find the best cable route for your vehicle then connect the cables to the Mounting the External Antenna indicated connectors on the Holder: The External Antenna is required for satellite communication when the Thuraya phone is used •... -
Page 7: Installing The Control Box
FIGURE 5 Installing the Control Box Follow the exact sequence below for your safety and to avoid any damage to your unit: • Turn off the ignition and disconnect the vehicle battery. • Connect the leads to the Control Box and ensure that the Red lead is connected the last. •... -
Page 8: Installing The Privacy Handset
Installing the Privacy Handset Using the two screws fasten the handset tightly to a flat surface in the vehicle as shown in Figure 7. FIGURE 6 Control Box Connection Diagram Cable Routing • Ensure that all connections are firm and stable. •... -
Page 9: Installing The Hands-Free Speaker
Testing the Installation Your VDA is a high-technology product enabling in-vehicle use of your Thuraya phone and bringing many features to your Thuraya experience. For your unit to work satisfactorily and not to impair the driver or your car, please ensure that you fully test it after installation. For this purpose, start your vehicle and ensure that you hear the sound of the engine working normally. -
Page 10: Operation
Operation Getting to Know Your VDA Holder Turning on Your Unit for the First Time Figure 10 shows the location of the buttons and the indicator lights on your VDA Holder. Attaching Thuraya phone to the VDA Holder Warning Failing to remove the rubber dust cap behind Thuraya phone may damage the VDA Holder. - Page 11 FIGURE 13 Setting the SVTS and Alarm Switches Making Calls with the Handset Your VDA is in the Handset mode when the Hands-Free indicator is off. If this indicator is red (ON) and you would like to make a call with the Handset, simply press the Mode Button to FIGURE 12 Removing Thuraya phone from the VDA Holder switch to the Handset mode.
-
Page 12: Data, Fax And Internet Connections
ISP’s guidelines with a different set of telephone number, username and password. For your convenience, a detailed version of these instructions, complete with screenshots, is available on Teknobil’s web site at www.teknobil.com.tr. -
Page 13: Optional Thuraya Manager Software
Thuraya-based smart fleet management system that can be purchased if it was checked. from Teknobil separately. All you need to activate the fleet management features of your VDA • Supply blank fields for both user name and password when prompted by the wizard. -
Page 14: The Svts Control Center
The SVTS Control Center Your VDA acquires, s tores and forwards all the required information. You also need a Control Center to receive and process this information from one or more vehicles depending on the size of your fleet. The Control Center has the following components: •... -
Page 15: Technical Specifications
Handset 17.5 • If possible use the mobile phone with your non-aided ear. Total Weight 2.2 kg • Use Hands-Free function of the Teknobil Next Thuraya Vehicle Docking Adaptor... -
Page 16: Warranty Card
Check with the manufacturer or its representative regarding your vehicle. You should feel that your product is not performing properly and it needs to be serviced, contact Teknobil also consult the manufacturer of any equipment that has been added to your vehicle.
