SALT WATER SYSTEM CHLORINATOR
ITEM: 90154 / 90155 / 90156
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: 909.628.0880 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Summary of Contents for Xtreme Power 90154
- Page 1 SALT WATER SYSTEM CHLORINATOR ITEM: 90154 / 90155 / 90156 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER) FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: 909.628.0880 MON-FRI 9AM TO 3PM PST...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION SAFETY The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. -
Page 3: Operation
OPERATION Cyanuric acid is needed in outdoor pools to help to stabilize and maintain proper levels of chlorine. 90% of unstabilized chlorine is destroyed by the UV radiation from the sun within two hours. Cyanuric acid stabilizes chlorine in water from UV degradation. When using the CFPT, the cyanuric acid level should be maintained between 30-50 ppm. -
Page 4: How Much Salt To Use
OPERATION How Much Salt to Use? Use table on page 7 to determine how much salt will be needed. Most pools contain some salt, depending on the water source and chemicals used for sanitizing. Therefore, the pool owner must always test salt levels before adding salt.A hand held meter calibrated for NaCl (salt) can be used to determine the salt levels of the water. - Page 5 APPLICATIONS POUNDS and (Kg) OF SALT NEEDED FOR 3400 PPM...
- Page 6 OPERATION Introduction: CFPT Salt Chlorinator The CFPT chlorine generator, by electrolysis, creates chlorine to sanitize your pool from the salt molecules (NaCL) in your water. A small electric charge is applied across a set of titanium plates inside the Electrolytic Cell.
- Page 7 OPERATION CFPT includes Flow sensor: Temperature sensor: Salt sensor Mark: The salt reading is around +/-300 ppm accuracy. CFPT Dual Voltage 115V-230V Power Center CFPT Power Center is a dual voltage power supply which means 115V/230V no wiring is required, The Power Supply converts AC electrical current to a low-voltage DC electrical current which is required to produce chlorine.
-
Page 8: Determining Pool Size (Gallons Of Water In Your Pool)
OPERATION Determining Pool Size (Gallons of Water in Your Pool) CAUTION: To protect the lifetime of CFPT, never use dry acid (sodium bisulfate) to adjust pH in arid geographic areas with excessive evaporation and minimal dilution of pool water with fresh water. LED LIGHT INSTRUCTION SUPERCL /SALINITY: SHORT PRESS: Show the salinity LONG TIME PRESS: Enter into SuperChlor mode, long time press... - Page 9 OPERATION IMPORTANT! Use of an external Pool Pump Timer is Required The CFPT is designed to supply a sufficient amount of chlorine to sanitize pool water on a daily basis. If the pool pump is continuously running 24 HOURS and the CFPT is operated at 100%, too much chlorine would be generated than would be needed by most pools (2-4 ppm).
-
Page 10: Installation
OPERATION INSTALLATION ATTENTION: Before installation, ensure power is disconnected! Grounding (earth bonding) is required. The unit should be installed by a qualified service person and grounded. Install to allow access to cell buttons and power center. Read Safety Precautions and Important Instructions on page 1. Before attempting any electrical wiring, be sure to read and follow Safety Instructions. - Page 11 OPERATION How to replace CFT Step 1. Turn off the power to the pump and chlorine salt generator. Ideally this should be done at the circuit breaker. The controller display should go blank. Step 2. Relieve the water pressure at the relief valve, it is usually on top of your pool filter.
- Page 12 OPERATION Step 7. Place the CFT cell into the piping and screw the unions back onto the ends of the new cell. Tighten the thread. The cell can be positioned either way. In fact, we suggest to reverse the cell every time you clean it to extend the life of the cell.
-
Page 13: Parts List
PARTS LIST... -
Page 14: Troubleshooting
TROUBLESHOOTING... -
Page 15: Diagnostic Displays
TROUBLESHOOTING Polaris-Attach wires to proper screw terminals as shown below. Note that screw terminal “1” is marked on the Polaris PCB. TROUBLESHOOTING Diagnostic Displays Sequential pushes of the small “diagnostic” button next to the LCD display will cause the SPS to display the following information: 1. -
Page 16: Please Read The Following Carefully
OF NOTE PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
