Summary of Contents for Hydroworks Hydroguard HG 4
- Page 1 ® Hydroworks Hydroguard Operations & Maintenance Manual Version 1.5...
- Page 2 Hydroworks HG Operation The Hydroworks HG separator is unique since it treats both high and low flows in one device, but maintains separate flow paths for low and high flows. Accordingly, high flows do not scour out the fines that are settled in the low flow path since they are treated in a separate area of the device as shown in Figure 1.
- Page 3 The Hydroworks HG separator is revolutionary since it incorporates low and high flow treatment in one device while maintaining separate low and high flow paths to prevent the scour and re-suspension of fines.
- Page 4 Figure 2. Hydroworks HG Operation – Profile View The HG 4i is an inlet version of the HG 4 separator. There is a catch-basin grate on top of the HG 4i. Water flows directly into the inner chamber of the HG 4i through the catch- basin grate on top of the structure.
- Page 5 Accordingly this funnel provides the same separate flow paths for low and high flow as the other Hydroguard separators. The whole funnel is removed for inspection and cleaning providing. Figure 3. Hydroworks HG 4i Normal Flow Path Figure 4. Hydroworks HG 4i Peak Flow Path...
- Page 6 A visual inspection can be conducted for floatables by removing the covers and looking down into the separator. Multiple covers are provided on Hydroworks HG units to access all areas of the separator (The HG 4 will have a single larger 32” (800mm) cover due to the lack of space for multiple 24”...
- Page 7 Once the water is decanted the sediment can be removed with the clamshell bucket. Maintenance of a Hydroworks HG unit will typically take 1 to 2 hours based on a vacuum truck and longer for other cleaning methods (i.e. clamshell bucket).
- Page 8 TSS/sediment reaches 30” (750 mm). It must also be maintained during the construction period if there is an appreciable depth of oil in the unit (more than a sheen) or if floatables other than oil cover over 50% of the open water surface on the inlet side of the outlet baffle wall.
- Page 9 Repairs required Further investigation is required Please call Hydroworks at 888-290-7900 or email us at support@hydroworks.com if you have any questions regarding the Inspection Checklist. Please fax a copy of the completed checklist to Hydroworks at 888-783-7271 for our records.
- Page 10 Other Comments:...
-
Page 11: One Year Limited Warranty
Under no circumstances shall Hydroworks, LLC be liable to the Purchaser or to any third party for product liability claims; claims arising from the design, shipment, or installation of the Hydroguard, or the cost of other goods or services related to the purchase and installation of the Hydroguard.
