- Page 1 MANUAL DIRECT PURGE OPTION UNION CWD2005 PLUS Instruments GmbH eneral information, safety standards and regulations or direct purge option Version: V1.00 Stand: 24.03.2010...
- Page 2 User Manual CWD2005 Plus Union Instruments GmbH Zeppelinstr. 42 D-76185 Karlsruhe +49 (0)721-95243-0 +49 (0)721-95243-33 info@union-instruments.com http://www.union-instruments.com...
-
Page 3: Table Of Contents
User Manual CWD2005 Plus Contents Contents ........................... 3 1. General information about safety and warranty ..............5 2. Fundamental Safety Instructions ..................7 3. Information related to designated use ................9 3.1 Foreseeable misuse ....................9 3.2 Specific hazard warning ................... - Page 4 User Manual CWD2005 Plus...
-
Page 5: General Information About Safety And Warranty
General information about safety and warranty User Manual CWD2005 Plus 1. General information about safety and warranty Strictly follow the Instruction for Use Any use of the control unit requires full understanding and strict observation of this instruction. The installation must be performed in the way as described in the instruction and manual. - Page 6 User Manual CWD2005 Plus General information about safety and warranty Work on electrical system may be accomplished only by trained and instructed personnel. Danger! Mains voltage 120V, 60Hz Contact with this voltage can cause serious burns or even death. Work on electrical circuits may only be carried out by qualified electrician.
-
Page 7: Fundamental Safety Instructions
Fundamental Safety Instructions User Manual CWD2005 Plus 2. Fundamental Safety Instructions Before operating or maintaining the instrument it is of utmost importance to get familiar with all operating and maintenance instructions contained in this manual. The manuals contain important information on how to operate the system safely and properly. - Page 8 User Manual CWD2005 Plus Fundamental Safety Instructions For damage resulting from inappropriate usage or repair or maintenance work the manufacturer will not undertake any liability. In the case of doubt a service technician of the manufacturer should be contacted and/or ordered.
-
Page 9: Information Related To Designated Use
Information related to designated use User Manual CWD2005 Plus 3. Information related to designated use The analyzer should be placed as close as possible to the sampling location to avoid unnecessary time delays. Install the analyzer in a climatically stable area; see the manual of the analyzer. -
Page 10: Specific Hazard Warning
User Manual CWD2005 Plus Information related to designated use Specific hazard warning Specific hazard warning Pay attention to all warnings placed on the analyzer. -
Page 11: Main System Configuration
Main System Configuration User Manual CWD2005 Plus 4. Main System Configuration The analyzer is developed and tested to directly operate in hazardous areas, the class1, Div.2, according to NEC500. The enclosure is equipped with a compressed air purging and safety shutdown. -
Page 12: Protection System
User Manual CWD2005 Plus Protection system 5. Protection system The enclosure of the analyzer is purged by compressed air with a min. consumption of 35 m³/h and a pre-pressure of 101.5 psi. Within the container there's an overpressure of 1 InWc. The air flows through the enclosure and rinse the analyzer. -
Page 13: Commissioning
Commissioning User Manual CWD2005 Plus 6. Commissioning The compressed air supply is connected via the connector on the right side of the analyzer. A flexible hose is with nominal diameter of 1/2 " is required. Fig. 1 A filter cartridge dryer unit must be installed. Pay attention: the maximum input pressure at the analyzer is 0.3 bar (4.351 psi). -
Page 14: Adjusting The Manometer
User Manual CWD2005 Plus Commissioning Adjusting the manometer The manometer has been pre-adjusted at the factory. Should it still necessary be adjusted, the adjustment should be performed with the enclosure door opens. -
Page 15: Power Requirements
Power requirements User Manual CWD2005 Plus 7. Power requirements The system requires one power supply. Power supply: 120, 1~, N, PE, 60Hz Work on electrical system may be accomplished by trained and instructed personnel only. Danger! Mains voltage 120V, 60Hz Contact with this voltage can cause serious burns or even death. -
Page 16: Manufacturer
User Manual CWD2005 Plus Manufacturer 8. Manufacturer The system has been designed, manufactured and tested by Union Instruments GmbH. For problem, technical questions, or ordering service or spare parts, please contact: UNION Instruments GmbH Zeppelinstr. 42 D-76185 Karlsruhe +49 (0)721-95243-0 +49 (0)721-95243-33 info@union-instruments.com...
