DUCOTERRA® SolaRay Electric Infrared Heating Ceiling Panels
• Attractive low-profile appearance
• High performance materials
Ducoterra's SolaRay ETL-Listed radiant ceiling panels are cost-effective, efficient heating solutions for both residential and
commercial environments and are easily installed in either new or existing construction. SolaRay panels are ideal for
augmenting heating in conjunction with ductless heat pumps or forced air systems, or for heating entire homes.
SolaRay panels are ideal alternatives for:
Baseboard and wall heater alternative or replacement
Remodel projects without existing ductwork (garages, guest houses, add-on rooms)
Areas with drafts, many windows, or with "cold spots"
Washrooms, shower rooms and other spaces with high ventilation rates
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and
injury to persons, including the following:
1) Read all instructions before installing and using this heater.
2) To prevent possible electrical shock, disconnect ALL power coming to the heater at main service panel before wiring or
servicing
3) Extreme caution is necessary when any heater is used by or near children or invalids and whenever the heater is left
operating and unattended.
4) Do not operate any heater after it malfunctions. Disconnect power at service panel and have heater inspected by a
reputable electrician before reusing.
5) Panels are intended for ceiling installation only. Do not install on walls, floor, etc. Do not use outdoors.
6) To disconnect heater, turn controls to off, and turn off power to heater circuit at main disconnect panel.
7) A heater has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or flammable vapors or
liquids are used or stored.
8) Use this heater only as described in this manual. Any other use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons.

1. Introduction

Ducoterra's SolaRay panels are designed to heat living
and working spaces rapidly and efficiently by radiant
heating. Like the sun, these panels will create a warm
environment for all people and objects within line of
sight of the panel surface. They are designed to be
surface mounted on ceilings or for installation in a T-bar
grid.

2. Installation Layout Guidelines

In a standard 8' ceiling room, these heating panels will
cover approximately 10 times the floor square footage as
panel size (e.g. a 2x4 panel will cover approximately 48
to 80 square feet of floor space). They may be installed
at zero clearance to adjoining walls and adjacent panels,
1645 JILL'S COURT, SUITE 108, BELLINGHAM, WA 98226 |

IMPORTANT INSTRUCTIONS

• Multiple Sizes and Mounting Options
Qualifies for LEED Certification
but optimal coverage is obtained by spacing the panels
to cover the floor space efficiently.
As maximum panel efficiency is obtained within a 45
degree angle of the panels, spacing panels 2' off walls
and approximately 4' from other panels will generally
cover a room sufficiently. Panels may need to be
positioned differently or installed at higher/lower
wattage
densities
configurations, insulation, heating requirements, and
other factors.

3. Environment Insulation Requirements

For proper functionality, the heated space should be
insulated appropriately. Optimal panel operation is
achieved if walls and ceilings are insulated according to
ASHRAE 189 standards in accordance with your local
www.ducoterra.com
|
info@ducoterra.com
depending
on
specific
| 360.788.4200
room

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SolaRay and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ducoterra SolaRay

  • Page 1 Ducoterra’s SolaRay ETL-Listed radiant ceiling panels are cost-effective, efficient heating solutions for both residential and commercial environments and are easily installed in either new or existing construction. SolaRay panels are ideal for augmenting heating in conjunction with ductless heat pumps or forced air systems, or for heating entire homes.
  • Page 2 Insert plastic caps to close mounting holes after allowing time to adjust installation if necessary. Caps are non-removable. Figure 1 – Surface Mounting SEE SCHEMATIC ON LAST PAGE FOR ADDITIONAL DETAILS ON SURFACE MOUNTING 1645 JILL’S COURT, SUITE 108, BELLINGHAM, WA 98226 | www.ducoterra.com info@ducoterra.com | 360.788.4200...
  • Page 3 If your panel ceases to operate at any operation. Radiant heat ceiling panels function best in a time during the warranty period, contact Ducoterra to zone heating configuration. Use a programmable obtain a replacement panel at no charge (installation and thermostat to apply appropriate setbacks to spaces that shipping costs not covered).
  • Page 4 LIMITED WARRANTY Ducoterra’s SolaRay radiant ceiling panels are warranted to the original owner against all defects in workmanship and materials for the lifetime of the product. This warranty applies only for normal use of the product, and shall not be effective for products or parts which do not function properly due to misuse, alteration, installation, accident, negligence, misapplication, modification, improper installation (including improper operating voltage) or maintenance, or if any product or part has been serviced or repaired by other than DUCOTERRA.
  • Page 5 SolaRay Infrared Radiant Ceiling Panel Schematic and Assembly Details Shown below is a SolaRay 2’ X 4’ panel schematic. The location of the Handybox is the same for all panels. Spacing between holes is as shown in the Standard Model Specifications table.
