Quick-Start Operating Guide
Document No. 1800-73
CleanBooth™ Laminar Flow Station
© Copyright 2020 Terra Universal Inc. All rights reserved. • Revised May 2020
Revised May 2020
Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CleanBooth 1870-03B and is the answer not in the manual?

Questions and answers

Related Manuals for Terra CleanBooth 1870-03B

Summary of Contents for Terra CleanBooth 1870-03B

  • Page 1 CleanBooth™ Laminar Flow Station © Copyright 2020 Terra Universal Inc. All rights reserved. • Revised May 2020 Revised May 2020 Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...

  • Page 2: Table Of Contents

    CleanBooth Narrow Version 1870-03B ....................4 3.2. CleanBooth Wide Version 1870-04B: ....................8 Maintenance ............................13 Specifications ............................14 Warranty .............................. 16 Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...

  • Page 3: Introduction

    GripTrack™ system. System options include fluorescent lighting and ionizing bars – see maintenance descriptions below. Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...

  • Page 4: Installation

    GripTrack mount, seating the curtain bead inside the track, and snapping the cover down to secure the curtain. 3.1. CleanBooth Narrow Version 1870-03B Step 1: Connect the two frame members Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
  • Page 5 © Copyright 2020 Terra Universal Inc. All rights reserved • Revised May 2020 • Document No. 1800-73 v2.0tm Step 2 (OPTIONAL): Apply gasketing along the ceiling grid perimeter Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
  • Page 6 © Copyright 2020 Terra Universal Inc. All rights reserved • Revised May 2020 • Document No. 1800-73 v2.0tm Step 3: Place the fan filter units onto the ceiling Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
  • Page 7 © Copyright 2020 Terra Universal Inc. All rights reserved • Revised May 2020 • Document No. 1800-73 v2.0tm Step 4: Place curtain panels along the left, right, and back side. Step 5: Completed assembly Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...

  • Page 8: Cleanbooth Wide Version 1870-04B

    © Copyright 2020 Terra Universal Inc. All rights reserved • Revised May 2020 • Document No. 1800-73 v2.0tm 3.2. CleanBooth Wide Version 1870-04B: Step 1: Assemble the base frame as shown below. Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
  • Page 9 © Copyright 2020 Terra Universal Inc. All rights reserved • Revised May 2020 • Document No. 1800-73 v2.0tm Step 2: Connect the top frame onto the base frame assembly. Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
  • Page 10 Step 3 (OPTIONAL): Apply gasketing along the ceiling grid perimeter Step 4: Place the fan filter units onto the ceiling Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
  • Page 11 Step 5: Place the curtain panels on the left, right, and back sides Step 6: Place the curtain strips on the entrance of the Cleanbooth Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
  • Page 12 © Copyright 2020 Terra Universal Inc. All rights reserved • Revised May 2020 • Document No. 1800-73 v2.0tm Step 7: Completed assembly Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...

  • Page 13: Maintenance

    (typical life: two years of continuous operation). When ballast fails, replace entire light fixture (typical life: five years of continuous operation). Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...

  • Page 14: Specifications

    90 (±10) FPM (.45 m/s), when measured using a Velgrid (eight readings) 6 in. (152mm) below the filter face. Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
  • Page 15 All filters are tested for air flow resistance and DOP (dioctylphthalate) smoke penetration (with a mean particle diameter of 0.3 microns) by measuring upstream and downstream smoke concentrations with a photometer. Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...

  • Page 16: Warranty

    Products Manufactured by Terra: Terra Universal, Inc., warrants products that it manufactures to be free from defects for a period of 12 months for parts and 90 days for labor, commencing from the date of shipment. Terra’s sole responsibility is to repair or replace, at its option, any part of the product that proves defective or malfunctioning during this time limit.
