Multiple Power Supply
Scientech 4077
Learning Material
Ver.1.1
An ISO 9001:2008 company
Scientech Technologies Pvt. Ltd.
94, Electronic Complex, Pardesipura, Indore - 452 010 India,
+ 91-731 4211100,
: info@scientech.bz ,
:
www.ScientechWolrd.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scientech 4077 and is the answer not in the manual?

Questions and answers

Summary of Contents for Scientech Technologies Scientech 4077

  • Page 1 Multiple Power Supply Scientech 4077 Learning Material Ver.1.1 An ISO 9001:2008 company Scientech Technologies Pvt. Ltd. 94, Electronic Complex, Pardesipura, Indore - 452 010 India, + 91-731 4211100, : info@scientech.bz , www.ScientechWolrd.com...
  • Page 2 Please remember that each paper manual requires 50-100 sheets of paper on an average. Your CD learning material has colourful diagrams, plenty of theory, detailed experiments with observation tables, frequently asked questions, etc. …….. and more so sometimes videos as well. Scientech Eco Foundation Scientech Technologies Pvt. Ltd.
  • Page 3 Scientech 4077 Scientech Technologies Pvt. Ltd.
  • Page 4: Table Of Contents

    It is mandatory that service engineers use lead free solder wire and use the soldering irons upto (25 W) that reach a temperature of 450°C at the tip as the melting temperature of the unleaded solder is higher than the leaded solder. Scientech Technologies Pvt. Ltd.
  • Page 5: Safety Instructions

    Use in proper Atmosphere : Please refer to operating conditions given in the manual. Do not operate in wet / damp conditions. Do not operate in an explosive atmosphere. Keep the product dust free, clean and dry Scientech Technologies Pvt. Ltd.
  • Page 6: Introduction

    Scientech 4077 Introduction Scientech 4077 Multiple Power Supply has been designed as a constant current (CC) and constant voltage (CV), source for laboratories, industries and field testing applications, featuring low power loss, compact and lightweight. It provides three floating independent DC output voltages and is ideally suitable for complex analog and digital testing.
  • Page 7: Features

    A: 0 -30V, 2A B: 5V, 2 Amps C: 0 ± 15V (Dual Tracking) /1A each  Constant voltage and constant current operation  Short circuit protection  Digital display for voltage and current  Adjustable current limiter Scientech Technologies Pvt. Ltd.
  • Page 8: Technical Specifications

    Load & Line Regulation 0.05% Temperature Coefficient 0.05% + 5 mV/C Ripple & Noise 1mVrms Display 3digits for voltage, 3 digits for current LED indication for voltage & current Accuracy ± (1% rdg + 1 dgt) Scientech Technologies Pvt. Ltd.
  • Page 9 > 50 M at 500VDC and AC plug Power Supply 230V AC ± 10% 50Hz Operating Conditions 0 - 40 C; 90% RH Dimension W 285 x H 75x D 385 mm Weight 5.5 Kgs. (approximately) (Subject to Change) Scientech Technologies Pvt. Ltd.
  • Page 10: Front Panel Controls

    For current limit setting of the outputs A & C respectively. Adjustment range 100mA -2A & 20mA - 1A each. 8 & 14 Digital Display (7-segment LED): 3-digit readout for output voltage & 3 digit readout for output current. Scientech Technologies Pvt. Ltd.
  • Page 11 ORA, ORB, ORC-, ORC+ (Overload indicators): LEDs for overload indication for respective DC outputs are provided. In case of overheating or output current in excess of set limit corresponding OR LED lits up. Scientech Technologies Pvt. Ltd.
  • Page 12: Operating Instructions

    230V ± 10%. Switch on the instrument. The power ‘On’ is indicated by lighting of displays. Operation: The Multiple Power Supply Scientech 4077 has three electrically isolated supply voltages. This permits easy series connection of output voltages. In case of series connection the maximum output voltage increases with a maximum current of 2Amp.
  • Page 13: Functional Checks

    DC output voltage should be  4.0 V, when measured on DMM. Check of maximum output current: Set the current limit knob "I maximum" to 5V maximum Short circuit the output terminals. The reading on the current display should be 2.10A Scientech Technologies Pvt. Ltd.
  • Page 14 Set the I maximum, to maximum Connect two equal loads of any value to both '+' and '-' outputs with respect to common terminal. Check the ripple and noise on DMM. It should not be more than 1mVrms in both the sections. Scientech Technologies Pvt. Ltd.
