8.0 Using the saw

8.1 On/Off switch (Fig. 1)
The saw can be switched on by pressing the
green pushbutton.
The red pushbutton has to be pressed to switch
off the saw.
8.1.1 Cutting depth (Fig. 11)
Turn the round handle (17) to set the blade (4) to
the required cutting depth.
Turn anti-clockwise:
Turn clockwise:
8.2 Parallel stop
8.2.1 Stop height (Fig. 7/8)
The stop rail (25) supplied has two different
guide faces (high and low).
For thick material you must use the stop rail (25)
as shown in Fig. 7, for thin material you must use
the stop rail as shown in Fig. 8.
To change the height of the stop, slacken the two
knurled screws (16) and pull the stop rail off the
carrier rail.
Turn the stop rail (25) 90° to the left or the right,
depending on the required height of the stop,
and plug in back on the carrier rail (26).
Re-tighten the knurled screws (16).
8.2.2. Stop length (Fig. 7/8)
To prevent the workpiece becoming jammed,
always slide the stop rail (25) to the front edge of
the table (1) and fix it in place with the two
knurled screws (16) (see 8.2.1).
8.2.3 Cutting width (Fig. 8)
The parallel stop (7) has to be used when
making longitudinal cuts in wooden workpieces.
Slide the parallel stop (7) to the right or left side
of the saw table (1).
The parallel stop (7) can be set to the required
dimension with the help of the scale (b) engraved
on the saw table (1).
Tighten the two star grip screws (12) in order to
fix the parallel stop (7).
8.3 Setting the angle (Fig. 1/2/10)
Undo the fixing handle (15).
Turn the locking screw (16) to set the blade (4) to
the required angle value (see scale (13)).
Re-tighten the fixing handle (15).
25.07.2006 16:11 Uhr Seite 17
8.4. Cross stop (Figure 9)
Slide the cross stop (14) into the groove (a) of
the table.
Slacken the knurled screw (c).
Turn the cross stop (14) until the arrow points to
the angle required.
Retighten the knurled screw (c).
When cutting large parts of workpieces you can
use the stop rail (25) from the parallel stop (7) to
extend the length of the cross stop (14).
8.5 Table width extension (21) (Fig. 1/9/10)
Important!
larger cutting depth
The table width extension should be pulled out for
smaller cutting depth
wide pieces of wood.
Slacken the knurled screws (e)
Pull out the table width extension (21)
Swing out the support foot (22)
Retighten the knurled screws (e)

9. Sawing operations

After each new adjustment it is advisable to
carry out a trial cut in order to check the set
dimensions.
After switching on the saw, wait for the blade to
reach its maximum speed of rotation before
commencing with the cut.
Secure long workpieces against falling off at the
end of the cut (e.g. with a roller stand etc.)
Take extra care when starting the cut!
9.1 Cutting narrow workpieces
(width less than 120 mm) (Fig. 12)
Adjust the parallel stop (7) to the width of
workpiece you require.
Feed in the workpiece with two hands. Always
use the push stick (3) in the area of the saw
blade (4).
(A push stick is supplied with the saw!)
Always push the workpiece through to the end of
the splitter (5).
Caution! With short workpieces, use the push
stick from the beginning.
9.2 Cutting extremely narrow workpieces
(width less than 30 mm) (Fig. 13)
Adjust the parallel stop (7) to the width of
workpiece you require.
Use the push block (d) to press the workpiece
against the stop rail (25) and push the workpiece
with the push stick (3) through to the end of the
splitter (5).
There is no push block supplied with the saw!
(Available from your specialist dealer)
