DIGI*TRAC
Annunciator Guide
DTA001-0602

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIGI TRAC and is the answer not in the manual?

Questions and answers

Related Manuals for HIRSCH DIGI TRAC

Summary of Contents for HIRSCH DIGI TRAC

  • Page 1 DIGI*TRAC Annunciator Guide DTA001-0602...
  • Page 2 2001 Hirsch Electronics Corporation. All rights reserved. ScramblePad is a registered ® trademark of Hirsch Electronics Corporation. DIGI*TRAC™, MATCH™, ScramblePad, ScrambleProx SCRAMBLE*NET™ (abbreviated S*NET) are all trademarks of Hirsch Electronics Corporation. Hirsch Electronics Corporation 1900 East Carnegie Avenue Building B...
  • Page 3 Attn: Technical Services Voice: (877) HIRSCHX (technical queue) (888) 809-8880 Fax: (949) 250-7362 Email: support@hirschelectronics.com WWW: www.hirschelectronics.com Whenever you call your local dealer or Hirsch, be sure to have your registration material, serial number and software version number available. Getting Help...
  • Page 4 DIGI*TRAC Annunciator Guide Getting Help...
  • Page 5 DTA001-0602 Introduction The DIGI*TRAC Annunciator (DTA) is used to monitor basic security functions—such as alarm, input, and relay status. It provides a local display of critical information near or outside the protected area. The DTA is ideal for lobbies and other passages outside of the secured area where a qualified individual can confirm the protected area is secure.
  • Page 6 DIGI*TRAC Annunciator User’s Guide Both a picture and an illustration of this front panel is shown in Figure 2: 4-line LCD screen 4-button keyboard Figure 2: DIGI*TRAC Annunciator – Front View These keys are used for status requests only and cannot issue commands of any sort.
  • Page 7 The DIGI*TRAC Annunciator comes pre-assembled with the MATCH2 board installed on the back of the DTA. Hirsch supplies the DTA in either a surface-mounted or flush-mounted back box. For surface-mounting, Hirsch provides a MB4; For flush-mounting, Hirsch supplies the MB3.
  • Page 8 DIGI*TRAC Annunciator User’s Guide A more complex example is shown in Figure 5: Figure 5: Annunciator Example This example represents the way in which an annunciator can be used to monitor activity within a given area—in this case, three rooms incorporating readers, keypads, relays, motion detectors, amongst other devices—and supply alarm and event information specific to the entry and exit of personnel to/from that area.
  • Page 9 DTA001-0602 To install the Annunciator: 1. Locate the place where you want to install the DTA. The DTA should be located near the ScramblePad/ScrambleProx and/or reader that will authorize the DTA’s use. 2. Use the surface mount plate or flush mount back box to position and draw an outline on the wall.
  • Page 10 HEAT SHRINK ALL SPLICES NOTE: Special power filter is required 1 2 3 4 5 6 7 8 and can be purchased separately from Hirsch (part # HPF). This modification is factory-provided when the CR20L-125-6005 ProxPoint reader is ordered. NOTES...
  • Page 11 DTA001-0602 If you are using a ScrambleProx as the keypad, follow these Using a instructions (as shown in the example in Figure 8): ScrambleProx a. Connect an extension cable from the D*TRAC port on the back of the ScrambleProx to the KEYPADS port on the DTA’s MATCH2 board.
  • Page 12 DIGI*TRAC Annunciator User’s Guide Assigning Annunciator Privileges The process of enabling the DTA for the controller depends on the host PC software used. There are three methods for assigning Annunciator privileges to a user: Keypad assignment (programming) SAM assignment Velocity assignment Each of these methods is discussed in this section.
  • Page 13 DTA001-0602 4. Select the access zone and the code extension you require to activate this DTA. Select the ID Format and Code extension Select the Access you want to activate Zone you need for the DTA this function Select Alarm Cancel from the Alarm Control option list Figure 9: Programming the Controller Using SAM...
  • Page 14 DIGI*TRAC Annunciator User’s Guide Velocity Assignment If you are using Velocity, you can assign an operator the ability to use the Annunciator in one of two ways: Define a Function Group Define a user credential through Enrollment Manager Creating a Function Group is the best way if you plan to assign Annunciator privileges to more than one user.
  • Page 15 DTA001-0602 13. Using Function Groups in the Administrative Mode, assign this function group to the specified user(s) on the Function property page. Click Add... Select Alarm & Alarm Cancel Click Add... Click OK Figure 10: Assigning Annunciator Privileges using Velocity’s Function Group...
  • Page 16 DIGI*TRAC Annunciator User’s Guide Single Credential Assignment To assign Annunciator privileges for a single credential through Enrollment Manager: 1. Open the Enrollment Manager. 2. Select the person to whom Annunciator privileges should be assigned. 3. Create a new credential by double clicking the Add New Credential button.
  • Page 17 DTA001-0602 Enter code and/or card Click Function Tab then Alarm & Alarm Cancel Figure 11: Assigning Annunciator Privileges to a Credential using Enrollment Manager...
  • Page 18 DIGI*TRAC Annunciator User’s Guide Operating the Annunciator The following procedure shows you how to use the Annunciator. 1. Go to the keypad (either ScramblePad or ScrambleProx) or card reader connected to the DTA. This normally will be the keypad or reader mounted closest to the DTA.
  • Page 19 DTA001-0602 These options are: Press this button to: End the current session and return the DTA to inactive mode. ALM LOG Display the log of all alarms experienced by this controller only. INP STAT Display the current status for all inputs connected to this controller only.
  • Page 20 DIGI*TRAC Annunciator User’s Guide If you press INP STAT, a screen like Figure 15 appears: BACK EXIT Figure 15: Input Status Menu This screen displays the current Alarm Input or Expansion Alarm Input status. The report is time stamped at the time the button is pushed.
  • Page 21 DTA001-0602 An example of several possible input status values are shown in Figure 16: Figure 16: Input Status Example If you press RELAY STAT, a screen like Figure 17 appears: BACK EXIT Figure 17: Relay Status Menu A list of abbreviations used in this display are explained in the following table: The relay designation followed by the number of this relay, such as R1 or R2.
  • Page 22 DIGI*TRAC Annunciator User’s Guide F in 2nd group Control Force Off. Actuate by Time Zone. D (in middle) Disable by Time Zone. Control Zone “Drive On” by Alarm Input or Expansion Alarm Input. F in 4th group Control Zone “Drive Off” by Alarm Input or Expansion Alarm Input.
  • Page 23 DTA001-0602 • If this is Alarm Log, use the ERASE key to delete the alarm log. All alarms are cleared from the buffer and a screen like this appears. • If this is the Alarm Log, press SAVE to save the current alarm entries for later review.
  • Page 24 DTA, refer to “ScramblePad/MATCH Inputs” on page 2-15 of the DIGI*TRAC Design and Installation Guide (Hirsch# MAN001). For information on powering a ScramblePad or MATCH locally, see “Powering ScramblePads/MATCH Interfaces Locally” on page 2-31 in the DIGI*TRAC Design and Installation Guide.
