- Page 1 SERVICE MANUAL H6510A IMPACT WRENCH Serial Codes FJR, FJT, FJV, and FPH Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 999 1596.0 REV 3 © 2001 Greenlee Textron 2/01...
-
Page 2: Table Of Contents
Loctite and 242 are registered trademarks of Loctite Safety Corporation. Safety is essential in the use and maintenance of Fairmont tools and equipment. This instruction manual Other Publications and any markings on the tool provide information for avoiding hazards and unsafe practices related to the use of this tool. -
Page 3: Important Safety Information
H6510A Impact Wrench IMPORTANT SAFETY INFORMATION SAFETY Skin injection hazard: ALERT Oil under pressure easily punctures skin causing serious injury, gan- SYMBOL grene or death. If you are injured by escaping oil, seek medical attention This symbol is used to call your attention to hazards immediately. - Page 4 H6510A Impact Wrench IMPORTANT SAFETY INFORMATION Hydraulic oil can cause skin irritation. Do not exceed the maximum hydraulic flow, pressure relief or back pressure listed in the • Handle the tool and hoses with care to prevent Specifications and Parts manual.
-
Page 5: Disassembly
Clean all parts with an appropriate cleaning solution and If a complete overhaul is necessary, return the tool to dry them thoroughly. Inspect each component as your nearest authorized Fairmont distributor or to described in this section. Replace any component that Fairmont. -
Page 6: Assembly
H6510A Impact Wrench Assembly Refer to the Illustration and Parts List for correct Motor and Hammer Case orientation and placement of parts. 1. Install the hammer assembly (34–45). Install the Replace any O-rings, V-rings, seals, and gaskets on hammer case (29) and secure with three cap parts that have been disassembled. -
Page 7: Illustration And Parts Lists
H6510A Impact Wrench Illustration Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070... - Page 8 41616 F016807 Screw, Cap, 1/4 – 20 x 1.00" Socket Head ......... 1 40190 105369 Valve Spool (H6510A and H6510A2) ..1 40204 105385 Valve Spool (H6510A1 and H6510A3) ..1 40242 107725 Spring, Comp., .265 x .359 x .812" ..1...
- Page 9 H6510A Impact Wrench Parts List (cont’d) UPC NO. PART 78-3310- DESCRIPTION QTY. 43382 FOR002491 Pin, Dowel, .250 x .625" ......2 42112 FOR002812 Rotor Pinion ..........1 43935 FOR003744 Race, Thrust Bearing ....... 1 48661 48661 Guide ............1 48170 48170 Spring ............
- Page 10 Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Drive, Rockford, IL 61109-2988 USA Customer Service (International): 815/397-7070 • Fax: 815/397-9247 Customer Service (North America): 800/435-0786 • Fax: 800/451-2632, 815/397-1865 Canada Fax: 800/524-2853 Printed in the U.S.A.
